- Page 1 INSTALLATION- AND OPERATING INSTRUCTIONS Steam generator Condair Sigma Humidification and Evaporative Cooling...
- Page 2 Condair Group AG, except to the extent required for installation or maintenance of recipient's equipment. Liability Notice Condair Group AG does not accept any liability due to incorrect installation or operation of the equipment or due to the use of parts/components/equipment that are not authorised by Condair Group AG.
-
Page 3: Table Of Contents
Common steam and condensate line errors 5.4.5 Inspecting the steam installation Water installation 5.5.1 Overview water installation 5.5.2 Notes on water installation 5.5.3 Inspecting the water installation Electric installation 5.6.1 Hinweise zur Elektroinstallation 5.6.2 Wiring diagram Condair Sigma 4 kg/h Contents... - Page 4 5.6.4.5 Connecting the heating voltage to the Condair Sigma 5-65 kg/h 5.6.4.6 Connecting the voltage supply to the Condair Sigma 5-65 kg/h via Option TR 5.6.4.7 Connecting the voltage supply to the Condair Sigma 5-65 kg/h via Option CVI 5.6.4.8 Connecting the voltage supply to the Condair Sigma 4 kg/h 5.6.5...
-
Page 5: Introduction
The steam generator Condair Sigma incorporates the latest technical ad van ces and meets all recognized safety standards. Nevertheless, improper use of the Condair Sigma may result in danger to the user or third parties and/or impairment of material assets. - Page 6 Please safeguard these installation and operating instructions in a safe place, where it can be immediately accessed. If the equipment changes hands, the documentation should be passed on to the new operator. If the documentation gets mislaid, please contact your Condair supplier. Language versions The present installation and operation manual is available in various languages.
-
Page 7: For Your Safety
For safety and warranty reasons any action beyond the scope of this manuals must be carried out only by qualified personnel authorised by the manufacturer. It is assumed that all persons working with the Condair Sigma are familiar and comply with the appropri- ate regulations on work safety and the prevention of accidents. - Page 8 DANGER! Danger of electric hazard! The Condair Sigma is mains powered. One may get in touch with live parts when the unit is open. Touching live parts may cause severe injury or danger to life. Prevention: Before carrying out any work set the Condair Sigma out of operation as described in chapter 6.5...
-
Page 9: Product Overview
Product Overview Models overview Steam generators Condair Sigma are available with different heating voltages and steam capacities ranging from 4 kg/h up to a max. of 65 kg/h. Heating voltage ** Max. steam capacity Model Unit size in kg/h Condair Sigma... -
Page 10: Identification Of The Unit
Identification of the unit The identification of the unit is found on the type plate: Type designation Serial number (7 digits) Month/Year Condair Group AG, Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland Heating voltage Type: Condair Sigma 4564 Ser.Nr.: XXXXXXX 02.10 Heating voltage: 400V / 3~ / 50...60Hz Power: 33.8 kW... -
Page 11: Construction Of The Condair Sigma
Construction of the Condair Sigma Abb. 2: Construction of the Condair Sigma (figure shows medium unit) Housing (small, large) Filling hose Cable openings, top side Water supply hose Overflow hose SC pump (option) Main contactor Drain valve Power board Inlet valve... -
Page 12: Functional Description
Functional description The steam generator Condair Sigma is a pressureless steam generator that utilizes an electrode heat- ing. The steam generator Condair Sigma is designed for SPA applications. Steam hose Steam distributor Condensate hose with siphon (if steam distributor is installed... - Page 13 Steam generation Any time steam is requested, the electrodes are supplied with voltage via main contactor. Simultaneously, the inlet valve opens and water enters the steam cylinder from the bottom via water cup and supply line. As soon as the electrodes come in contact with the water, current begins to flow between the electrodes, eventually heating and evaporating the water.
-
Page 14: System Overview
Water connection hose G 3/4"- G 3/8" Steam hose (accessory "DS..") (included in the delivery) SPA Display Manometer (installation recommended) Condair Delta SPA Control Box Filter valve (accessory "Z261") Electrical isolator Condair Delta SPA Control Box Abb. 4: System overview Product Overview... -
Page 15: Options
SC pump (lime management system) 1xSC The SC pump keeps the solved minerals in the water of the steam cylinder in motion, in order to discharge them with the automatic drain cycles. Condair Sigma... (400 V/3~/50...60 Hz) 1534 2364 3264 4564 6564 Steam cylinder for low water conductivity from 80 to 125 µS/cm... -
Page 16: Accessories
1x KS10 Condensate drain 1xCD22 1xCD35 2xCD35 T-piece for fragrance injection 1xTSD22 1xTSD35 2xTSD35 Fragrance pump 1xFP 240V Accessories for control Condair Sigma ... 1532 2362 3262 4564 6564 1534 2364 3264 SPA control Condair Delta SPA Control Box Product Overview... -
Page 17: Accessory Details
3.7.2 Accessory details 3.7.2.1 Steam distributor DDS22 ø22.5 mm ø48.5 mm max. 19 mm Abb. 5: Steam distributor DDS22 (up to max. 5 kg/h) 3.7.2.2 Steam distributor DDL35 ø43 mm DDL35: ø35 mm max. 18 mm Abb. 6: Steam distributor DDL35 (15-32 kg/h) Product Overview... -
Page 18: Steam Distributor
3.7.2.3 Steam distributor W22/W35 W22: ø43 mm W35: ø61 mm W22: ø22.5 mm W35: ø35 mm Abb. 7: Steam distributor W22 (4-8 kg/h) / W35 (15-65 kg/h) Product Overview... -
Page 19: Standard Delivery
Standard delivery The standard delivery includes: – Steam generator Condair Sigma with water drain hose and water connection hose G 3/4" - G 3/8" equipped with the options ordered according to 3.6, fixing set and installation and operating chapter instructions (this document), packaged in cardboard box –... -
Page 20: Notes For The Planning Engineer
The total amount of losses depends on the entire system and must be taken into consideration when determining the required steam capacity. If you have any questions regarding the calculation of the steam capacity please contact your Condair supplier. Notes for the planning engineer... -
Page 21: Selecting The Unit
4.1.2 Selecting the unit Condair Sigma 4564 400V3 Model Unit size Heating voltage ** Max. steam capacity Condair Sigma .. in kg/h small medium large 1534 400V3 2364 (400 V/3~/50...60 Hz) 3264 4564 6564 400V2 (400 V/2~/50...60 Hz) 230V3 1532 (230 V/3~/50...60 Hz) -
Page 22: Mounting And Installation Work
Mounting and installation work Important notes for mounting and installation work Qualification of personnel All mounting and installation work must be carried out only by well qualified personnel authorised by the owner. It is the owner’s responsibility to verify proper qualification of the personnel. General note Strictly observe and comply with all information given in the present installation and operating instructions regarding the location of the unit and the installation of water, steam and electricity. -
Page 23: Installation Overviews
Installation overviews DDS22 DDL22 DDL35 min. 15 % – min. 15 % min. 15 % min. 15 % – DS22 DS35 DDS22 ø 30 mm DDL22 DDL35 G 3/4" ø14/7 mm G 1/2" G 3/8" Z261 125...1250 µS/cm 1...10 bar ≥... -
Page 24: Mounting The Unit
1 ... 40 °C max. 75 %rh IP20 1532 2362 3262 4564 6564 1534 2364 3264 Condair Sigma ... Dimensions Housing (XxYxZ) in mm 285x205x430 377x279x612 492x351x670 Weights Net weight in kg Operating weight in kg Mounting and installation work... - Page 25 The steam generator Condair Sigma may only be installed in rooms with a floor drain. CAUTION! If for some reason the Condair Sigma must be installed in a location without floor drain, it is manda- tory to provide a leakage monitoring device to safely interrupt the water supply in case of leakage.
-
Page 26: Mounting The Humidifier
5.3.2 Mounting the humidifier Dimension Housing size small medium large 175 mm 189 mm 246 mm 35 mm 61 mm 52 mm 335 mm 490 mm 547 mm 130 mm 120 mm 180 mm 75 mm 120 mm 180 mm Procedure 1. Mark the attachment point "A" on the wall. 2. -
Page 27: Inspecting The Installed Unit
5.3.3 Inspecting the installed unit Check the following points: Is the unit installed in the correct place (see chapter 5.3.1)? Is the supporting surface stable enough? Is the unit correctly aligned, vertically and horizontally? Is the unit properly secured (see chapter 5.3.2)? Has the front panel of the unit been relocated and correctly fixed with the two screws? -
Page 28: Steam Installation
Steam installation 5.4.1 Overview steam installation DDS22 DDL22 DDL35 min. 15 % – min. 15 % min. 15 % – min. 15 % min. 15 % DS22 – DS35 DDS22 DDL22 DDL35 Abb. 9: Overview steam installation Mounting and installation work... -
Page 29: Positioning/Mounting The Steam Distributor
5.4.2 Positioning/mounting the steam distributor It’s the responsibility of the customer to correctly position the steam distributor in the steam bath cabin. WARNING! Hot water vapour - Danger of scalding! Shield the steam outlet of the steam distributor with corresponding measures to make sure steam bath users can not be burned by the steam flow. -
Page 30: Installing The Steam And Condensate Lines
5.4.3.1 Notes on installation – Use original steam and condensate hose from your Condair representative or solid steam pipes from copper or stainless steel (min. DIN 1.4301) exclusively. Steam and condensate lines from other material may cause undesired operational malfunctions. -
Page 31: Installation Examples
– Steam hoses must be prevented from sagging (condensate pockets); if necessary, support steam hose with pipe clamps, trough, or wall brackets, and install a condensate drain at any low points in the steam line. – It is not permitted to install a stop valve (e.g. a manually controlled stop valve, solenoid valve, etc.) in the steam line, due to an inadmissible increase of pressure in the steam tank if the valve is closed during the operation. - Page 32 min. 15 % min. 15 % – min. 15 % – Obstacle min. 15 % min. 15 % min. 15 % – min. 15 % – Ensure adequate cooling according to local codes Install condensate drain (full size T) at the lowest point Abb.
- Page 33 min. 15 % min. 15 % – min. 15 % – min. 15 % – Abb. 12: Steam line with solid piping and insulation The following notes should be observed: – The minimum internal diameter of the steam line (diameter dependent on the steam generator) should be applied over the entire length of the piping.
- Page 34 – The minimum bend radius for fixed piping is 5 x steam pipe inside diameter. – Connection of the steam pipes to the steam distributor and the steam outlet connector on the steam tank is effected with pieces of steam hose with an appropriate length (the length of the steam hose connected to the steam outlet of the steam generator must be min.
-
Page 35: Common Steam And Condensate Line Errors
5.4.4 Common steam and condensate line errors Wrong Correct Steam hose/steam hose piece not led at least 300 mm perpen- Lead steam hose/steam hose piece at least 300 mm (for steam dicularly upwards before first bend (forming of condensate). hose installations) or 1,000 mm (for solid pipe installation) perpendicularly upwards before first bend. -
Page 36: Inspecting The Steam Installation
5.4.5 Inspecting the steam installation Use the following check list to ascertain that the steam installation was performed correctly: – Steam distributor Is the steam distributor correctly positioned and fastened in the SPA cabin? Is the steam outlet of the steam distributor shielded by appropriate measures so that the steam bath users cannot burn themselves on the escaping steam? –... -
Page 37: Water Installation
Water installation 5.5.1 Overview water installation G 3/4" ø 30 mm G 3/4" ø14/7 mm G 3/8" ø 40/31 mm G 3/4" ø 30 mm G 3/4" ø 30 mm G 3/4" ø14/7 mm ø14/7 mm G 1/2" ø 40/31 mm G 3/8"... -
Page 38: Notes On Water Installation
The use of additives such as corrosion inhibitors, disinfectants, etc. is not allowed, since these additives may endanger health and affect proper operation. – If the Condair Sigma shall be operated with softened or partly softened water, please contact your Condair supplier. –... -
Page 39: Inspecting The Water Installation
5.5.3 Inspecting the water installation Check the following topics: – Water supply Has filter valve (accessory "Z261") or shut-off valve and 5 µm water filter respectively been installed in supply line? Have admissible water pressure (1 – 10 bar) and admissible temperature (1 – 40 °C) been ob- served? Does the supply capacity match the steam generator and is the minimum internal diameter of 8 mm of the supply pipe maintained throughout the entire length? -
Page 40: Electric Installation
DANGER! Danger of electric shock The Condair Sigma is mains powered. Live parts may be exposed when the unit is open. Touch- ing live parts may cause severe injury or danger to life. Prevention: The Condair Sigma unit must be connected to the mains only after all mounting and in- stallation work has been completed, all installations have been checked for correct workmanship and the unit is closed and properly locked. -
Page 41: Wiring Diagram Condair Sigma 4 Kg/H
Connection terminal unit switch Short circuited, if no external monitoring devices are Connection terminal voltage supply connected Set jumper for voltage output on X1, V+ = 5 V (remove jumper JP1) Abb. 15: Wiring diagram Condair Sigma 4 kg/h Mounting and installation work... -
Page 42: Wiring Diagram Condair Sigma 5-65 Kg/H
5.6.3 Wiring diagram Condair Sigma 5-65 kg/h Control board Power board L1 L2 L3 Smart Card CURRENT SENSOR LEV.SENSOR Drain Factor L1 L2 L3 Cylinder Power Limit ext. Settings CPU BOARD Manual Drain Low Conduct. (6.3 AT) Standby Drain Force Drain... -
Page 43: Installation Work External Connections
5.6.4 Installation work external connections 5.6.4.1 Connecting the external safety chain Condair Sigma 4 kg/h The potential-free contacts of external moni t or ing de- SAFETY vices (e.g.safety humidistat "B1") are connected in series (safety chain "K") to the terminals "SC1" and "SC2" of the terminal block "X6"... -
Page 44: Humidity Control Wiring
5.6.4.2 Humidity control wiring Connecting a demand signal 0-10 V to the Condair Sigma 4 kg/h The demand signal cable of an external controller is to CONT.SIGN be connected according to the wiring diagram to the terminals "CTRL" and GND" of the terminal strip "X1"... - Page 45 Connecting a 24V On/Off humidistat/thermostat to the Condair Sigma 4 kg/h The signal cable of 24V On/Off humidistat/thermostat is to be connected according to the wiring diagram to the terminals "V+" and "CTRL" of the terminal strip "X1" on the driver board in the control compartment.
-
Page 46: Connecting The Optional Remote Operating And Fault Indication To The Condair Sigma 5-65 Kg/H (Option)
5.6.4.3 Connecting the optional remote operating and fault indication to the Condair Sigma 5-65 kg/h (Option) The optional remote operating and fault indication board contains four potential-free relay contacts for the con- nection of the following operating and fault indications: F1 (100 mA) –... -
Page 47: Connecting The Control Voltage To The Condair Sigma 5-65 Kg/H
5.6.4.4 Connecting the control voltage to the Condair Sigma 5-65 kg/h The control voltage supply (L1, N, PE) is to be con- MAIN SUPPLY nected in accordance with the wiring diagram to the L1 N SC1SC2 corresponding terminals on the driver board in the control compartment. -
Page 48: Connecting The Heating Voltage To The Condair Sigma 5-65 Kg/H
5.6.4.5 Connecting the heating voltage to the Condair Sigma 5-65 kg/h The heating voltage supply (L1, L2, L3 and PE or L1, N and PE, respectively) is to be connected in accordance L1 L2 L3 with the wiring diagram to the corresponding terminals of the main contactor "K1"... -
Page 49: Connecting The Voltage Supply To The Condair Sigma 5-65 Kg/H Via Option Tr
5.6.4.6 Connecting the voltage supply to the Condair Sigma 5-65 kg/h via Option TR MAIN SUPPLY L1 N SC1SC2 L1 L2 L3 Control compartment 6.3 A, slow acting Option TR (3Ph) 400 V/3~/50..60 Hz The voltage supply (L1, L2, L3 and PE) is to be connected in accordance with the wiring diagram to the corresponding terminals of option "TR". -
Page 50: Connecting The Voltage Supply To The Condair Sigma 5-65 Kg/H Via Option Cvi
5.6.4.7 Connecting the voltage supply to the Condair Sigma 5-65 kg/h via Option CVI MAIN SUPPLY L1 N SC1SC2 L1 L2 L3 Control compartment 6.3 A, slow acting Option CVI (3Ph+N) 400 V/3~N/50..60 Hz The voltage supply (L1, L2, L3, N and PE) is to be connected in accordance with the wiring diagram to the corresponding terminals of option "CVI". -
Page 51: Connecting The Voltage Supply To The Condair Sigma 4 Kg/H
5.6.4.8 Connecting the voltage supply to the Condair Sigma 4 kg/h The voltage supply (L1, N and PE) is to be connected MAIN SUPPLY in accordance with the wiring diagram to the correspon- ding terminals of terminal strip "X9". The connecting... -
Page 52: Unit Configuration
30...100%, factory setting: 100%). General settings ("Settings") With the DIP switches "Settings" you can set different unit parameters. The unit parameters are preset in the factory and may only be modified by the client after consulting the Condair representative. Switch Factory setting Description ON: low water conductivity <125 µS/cm... -
Page 53: Inspecting The Electrical Installation
5.6.6 Inspecting the electrical installation Check the following points: Do the supply voltages for heating and control voltage comply with the relevant voltages given in the wiring diagram? Is the correct Smart Card inserted? Are the voltage supplies (heating and control voltage) correctly fused? Are the electrical isolators "Q.."... -
Page 54: Operation
Operation Function of the display and operating elements Drain/Info key press key shortly: Opens and closes the drain valve (manual drain- – ing). Note: the drain valve is automatically closed after 10 minutes. press key for a extended period of time (>3 sec.): activating the –... -
Page 55: Commissioning
Note: If the Condair Sigma is operated with water of low conductivity it may happen that the maximum steam capacity is not reached in the first few hours of operation. This is normal. As soon as the con- ductivity has reached a sufficient level (due to the vaporisation process) the humidifier will reach the maximum steam capacity. -
Page 56: Notes On Operation
Notes on operation 6.3.1 Function of the LED's in info mode The info mode is activated by pressing the drain/info key for an extended period of time (> 3 seconds). After activating the info mode: – first, the green LED flashes. The number of flashes indicates the current steam output in % of the maximum steam capacity. -
Page 57: Inspections During Operation
6.3.3 Inspections during operation During operation the Condair Sigma and the humidification system have to be inspected weekly. On this occasion check the following: • the water and steam installation for any leakage. • the steam generator and the other system components for correct fixing and any damage. -
Page 58: Maintenance
You may get in touch with live parts when the unit is open. Touching live parts may cause severe injury or even lethal violation. Prevention: Before carrying out any maintenance work set the Condair Sigma out of operation as described in chapter 6.5... -
Page 59: Maintenance List
Maintenance list To maintain operational safety the Condair Sigma steam generator must be maintained at regular inter- vals. This is differentiated between the first maintenance after approx. 500 operating hours (I), steam cylinder replacement after the yellow LED lights (II) and annual maintenance (III). -
Page 60: Removing And Installing Parts For Maintenance
Removing and installing parts for maintenance 7.3.1 Removal and installation of the steam cylinder 1. Undo the two screws fixing the front panel to the unit using a screwdriver, then remove the front panel. 2. Release the hose clamp on the steam hose using a screwdriver, then detach the steam hose from the steam outlet connection of the steam cylinder. - Page 61 5. Carefully lift steam cylinder away from the cylinder receptacle, then remove it to the front. CAUTION! Put steam cylinder down carefully to avoid damage to the lower connection piece! 6. Carefully pull the drain screen out of the drain outlet of the steam cylinder. Note: this step must only be carried out if the drain screen is clogged (see chapter 8.2.2) and the...
- Page 62 Installation of the steam cylinder follows the reverse sequence. Observe the following: – Before installing the steam cylinder in the unit, check the O-ring of the cylinder receptacle for dam- age and replace if necessary. – Moisten the O-ring of the cylinder receptacle with water (do not use grease or oil), then insert steam cylinder into the receptacle and push it down to the stop.
-
Page 63: Removal And Installation Of The Drain Cup
7.3.2 Removal and installation of the drain cup 1. Release the hose clamp, then remove water drain hose from the connector on the water cup. 2. Undo the three screws fixing the drain cup to the unit using a screwdriver, then remove the drain cup downwards. -
Page 64: Removal And Installation Of The Water Cup And The Water Hoses
7.3.3 Removal and installation of the water cup and the water hoses For removing the water cup and the water hoses the steam cylinder must be removed first (see chapter 7.3.1). 1. Release hose clamps using pliers, then disconnect all hoses from the corresponding connectors and remove the hoses. -
Page 65: Removal And Installation Of The Drain Valve
7.3.4 Removal and installation of the drain valve For removing the drain valve the steam cylinder must be removed first (see chapter 7.3.1). 1. Detach electric cables (polarity of the cables must not be observed). 2. Release hose clamp and remove the hose from the connector. 3. -
Page 66: Removal And Installation Of The Inlet Valve
7.3.5 Removal and installation of the inlet valve For removing the inlet valve the steam cylinder must be removed first (see chapter 7.3.1). 1. Detach electric cables (polarity of the cables must not be observed). 2. Release hose clamp and remove the hose from the connector. 3. -
Page 67: Notes On Cleaning The Unit Components
Notes on cleaning the unit components Unit component What to clean and how to clean Water hoses • Loosen any limescale in the hoses by carefully twisting and flexing the hoses, then flsuh out the hoses thoroughly with hot water. Inlet valve •... -
Page 68: Notes On Cleaning Agents
Unit component What to clean and how to clean Drain screen of the steam cylinder • Carefully remove any limscale from the drain screen using a brush (do not use a wire brush) and remove loose limescale inside the drain connector of the steam cylinder. -
Page 69: Resetting The Maintenance Indication
Resetting the maintenance indication After completing maintenance work, the maintenance indication (yellow LED lights) must be reset as follows: • Press drain key with the unit switched off and hold down. • Switch on steam generator via the unit switch. •... -
Page 70: Fault Elimination
Fault elimination Important! Most operational malfunctions are not caused by faulty equipment but rather by improper installation or disregarding of planning guidelines. Therefore, a complete fault diagnosis always involves a thorough examination of the entire system. Often, the steam hose connection has not been properly executed, or the fault lies with the humidity control system. -
Page 71: Malfunction Lists
Smart Card is The installed Smart Card is not com- Install correct Smart Card. Let your incompatible patible with the hardware of the unit or Condair service technician adjust with the basic settings of the control the basic settings. electronics. –––... - Page 72 Warning Error Cause Remedy Code Malfunction Code Malfunction No electrode current No electrode cur- Phase failure heating voltage. Inspect/turn on electrical isolator of for more than 20 rent for more than the mains supply line. Inspect the minutes 4 hours fuses of the mains supply, replace if necessary.
-
Page 73: Notes On Fault Elimination
Malfunctions relating to the electrical installation (e.g. replacement of fuses) must be repaired by author- ized personnel or by your Condair representative’s service technician only. Repair work and the replacement of faulty components must be carried out by your Condair representa- tive’s service technician only! -
Page 74: Taking Out Of Service/Disposal
Taking out of service/Disposal Taking out of service If the Condair Sigma must be replaced or is not needed any more, proceed as follows: 1. Take the unit out of operation as described in chapter 6.5. 2. Have the unit (and all other system components, if necessary) unmounted by a qualified service technician. -
Page 75: Product Specifications
Product specifications 10.1 Technical data Steam capacity in kg/h Capacity range in kg/h 1...4 1...5 1.6...8 3...15 4,6...23 6,4...32 9...45 13...65 Nominal power in kW 11,3 17,3 24,0 33,8 48,8 Heating voltage 230V/1~/50..60Hz * Unit model Nominal current in A 13.5 16,3 26,1 Steam cylinder type **... -
Page 76: Unit Dimensions
10.2 Unit dimensions Unit dimensions Condair Sigma 4 (Dimensions in mm) ø30 G 3/4" Abb. 16: Geräteabmessungen Condair Sigma 4 Product specifications... - Page 77 Unit dimensions Condair Sigma 5-15 (Dimensions in mm) ø30 Abb. 17: Unit dimensions Condair Sigma 5-15 Product specifications...
- Page 78 Unit dimensions Condair Sigma 23-65 (Masse in mm) ø30 Abb. 18: Unit dimensions Condair Sigma 23-65 Product specifications...
- Page 80 CONSULTING, SALES AND SERVICE: CH94/0002.00 Condair Group AG Gwattstrasse 17, 8808 Pfäffikon SZ, Switzerland Phone +41 55 416 61 11, Fax +41 55 588 00 07 info@condair.com, www.condair-group.com...
