SYNERGIE
where inspiration flows
Installation Guide
Mono Basin Mixers
100
100E
This instruction booklet covers models:
SYN-100 & SYN-100E.
Vado
Wedmore Road, Cheddar, Somerset, England BS27 3EB
tel 01934 744466.
fax 01934 744345
aftersales @ vado.com
www.vado.com
Keep for future reference
Version 1, 1-9-17
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VADO SYNERGIE SYN-100
Summary of Contents for VADO SYNERGIE SYN-100
- Page 1 Installation Guide Mono Basin Mixers 100E This instruction booklet covers models: SYN-100 & SYN-100E. Vado Wedmore Road, Cheddar, Somerset, England BS27 3EB tel 01934 744466. fax 01934 744345 aftersales @ vado.com www.vado.com Keep for future reference Version 1, 1-9-17...
- Page 2 Important - please read Contents of Packaging Please read these instructions carefully before starting installation and keep for future reference. Remove all packaging and check the product for missing parts or damage before starting installation. Any alterations made to this product and fittings may infringe water regulations and will invalidate the guarantee.
- Page 3 Valve dimensions - 100 Valve dimensions - 100E 73mm 46mm 199mm 73mm 139mm 46mm 38mm 38mm G1/2 G1/2...
- Page 4 Installation - Quick guide Installation NOTE: For illustrative purposes only the 100 tap installation is shown. Please follow the same procedure to install the 100E tap. Before installing your new mixer, flush Max - 5 Bar Min - 1 Bar through the pipework to ensure removal of debris, turn off the water supply.
