- Page 1 PROGRAMMABLE ANALOG 10 BAND EQ PA-1QG/PA-1QB/PA-1QA Preset Data Dump & Load Procedures...
- Page 2 Do not connect the PA-1Q series unit to the MIDI interface at this step. For setting up information of the MIDI interface, please refer to its manual. NOTE: As we use a YAMAHA USB-MIDI interface UX16 for operation evaluations at Free The Tone, we recommend to use this model.
-
Page 3: For Macintosh
For Macintosh Preparation of MIDI software 1 ) Download the freeware “SysEx Librarian” from http://snoize.com/SysExLibrarian/ and save it in a folder. 2 ) Unzip the downloaded file and install the software. 3 ) Start the SysEx Librarian.The following screen appears. 4 ) Setting up the SysEx Librarian: From the pulldown menu in the main window, select the MIDI interface to be used. - Page 4 The interface list will not be shown if no MIDI interface is connected or the MIDI interface driver is not installed correctly. If the list is not shown, confirm whether the MIDI interface is connected correctly and the driver has been installed. The following screen appears when you select the interface to be used.
- Page 5 2 ) Click “Record Many” displayed in the SysEx Librarian screen. 3 ) Click “Record Many.” The following screen appears.
- Page 6 4 ) While holding down both the 【◀Cursor Key】 and 【SAVE】 switches on the PA-1Q series, turn on the power to it. 5 ) The 【 LEVEL】 display shows “ ” and flashes s nd 6 ) Press the 【PARAMETER】 encoder. 7 ) The 【PRESET】...
- Page 7 9 ) Select the received preset data. Select “Save As Sysex(.syx)” from the “File” menu of the SysEx Librarian to save the received preset. 10 ) Enter a name, select the storage location, and click “Save” to complete.
- Page 8 Loading the saved preset data to the PA-1Q series unit 1 ) Connect the MIDI interface’s “MIDI OUT” terminal to the PA-1Q series’s [MIDI IN] terminal. DC9V IN INPUT LEVEL MIDI IN MIDI OUT/THRU INST LINE 2 ) While holding down both the 【◀Cursor Key】 and 【SAVE】 switches on the PA-1Q series, turn on the power to it. 3 ) The 【LEVEL】...
- Page 9 7 ) Select the preset data to be written into the PA-1Q series and click “Open.” After selecting the file, the following message is displayed. Click “OK.”...
- Page 10 8 ) Select the preset data shown in the SysEx File list and click “Play” near the upper left corner of the screen. 9 ) The preset data is sent from the SysEx Librarian. The connected PA-1Q series unit’s 【PRESET】 display starts counting up from “00”...
-
Page 11: For Windows Pc
For Windows PC Preparation of MIDI software 1 ) From http://www.bome.com/products/sendsx, download the shareware “SendSx” which can be used for free for a limited period of time and save it in a folder. 2 ) Unzip the downloaded file and install the software. 3 ) Start the SendSx application. - Page 12 The following screen appears when you select the interface to be used. => Sending and saving the preset data from the PA-1Q series unit to your computer: refer to page 12. => Loading the saved preset data to the PA-1Q series unit: refer to page 15. Sending and saving the preset data from the PA-1Q series unit to your computer 1 ) Connect the MIDI interface’s “MIDI IN”...
- Page 13 5 ) The 【PRESET】 display starts counting up from “00” to “99” The “MIDI IN” field in SendSx counts up. NOTE: If the SendSx application opens upon receiving a preset and the MIDI interface is correctly selected, then you do not have to operate SendSx.
- Page 14 7 ) Select “Save MIDI In As...” from the “File” menu. 8 ) Enter a filename. Select the storage location and click “Save” to complete.
- Page 15 Loading the saved preset data to the PA-1Q series unit 1 ) Connect the MIDI interface’s “MIDI OUT” terminal to the PA-1Q series’s [MIDI IN] terminal. DC9V IN INPUT LEVEL MIDI IN MIDI OUT/THRU INST LINE 2 ) While holding down both the 【◀Cursor Key】 and 【SAVE】 switches on the PA-1Q series, turn on the power to it. 3 ) The 【LEVEL】...
- Page 16 7 ) From the folder, select the preset data to be written to the PA-1Q series and click “Open.” 8 ) The “MIDI Out” field indicates character strings. Click “ ” s nd 9 ) The preset data is sent from SendSX. The connected PA-1Q series unit’s 【PRESET】 display starts counting up from “00” to “99”...
