Facia C84, C88, C86, C87 and C89
Facias are used for flush mounting Axema's readers A66, A63, A61 and A04.
Axema Access Control AB | Box 90215 | 120 23 Stockholm, Sweden | 08-722 34 40 | info@axema.se | www.axema.se
Advertisement
Table of Contents
Related Manuals for Axema Facia C84
Summary of Contents for Axema Facia C84
- Page 1 Facia C84, C88, C86, C87 and C89 Facias are used for flush mounting Axema's readers A66, A63, A61 and A04. Axema Access Control AB | Box 90215 | 120 23 Stockholm, Sweden | 08-722 34 40 | info@axema.se | www.axema.se...
- Page 2 Facia Facia C84 and C88 fits the flush mount box C83 and BB3 Facia C86 and C87 fits the flush mount boc C85 and BB5 Facia C89 fits the flush mount box TPIM Facia C84, C88, C86, C87 and C89 If A04 or A05 is used.
- Page 3 If A04 or A05 is used. 1. Supply power the code lock 2. Mount the spacer with the "wing" towards the code lock.. 3. The code lock will automatically enter the programming mode. 4. Press A20, enter the desired six digit programming code twice followed by 5.
- Page 4 Mounting 1. If an existing flush mount box is not available, mount a new box in the wall. 2. Mount the spacer with the "wing" towards the code lock. and the support plate on the reader insert (the reader without frame and backing. Screw the insert to the facia using the thumb screws tight enough to hold them in place, but not harder.
