Configuration

Get Configuration
Purpose:
Show the current configured parameters.
Command:[all privileges]
GET CONFIGURATION
Interface Speed and Negotiation
Purpose:
Configure speed and negotiation mechanism for the NETWORK and SUBSCRIBER interfaces.
Command:[RW, SECURE privilege]
SET [NETWORK|SUBSCRIBER] INTERFACE SPEED 10|100|1000 [AUTO|FORCE]
Note: NETWORK or SUBSCRIBER is optional and is specified to identify a specific interface. If not
specified, both interfaces will be targeted. AUTO or FORCE is optional and indicates whether the
interface(s) should auto-negotiate up to the configured speed or if the interface should be forced to the
indicated speed. Negotiation defaults to AUTO if not specified.
Example 1: SET INTERFACE SPEED 100
Example 2: SET NETWORK INTERFACE SPEED 1000 FORCE
Status Commands: [all privileges]
GET CONFIGURATION
Configure Data Rate
Purpose:
Configure transmit and receive data rates relative to the SUBSCRIBER interface and independent of the link speed.
This mechanism provides a mechanism to limit the amount of bandwidth that the SUBSCRIBER can use.
Command:[RW, SECURE privilege]
SET [TRANSMIT|RECEIVE] DATA RATE FULL|<value>
TRANSMIT or RECEIVE is optional and is specified to identify a specific direction. If not specified, both directions
will be targeted. The data rate is specified in megabits by supplying a <value> number from 1 to 1000, or FULL to
allow the full rate of the interface.
Example: SET DATA RATE FULL
Example: SET TRANSMIT DATA RATE 15
Status Commands: [all privileges]
GET CONFIGURATION
