1.3.5 Inverter Box

Noise filter board（EC9）
L1A L2A L3A
L1B-2 L1B L2B
X91A
Note: Wiring diagram for the unit including inverter circuit is put on back side of the control box cover.
L1B
L2B
L3B
P1
P2
U
V
L3B
W
Inverter board（EC8）
X6A
1-8
AC reactor
Noise filter board （EC9）
Inverter board （EC8）
X801A
