Features; Control; Menu Display Instruction - Light4Me THUNDER BAR User Manual

Features

Voltage: AC100-240V 50/60Hz
Switching power supply: 12V/100W
Light source: 12* 3W 3535 warm white LED+ 156pcs 5730 led+ 96pcs 5050RGB LED;
operation modes: Automatic running, DMX512, Sound Active, Master/Slave
Sound controlled via built-in microphone
Beam angle: 6 degrees, radiation range: 8 degrees;
Dimming frequency: FLICKER FREE Up to 10KHz dimming refresh PWM frequency, camera shooting
without flicker.
0-100 linear dimmer, high power led and low power consumption
5CH/14CH /62CH DMX channels selectable
Packing Size:
Weight: 3.5kg

Control

Menu display Instruction

DMX address ADDR
Channel mode CHND
Master/Slave Mode
/d512
Sound mode SOUN
AUTO AUTO
COLOR COLO
Display inversion DISP
Software version Ver
DMX address (0-512)
5CH/ 14CH/62CH
Mast
Slave
Sound 0--sound 59
SENS 0--100
AUTO 0-59
Speed 0--9
color1--color15
inversion
V12
DMX512
ENGLISH
