M7 RA-101 Manual page 43

NO. PART NO. DESCRIPTION
1 --- Retaining Ring
2 --- Sleeve Ring
3 --- Ball Retainer
4 --- Steel Ball
5 --- Spring
6 --- Cap Bolt (4PCS)
7 --- Spring Washer (4PCS) 1 set
8 --- Hammer Housing
9 --- Anvil Bushing
10 RA-105P10 Washer
11 RA-105P11 Spacer
12 RA-105P12 Anvil
13 RA-105T13 Hammer Dowel (2PCS) 1 set
14 RA-105T14 Hammer (2PCS)
15 RA-105P15 Hammer Cage
16 RA-105P16 Hammer Cam
17 RA-105P17 Spacer
18 RA-105P18 Clamp Nut
19 RA-105P19 Rubber Gasket
20 RA-105P20 Ball Bearing
21 RA-105P21 Front End Plate
22 RA-105P22 Center Dowel
23 RA-105P23 Rotor
24 RA-105T24 Rotor Blade (6PCS)
25 --- Spring Pin
26 --- Cylinder
27 --- Positioning Pin
ltem No ： RA-105
Q'TY
NO. PART NO.
1
28 RA-105P28 Rear End Plate
1
29 RA-105P29 Ball Bearing
1 30 RA-195
1
31 ---
1
32 ---
1 set 33 ---
34 RA-105T34 O-Ring (2PCS)
1
35 ---
1 36 ---
1
37 ---
1
38 ---
1 39 ---
40 RA-105P40 Spring Pin
1 set
41 ---
1
42 ---
1
43 ---
1 44 ---
1
45 RA-105P45 Hanger
1
47 RA-105P47 Air Regulator
1
RA-105T01
1
RA-105T06 Fastener Assembly (06.07)
1
1
RA-105T08
1 set
RA-105T41 Throttle Lever Assembly (41.42) 1 set
1
RA-105T44 Air Inlet Bushing (43.44)
1
1
RA-105T46
RA-105T48
DESCRIPTION
Motor Housing
Valve Stem
O-Ring
Throttle Bushing
Steel Ball
Spring
O-Ring
Reverse Knob
Round Pin
Throttle Lever
Round Pin
O-Ring
Air Inlet Bushing
Cylinder Assembly
(25.26.27)
Hammer Housing Assembly
(08.09)
Throttle Valve Ass'y
(31.32.33.35.36.37.38.39)
Bit Sleeve Assembly
(01.02.03.04.05)
Q'TY
1
1
1
1
1
1
1 set
1
1
1
1
1
1
1
1
1
1
1
1
1 set
1 set
1 set
1 set
1 set
1 set
43
