M7 RA-101 Manual page 2

Ideal system connection:
Piping diameters and length requirement:
The diameter ΦA required for the inlet pipe
The diameter ΦB required for the branch pipe (from
ΦB = 2 x ΦA
The diameter ΦC required for the primary air supply (from
ΦA. ΦC = 3 x ΦA
The length for the inlet pipe
2
is recommended on the specification table.
should be less than 15 feet (4.5m).
to ) should be 2 times as large as ΦA.
to ) should be 3 times as large as
