Important Safeguards

(For your safety, please follow the instructions below.)
In this Instruction Manual, the following symbols are shown for safe and proper use
of your automatic faucet and in order to alert you to the possibility of personal injury
and damage to your property.
The symbols and their meanings are as follows.
Ignoring these symbols may cause
Warning
personal injury and/or property damage.
*Some models may have different components from the ones illustrated below.
Do not place the Automatic Faucet in a high humidity
area such as shower room or sauna.
This may cause damage.
Do not use in
humid area
Do not strike or kick the Automatic Faucet.
This may cause damage or water leakage.
Do not strike
Never attempt to disassemble, reassemble, repair
or modify the Automatic Faucet, unless you are an
electrician, or qualified service person.
Do not
This may cause property damage or personal injury.
disassemble
Do not use the Automatic Faucet at temperatures
what local codes allow.
Do not.
0GU3014ER
2007.03
Warning
AUTOMATIC FAUCET
Thermal mixing valve faucet

Specification

Item
RYOHAN™
Model
number
Helix™ Wall Mount
Duration of
water discharge
Power supply
Battery life
Detection range
from the sensor
Water supply
maximum water pressure:
pressure
check local building codes for maximum water
Water supply connection
Ambient temperature
Humidity
Flow rate
Discharge quantity
Max. 0.25 gallon per cycle (0.95 L/cycle)
EcoPower
type
TEL5GMY
TEL5GW#CP
60 seconds (TEL5
- 60)
-
-
5-1/8"~7-7/8" (130~200 mm)
sensor is self-adjusting
minimum required water pressure:
14.5 PSI (100 kPa) ( Flowing)
125 PSI (862 kPa)
pressure allowed
1/2" NPSM
o
o
32~104
F(0~40
C)
Max. 90% RH
0.8 gallon per minutes (3 L/min.)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Helix EcoPower TEL5GW CP Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Toto Helix EcoPower TEL5GW CP Series

  • Page 1 INSTALLATION MANUAL AUTOMATIC FAUCET Thermal mixing valve faucet Important Safeguards Specification (For your safety, please follow the instructions below.) In this Instruction Manual, the following symbols are shown for safe and proper use Item EcoPower type of your automatic faucet and in order to alert you to the possibility of personal injury and damage to your property.
  • Page 2 Set-up Drawing Before Installing Some models may have different components as illustrated below. 1. Check the pressure of cold and hot water supply Make sure the cold water supply pressure is higher or equal to the hot water Ryohan™ Battery type supply pressure.
  • Page 3 Installation *Some models may have different component as illustrated below. Control box Water inlet bracket Others EcoPower type ® Screw (φ3 mm×10) Allen wrench Installation Water inlet bracket (×2) Size:1/16"(2mm) Instruction manual manual *Spout , Flexible tube and Open-close tool are included. Self tapping screw (×8) (φ4.5 mm×38) RYOHAN™...
  • Page 4 Installation Procedure STEP STEP Fasten the spout with tool Remove the controller cover (Royhan™ only) STEP • Install the Drain controller cover Loosen the two screws on the front (Royhan™ only) cover. • • 8) Confirm with Set-up Remove the controller cover Pull Diagram and install the to the direction as shown in the figure.
  • Page 5 STEP STEP 6 Cut the spout connecting hose if necessary STEP Mount the two water inlet brackets on the wall STEP Note: Remove all protective covers. ●Cut the spout connecting hose to • Hexagonal nut the appropriate length. Connect the hot/cold water supply lines to the water inlet brackets. Washer Cutting length: ¤...
  • Page 6 STEP 7 STEP STEP 7 Attach the connector to the controller Install the spout (Helix™ Wall Mount) STEP 8 • Back-up battery ® <For EcoPower type> • connector (white) Make 3/4” diameter hole for water Framing Attach the back-up battery connector supply pipe and sensor cord.
  • Page 7 - STEP STEP Remove the drain cup unit Attach the controller cover STEP After checking the connectors are 1 . Pull the drain cup unit Pull Firmly securely attached, cover the controller. firmly to the drain part Drain cup Unit then release it.
  • Page 8 For safety and conservation reasons, after detecting objects continuously for about 10 seconds or 60 seconds, water automatically stops. Caution If the Automatic Faucet does not operate properly, contact TOTO or your ® ®...
