WELCOMECONSOLE USER GUIDE - ENGLISH
PACKING LIST
•
1 x WelcomeConsole phone
•
1 x handset
•
1 x handset cord
•
1 x RJ12 cord
•
1 x stand
SAFETY INFORMATION
https://www.wildix.com/safety-information/
MOUNTING INSTRUCTIONS
Attach the stand to the phone (desk mounting); for wall
mounting, use wall mount bracket (article can be purchased
separately, code: WP480-WM)
CONNECTION
The ports are situated on the rear panel of the phone
Connect the handset to the port using the handset
•
cord
Connect the phone to the network PoE switch using
•
RJ-45 cable
Connect a keypad extension module using RJ12
•
cord (up to 2 additional modules can be connected,
code: WelcomeConsole-EXT)
(Optional) Connect the port to the PC using
•
RJ-45 cable
(Optional, this is a PoE device) Connect the phone
•
to the power supply (power adapter can be
purchased separately)
(Optional) Connect the headset to the port (headsets
•
can be purchased separately)
(Optional) Connect the USB headset to the port
•
(headsets can be purchased separately)
PHONE OVERVIEW
Version 03/2019
LOGIN
1. Lift the receiver and dial 99
2. Enter your extension number
3. Enter the first five characters of your password
4. Press 1 when prompted
To enter your password from the phone's keypad: press
once an alphanumeric key corresponding to a letter which
you need to enter; press the star button (*) to enter any
special character.
Example: Password: 4Ag7$Zl@
Enter: 4247*
BLF / FUNCTION KEYS
Function keys must be set up in Collaboration Settings ->
Function keys or by the PBX administrator.
This phone supports up to 60 Function keys including
keypad extension. To use the keypad extension, add "Exp
module" Function key after having added 20 keys.
CALL FEATURES
Press Featur. Soft key from idle to set the following call
features for each call type (Internal, External, Blacklist,
Whitelist), based on user status (Available, DND, Away):
Call reject, Call forwarding, Call Waiting, Mobility, Ring
Tone.
Features can be also set up in Collaboration Settings ->
Features.
