Changing Shoulder Harness Strap Position

11
1
Fully Loosen
Harness Straps
Push down on
harness release
lever (through
opening in pad)
while pulling out on harness straps
as shown.
From Back of
2
Seat, Remove
Harness Straps
Loops From
Splitter Plate
3 Pull Harness
Straps Out of
Shoulder Harness
Slots
Rethread
4
Harness Straps
into Correct
Shoulder Harness
Slots For Your
Child
For Rear-Facing child fi t, see page
7.
For Forward-Facing child fi t, see
page 8.
5 Attach Harness
Strap Loops to
Splitter Plate
Sewn ends of the
sewn
harness strap loops
end
must face towards
you.
Do not twist harness straps or
harness adjustment strap. Make sure
the harness strap loops are fitted
completely on both sides of the
splitter plate.
Check your child's fit often.
If you cannot achieve a snug harness
fi t for your child, see pages 13-16.
To learn how to check harness
tightness, see pages 46-49.
Check the harness straps often for
any wear or damage.
Make sure the harness height is
correct for your child's size.
Harness system must be installed
correctly. Do not use a child restraint
with damaged harness straps.
Failure to follow these warnings can
result in serious injury or death.
