Summary of Contents for Cowon PLENUE R2
- Page 1 USER’S GUIDE ver. 1.0 EN...
- Page 2 THANK YOU FOR PURCHASING A PLENUE PRODUCT. We do our utmost to deliver DIGITAL PRIDE to our customers. This manual contains information on how to use the product and the precautions to take during use. If you familiarize yourself with this manual, you will have a more enjoyable digital experience. Product specification may change without notice.
- Page 3 General information as applied to this product, in compliance with USP4638258, 5510752 and 5736897. + COWON® and PLENUE® are registered trademarks of our company and/or its affiliates. + BBE and the BBE symbol are registered trademarks of BBE Sound, Inc.
-
Page 4: Table Of Contents
Contents Before you start! Using the Product Precautions Playback Screen Package Contents Music Selection Names of Parts and Functions Playback Settings Buttons Detailed Settings Basic Use Additional Product Specification Power Connection and Charging Connecting and Disconnecting from the PC Troubleshooting Inserting and Removing the microSD Card Using Headphone Mode Sound Source LED Indicator... -
Page 5: Before You Start
RESET button to stop operation and + If you are using a product that comes with an AC power adaptor, contact the place of purchase. please use the genuine charger offered by COWON. - Page 6 Before You Start! Precautions + If you find any abnormalities with the battery such as swelling, + Keep the player in cool and ventilated places, away from direct press the RESET button immediately to stop the operation and sunlight as it may cause deformation and damages to internal contact the place of purchase.
-
Page 7: Package Contents
Before You Start! Package Contents BODY (좌측면엔 특징 없음) ver. 1.0W Quick Guide ver. 1.3W PLENUE R2 USB Type-C Cable Warranty * Actual package contents may differ from the above images. -
Page 8: Names Of Parts And Functions
Before You Start! SIDE BUTTON Names of Parts and Functions PWR BUTTON BODY (좌측면엔 특징 없음) SIDE BUTTON Power Button BODY (좌측면엔 특징 없음) Volume Up(+) Volume Down(−) Play / Pause REW / Previous Track USB Type-C Port FF / Next Track Touch Display Earphone Jack / Optical Output Multi Button... -
Page 9: Buttons
Before You Start! PC CONNECT Buttons PC CONNECT CONNECT PWR BUTTON SIDE BUTTON PC CONNECT Previous Track / Next Track Power ON / OFF Press briefly to select the previous or next track. PWR BUTTON Press and hold the button to turn on the product. PWR BUTTON Rewind / Fast Forward SIDE BUTTON... - Page 10 Before You Start! Buttons - Volume Control Screen Adjust the 140-step volume control by swiping up or down on the volume control screen. Each level adjusts the volume by 0.5dB. If the Multi Button’s function is set to volume adjustment under system settings, you will be redirected to the volume control screen when touched.
-
Page 11: Basic Use
PWR BUTTON - PLENUE R2 can also be charged with an authentic USB DC adapter for smart phones. If 5V/2A or higher USB DC adapters are used, charging will be finished in approximately 3 hours. The charging time may vary if the product is in use while charging. -
Page 12: Connecting And Disconnecting From The Pc
PLENUE R2 is properly connected to the PC. - The following message may appear randomly, but it does not 5. Use PLENUE R2 to copy the track you wish to listen to. indicate that the product is malfunctioning. Please try again. -
Page 13: Inserting And Removing The Microsd Card
Sound Source LED Indicator 1. Properly place the microSD Card in the microSD card slot as The PLENUE R2's LED light changes color according to sound source. shown in the picture. Gently press the card to insert it. 2. When the database is automatically refreshed, the music files on the microSD card can be viewed. -
Page 14: Connecting To Balanced Audio Port
Basic Use Connecting to Balanced Audio Port PLENUE R2 has a high quality balanced line-out port that outputs + and - audio signals. 1. Connect balanced cable-supporting headphones (or a in-ear headphones) to the balanced line-out port (2.5mm). 2. Connect the receiver to the balanced audio port and check the icon status in the R−... -
Page 15: Using Bluetooth
Basic Use Using Bluetooth You can connect to a Bluetooth-supported device to listen to music. Bluetooth settings are located under ‘Settings ▶ Bluetooth’. 4. Select ▶ to edit the 1. Enable Bluetooth. 2. Search for device to be paired. 3. Select and connect to name of the connected device. - Page 16 ▶ ▶ - The call alarm function is only available when connected to a wired receiver. - If you answer a call on your smartphone, the Bluetooth connection between your phone and the PLENUE R2 will be terminated.
-
Page 17: Firmware Upgrade
The firmware uses built-in programs in the hardware and upgrades to improve product capabilities and fix bugs in the software. PLENUE R2 may use the firmware to adjust product performance or methods of use without prior notice, and minor malfunctions in the firmware may occur. -
Page 18: Using The Product
Using the Product Playback Screen ① Play / Pause the track. ② Press briefly to go to the previous track. Press and hold to rewind. ③ Press briefly to go to the next track. Press and hold to fast forward. ④... -
Page 19: Music Selection
Using the Product Music Selection Select a folder, artist, or album to view the corresponding track list. View track lists by folder. View track lists added to Favorites. View all tracks saved in the product. View track lists by artist. View track lists by album. -
Page 20: Playback Settings
⑬ Select the background image. Select the Elapsed+, you can hide the progress bar above the album art. * PLENUE R2 provides Gapless Playback to remove gaps between tracks during playback. Gapless Playback is applied in all situations without additional setup. -
Page 21: Detailed Settings
Using the Product Detailed Settings JetEffect 7 Settings 1. In Detailed Settings, select JetEffect 7. 2. Select User 1 / User 2 / User 3. EQ : Change the tone by 4. BBE+ : Select and apply 5. SE : Select and apply Chorus 3 / User 4 and set the user adjusting the level of each BBE sound effect. - Page 22 * Using JetEffect to play files of high quality, such as 24bit/192kHz, may slow the overall operation. * For detailed information about BBE, please see the introduction to BBE on our homepage(www.COWON.com). In "Settings ▶ Display ▶ User Presets", you can extend presets up to 16.
- Page 23 Load defaults : Reset all settings to the default. Bluetooth Format internal memory : Internal memory can be formatted by pressing and You can set the PLENUE R2's Bluetooth function. holding for 5 seconds. Formatting deletes all data in the internal memory, so please use when necessary.
-
Page 24: Additional
Additional Product Specification Model Name PLENUE R2 Product Capacity Built-in Memory : 128GB / External Memory : microSD SDXC Display 3.7”AMOLED Touch Display (480x800) Dimensions & Weight 61.5mm(W) x 112.9mm(H) x 13.9mm(D) / 154g Case Premium High-Strength Metal Body Buttons POWER, PLAY/PAUSE, VOL+, VOL- FF, REW, Multi Button ARM Cortex A9 1.2GHz Dual-Core... - Page 25 Additional Product Specification CS43131 X 2 (Dual DAC) 130dB Unbalance / 136dB Balance THD+N 0.0004% Unbalance / 0.0005% Balance (24bit, 48kHz) Stereo Crosstalk -128dB Unbalance / -148dB Balance Audio Output 2.0Vrms Unbalance / 4.0Vrms Balance Characteristics Output 0.6Ω Unbalance / 1.2Ω Balance Impedance Volume 140 Levels...
-
Page 26: Troubleshooting
COWON website(www.COWON.com) provides support for users of Each mode shows you a list of playable files only. To view all files that COWON products with FAQ (Frequently Asked Questions). Users are you have stored, select the Browser mode. Please note that System folder strongly encouraged to check out the website for further information will not appear in the Browser. - Page 27 www.PLENUE.com...
