User's Guide ver. 1.0EN
COWON Z2
Product specifications can be adjusted to improve performances without prior notice. And the images
in this manual can be slightly different from the product.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z2 Plenue and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cowon Z2 Plenue

Summary of Contents for Cowon Z2 Plenue

  • Page 1 User’s Guide ver. 1.0EN COWON Z2 Product specifications can be adjusted to improve performances without prior notice. And the images in this manual can be slightly different from the product.
  • Page 2 If you familiarize yourself with this manual, you will have a more enjoyable digital experience. Introduction to website + The address of the product-related website is http://www.COWON.com. + You can download the latest information on our products and the most recent firmware updates from our website.
  • Page 3 + COPYRIGHT NOTICE General + COWON is a registered trademark of COWON SYSTEMS, INC. + COWON SYSTEMS, INC. owns the copyright to this manual, and any unauthorized distribution of its contents, whether in part or in its entirety, is strictly prohibited.

  • Page 4: Table Of Contents

    + CONTENTS Before you start! Precautions Package Components Names of Parts and Functions Power Connection and Charging Connecting and Disconnecting the PC Firmware Upgrade Basic Use Buttons Main Screen Audio Videos Radio Recorder Settings HDMI Wireless Lan Additional Product specification Trouble Shooting...

  • Page 5: Before You Start

    The company will not be held responsible for any accident that may occur due to the failure to heed these precautions. The following information applies commonly to all products manufactured and produced by COWON SYSTEMS, INC. + Do not use this product for other purposes than those described in this manual.
  • Page 6 + If you find any abnormalities with the battery such as swelling, press the RESET button immediately to stop the operation and contact the place of purchase. + The price of the product may fluctuate due to unexpected commercial conditions. COWON SYSTEMS, Inc. accepts no liability to compensate for any price fluctuation.

  • Page 7: Package Components

    Before you start! + Package Components COWON Z2 Earphones Charger User Manual USB Cable HDMI Cable AV Cable (Composite, SPDIF)(Optional) * Actual package contents may differ from the above images.

  • Page 8: Names Of Parts And Functions

    Before you start! + Names of Parts and Functions Power / Hold Volume buttons Play / Stop button Fast Forward button Rewind button Menu button Home button Earphone Jack Micro USB / AC Adaptor Jack Speaker Reset Touchscreen...
  • Page 9 - When charging the device for the first time or the device has not been charged for an extended time, fully charge the battery before use. - COWON Z2 has a built-in Lithium Polymer battery. To prolong the life of the battery, it is recommended that you charge the device frequently, as opposed to fully discharging and then charging the device.

  • Page 10: Connecting And Disconnecting The Pc

    Before you start! + Connecting and Disconnecting from the PC 1. Use the USB cable to connect COWON Z2 to the PC. 2. Tap and drag the bar at the top. 3. Tap the item of USB connected(to Internal memory) and tap the mount.

  • Page 11: Firmware Upgrade

    2. Use the USB cable to connect COWON Z2 to the PC. 3. Unzip the downloaded firmware and copy it to the root folder of COWON Z2. * Before the file copying, tap the item of USB connected(to internal memory) and tap the mount to confirm connection, 4.

  • Page 12: Basic Use

    Basic Use + Buttons 1. Power on/off : Press and hold the Power / Hold button 2. Hold on/off : Briefly press the Power / Hold button while the device is turned on - The touchscreen is locked in hold status. - Locking the touchscreen with the hold button can prevent any unwanted operations usually caused by unintentional inputs.

  • Page 13: Main Screen

    Basic Use + Main Screen Play status Indicator Wireless Lan connection indicator Battery indicator Time...

  • Page 14: Audio

    Basic Use + Audio By tapping the menu key, the following settings can be used. PLAY / PAUSE Play/pause the music file. PREV Select the previous track or rewind. NEXT Select the next track or fast forward. Menu File List Folders Browse saved folders.

  • Page 15: Videos

    Basic Use + Videos PLAY Play/pause the video file. PAUSE PREV Select the previous video file or rewind. NEXT Select the next video file or fast forward. Repeat Select the repeat playback area while playing a video file. Playback Select the video playback speed. Speed Menu key File List...

  • Page 16: Radio

    Basic Use + Radio FM Radio supportive Search the receivable FM frequencies in your region and automatically register them in Preset. The channel is being tuned can be registered and deleted. The frequency bands can be changed by selecting countries,...

  • Page 17: Recorder

    Basic Use + Recorder RECORDER Start recording. PLAY Play recorded files. STOP Stop the currently playing or recording file. * Recorded files are automatically saved by touching stop button while recording.

  • Page 18: Hdmi

    Basic Use + Settings HDMI Select HDMI in the Output select of HDMI Sound & Display. * Although HDMI mode is set TV-Out is only possible with playing videos. Wireless LAN Go to the Wi-FI setting in the Wireless and Network and set AP. - Select AP from the list and touch ‘Connect’.

  • Page 19: Additional

    Additional + Product specifications Capacity 8GB / 16GB / 32GB (FAT32 file system) 1) Display 3.7 inch, AMOLED, WVGA(800X480) Size 64.7(W) x 116.6(H) x 11.9(T) mm Buttons Power/Hold, REW, Play/Pause, FF, VOL+, VOL - Battery Built-in rechargeable lithium polymer battery Power Playback Music up to XX hours playback / Videos up to X hours playback 2)

  • Page 20: Troubleshooting

    In order to display album image, the image has to be stored in the ID3 tag of the music file. You can edit the ID3 tags using COWON MediaCenter - JetAudio. A JPG image file with the same name as the relevant music file should be stored in the player.
  • Page 21 because some space of the memory should be used as the system area for normal operation. + The player does not play properly when memory is full. For the player to function properly, it requires enough space in the Flash memory for saving settings and other system files.
  • Page 22 The rechargeable batteries have limited number of charge cycles, and it will require a replacement as capacity to hold power will eventually diminish. The rechargeable batteries in COWON products should be replaced only by official COWON service centers. Please contact batteryreplace@cowon.com for more information on official COWON service centers.
