Furrion FMS5L2A-BL Owner's Manual

Model: FMS5L2A-BL / FMS5L2A-PS
FMS5L2-BL / FMS5L2-PS
IMPORTANT
For your safety, please read all
instructions in this manual carefully
before installation and use. Keep
this instruction manual for future
reference. This will ensure safe use
and reduce the risk of injury. If you
have any further questions regarding
our products, please contact us at
support@furrion.com
5" two-way Outdoor Marine Speaker
Owner's manual
Thank you for purchasing a Furrion® auto-
motive loudspeaker component system.
We've organized this manual to make your
installation as simple and trouble-free as
possible. Please read it thoroughly before
proceeding. Remember to keep your sales
receipt and this manual in a safe place so
both are available for future reference.
Installation
1. Select a suitable position that is not
susceptible to moisture.
2. Mark and cut an opening in the wall
according to the dimensions outlined in
the illustration below. (Fig. A)
Fig. A
3. Connect the speaker LED wire to a 12V
DC power supply and insulate the joints
with twist caps. (Fig. B)
Fig. B
4. Twist the speaker LED wires and LED
ring wires together and connect to a 12V
DC power supply (for FMS5L2A-BL/PS
only). (Fig. C)
"
Fig. C
