FP3700-T41 Installation Guide
• When connecting the FP3700-T41 (hereafter referred to as the "FP")'s power
cord terminals to the FP unit's Terminal Block, check first that the FP unit's
power supply is completely turned OFF, via a breaker, or similar unit.
• Whenever changing the backlight, to prevent electric shocks and burns, be
sure to unplug the FP unit's power cord and wear protective gloves.
• Do not open or remodel the FP unit, since it may lead to a fire or electric
shock.
• Do not use power beyond the FP unit's specified voltage range. Doing so
may cause a fire or an electric shock.
• Do not use the FP in an environment where flammable gases are present,
since operating the FP may cause an explosion.
• Do not use the FP as a warning device for critical alarms that can cause
serious operator injury, machine damage or production stoppage. Critical
alarm indicators and their control/activator units must be designed using
stand-alone hardware and/or mechanical interlocks.
• Do not use FP touch panel switches in life-related or important disaster
prevention situations. For safety related switches, such as an emergency
switch, be sure to use a separate mechanical switch.
• After the FP's backlight burns out, unlike the FP's "Standby Mode", the
touch panel is still active. If the operator fails to notice that the backlight is
burned out and touches the panel, a potentially dangerous machine miss-
operation can occur. Therefore, do not use FP touch switches for the con-
trol of any equipment safety mechanisms, such as Emergency Stop
switches, etc. that protect humans and equipment from injury and damage.
If your FP's backlight suddenly turns OFF, use the following steps to deter-
mine if the backlight is actually burned out.
1) If your currentFP application is not set to turn the backlight OFF, and the
screen has gone blank, your backlight is burned out.
2) If your current FP application is set to turn the backlight OFF, if touching
the screen does not cause the display to reappear, your backlight is burned
out.
• To prevent operator injury or machine damage, be sure to design your ma-
chine operation system so that the machine will not malfunction due to a
communication fault between the FP and its host controller.
• The FP is not appropriate for use with aircraft control devices, aerospace
equipment, central trunk data transmission (communication) devices, nuclear
power control devices, or medical life support equipment, due to these de-
vices' inherent requirements of extremely high levels of safety and reliabil-
ity.
• When using the FP with transportation vehicles (trains, cars and ships),
disaster and crime prevention devices, various types of safety equipment,
non-life support related medical devices, etc., redundant and/or failsafe sys-
tem designs should be used to ensure the proper degree of reliability and
safety.
WARNINGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro-face FP3700-T41 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Equipment Pro-face FP3700-T41

  • Page 1 FP3700-T41 Installation Guide WARNINGS • When connecting the FP3700-T41 (hereafter referred to as the "FP")'s power cord terminals to the FP unit's Terminal Block, check first that the FP unit's power supply is completely turned OFF, via a breaker, or similar unit. •...
  • Page 2: Ul/C-Ul (Csa) Application Notes

    To prevent this unit from malfunctioning: • Do not strike the FP touch panel with a hard or heavy object, or press on the touch panel with too much force, since it may damage the display. • Do not install the FP where the temperature will exceed the specified range. •...
  • Page 3: Package Contents

    Package Contents The following items are included in the FP unit's package. Before using the FP, please confirm that all items listed here are present. FP unit CD-ROM(1) (FP3700-T41) Contains the FP3700-T41 User Manual Installation Gasket (1) Installation Brackets (4/set, 2sets) FP3700-T41 Installation Guide (1) (this manual) AC Power Cord(1)
  • Page 4: Dip Switches

    Dimensions Unit:mm [in] 383[15.08] Top View 395[15.55] 5[0.2] 34.9[1.37] 60 [2.36] Side View Front View Dip Switches The dip switches are under the cover shown below. Rear view Dip-swiches After changing your FP unit's Dip Switch settings, please reboot your FP.
  • Page 5 SW1-8 Reserved (Set this switch to OFF) SW1-7 Reserved (Set this switch to OFF) SW1-6 Reserved (Set this switch to OFF) SW1-5 Switch between analog RGB and DVI-D input SW1-4 Reserved (Set this switch to OFF) SW1-3 Reserved (Set this switch to OFF) SW1-2 Display/hide the OSD SW1-1 Switch between USB and RS232C for touch panel data transmission.
  • Page 6 The number of dots (pixels) displayed are as follows: Screen Resolution H Sync. V Sync. Dot Clock Display Size Expansion (kHz) (Hz) (MHz) Resolution (H: Horizontal) (V: Vertical) 640×400 24.827 56.000 21.053 ×1.6 (H) 1024×767 640×400 31.469 70.000 25.175 ×1.92 (V) 640×480 31.469 59.992...
  • Page 7 DVI-D Interface Input signal type DVI-D Setting by OSD H-POS (On Screen Display) V-POS BACKLIGHT DEFAULT (ALL CLEAR) The number of dots (pixels) displayed are as follows: Screen Resolution H Sync. V Sync. Dot Clock Display Size Expansion (kHz) (Hz) (MHz) Resolution (H: Horizontal)
  • Page 8 Serial Interface Baud rate: 9600 bps Data length: 8 bits Serial Interface Parity: none Stop bit: 1 Pin Assignments and Signal Names for Serial Interface Signal Condition Pin Location Name Carrier Detect Receive Data (FP->Host) Send Data (FP<-Host) DT R Data T erminal Ready Ground Data Set Ready...
  • Page 9: Installation

    Installation Confirm the Installation Gasket's Positioning It is strongly recommended that you use the gasket. It absorbs vibration in addition to repelling water. Place the FP on a level surface with the display panel facing downward. Check that the FP’s installation gasket is seated securely into the gasket’s groove, which runs around the perimeter of the panel’s frame.
  • Page 10: Osd Settings

    • Tightening the screws with too much force can damage the FP unit's case. • The necessary torque is 0.5N•m. OSD settings You can operate the FP screen menus via the touch panel, and adjust screen image display to a minute level. The feature is called OSD (On Screen Dis- play).
  • Page 11 2) Connect the AC plug to the FP unit’s AC connector, as shown in fig. 2. AC Plug AC Connector Cord Clamp Lock Pin Hole Cord Clamp Lock Pin AC Plug Collar Lock Tab Release Figure 2 3) Insert the Cord Clamp Lock Pin into the FP unit’s Lock Pin Hole. 4) Adjust the Lock Pin’s Lock Tab length until it is securely held.
  • Page 12: Power Supply Cautions

    Power Supply Cautions Please pay special attention to the following instructions when connecting the power cord terminals to the FP unit. • If the power supply voltage exceeds the FP unit's specified range, connect a voltage transformer. • Between the line and the ground, be sure to use a low noise power supply. If there is still an excessive amount of noise, connect a noise reducing transformer.
