• Prior to connecting the FP2500-T12/FP2600-T12 (hereafter referred to as the "FP"or
FP unit) unit's power cord terminals to the Terminal Block, be sure to check that the
FP unit's power supply is completely turned OFF, via a breaker, or similar unit.
• Whenever changing the backlight be sure to unplug the FP unit's power cord and
wear protective gloves to prevent electric shocks and burns.
• Do not open or remodel the FP unit. Doing so may lead to a fire or electric shock.
• Do not use voltage levels that exceed the FP unit's specified voltage range. Doing so
may cause a fire or an electric shock.
• Do not use the FP in an environment where flammable gases are present, since
operating the FP may cause an explosion.
• Do not use the FP as a warning device for critical alarms that can cause serious
operator injury, machine damage or production stoppage. Critical alarm indicators
and their control/activator units must be designed using stand-alone hardware and/
or mechanical interlocks.
• Do not use FP unit touch panel switches in human-safety-related or important disas-
ter prevention situations. For safety-related switches, such as an emergency stop
switch, be sure to use a separately installed mechanical switch.
• After the FP unit's backlight burns out, unlike "Standby Mode", the unit's touch panel
is still active. If the operator fails to notice that the backlight is burned out and touches
the panel, a potentially dangerous machine operation error can occur. Therefore,
do not use FP unit touch-screen switches for the control of equipment safety mecha-
nisms, such as Emergency Stop switches, etc. that protect humans from injury and
equipment from damage.
If your FP unit's backlight suddenly turns OFF, use the following steps to determine
if the backlight is actually burned out.
1) If your currently running FP application is not set to turn the backlight OFF, and the
screen has gone blank, your backlight is burned out.
2) If your current FP application is set to turn the backlight OFF, if touching a corner of the
screen does not cause the display to reappear, your backlight is burned out.
• To prevent operator injury or machine damage, be sure to design your machine op-
eration system so that the machine will not malfunction due to a communication fault
between the FP unit and its host controller.
• Do not use the FP with aircraft control devices, aerospace equipment, central trunk
data transmission (communication) devices, nuclear power control devices, or medi-
cal life support equipment, due to these devices' inherent requirements of extremely
high levels of safety and reliability.
• When using the FP with transportation vehicles (trains, cars and ships), disaster and
crime prevention devices, various types of safety equipment, non-life support related
medical devices and others, be sure to use redundant and/or failsafe system designs
to ensure the appropriate degree of system reliability and safety.
FP2500-T12 / FP2600-T12
Installation Guide
WARNINGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Pro-face FP2500-T12 and is the answer not in the manual?

Questions and answers

Summary of Contents for Digital Equipment Pro-face FP2500-T12

  • Page 1 FP2500-T12 / FP2600-T12 Installation Guide WARNINGS • Prior to connecting the FP2500-T12/FP2600-T12 (hereafter referred to as the "FP"or FP unit) unit's power cord terminals to the Terminal Block, be sure to check that the FP unit's power supply is completely turned OFF, via a breaker, or similar unit. •...
  • Page 2: Package Contents

    To prevent this unit from malfunctioning: • Do not strike the FP unit's touch panel with a hard or heavy object, or press on the touch panel with too much force, since it may damage the display. • Do not install the FP where the temperature will exceed the specified range. •...
  • Page 3: About The Manual

    About The Manual The FP2500-T12/FP2600-T12 unit's PDF manual file (fp2000e.pdf) is contained in the CD- ROM's [Manual Eng] folder. ® Reading a PDF file requires installation of the Adobe Corporation's Acrobat Reader. ® Acrobat Reader Installation: ® To install the Acrobat Reader software, follow the steps given below.
  • Page 4 Dimensions FP2500-T12 Unit:mm [in] 301 [11.85] Top View 58 [2.28] 317 [12.48] 8 [0.31] Side View Front View FP2600-T12 301 [11.85] Top View 58 [2.28] 317 [12.48] 8 [0.31] Side View Front View...
  • Page 5: Dip Switches

    Dip Switches The FP unit's dip switches are located behind the Dip Switch Cover. After changing any dip switch settings, be sure to restart your FP unit. Factory SW No. Function Description Settings Used to set the touch panel data input (command Switch between USB control) method to either USB or RS-232C.
  • Page 6 The FP unit's available screen resolutions are as follows: (Unit: dot/pixel) <FP2500-T12> Screen Resolution H Sync. V Sync. Dot Clock Expansion Display Size (kHz) (Hz) (MHz) (H: Horizontal) Resolution (V: Vertical) 31.469 70.000 25.175 640 × 420 640×350 × 1.0 (H) 640×400 31.469 70.000...
  • Page 7: Dvi-D Interface

    Pin Assignments and Signal Names for Analog RGB Signal Name Condition Pin Location Analog R R signal input Analog G G signal input Analog B B signal input Reserved NC (spare for input) Digital grounding Digital signal GND Return R R signal GND Return G G signal GND...
  • Page 8 <FP2600-T12> Screen Resolution H Sync. V Sync. Dot Clock Expansion Display Size (kHz) (Hz) (MHz) (H: Horizontal) Resolution (V: Vertical) 640×400 31.469 70.000 25.175 × 1.25 (H) 800 × 600 × 1.5 (V) 640×400 24.827 56.420 21.053 800 × 600 640×480 31.469 59.992...
  • Page 9: Usb Interface

    RS-232C (Serial) Interface Pin Assignments and Signal Names Signal Condition Pin Location Name Carrier Detect *1 Receive Data (FP Host) → Send Data (FP Host) ← Data Terminal Ready *1 Ground Data Set Ready *1 Request to Send (FP Host) ←...
  • Page 10: Installation

    Installation Confirm the Installation Gasket's Positioning It is strongly recommended that you use the gasket, since it absorbs vibration in addition to repelling water. Place the FP on a level surface with the display panel facing downward. Check that the FP unit’s installation gasket is seated securely into the gasket’s groove, which runs around the perimeter of the panel’s frame.
  • Page 11 • Tightening the screws with too much force can damage the FP unit's case. • The necessary torque is 0.5N•m. • Depending on the installation panel's thickness, etc., the number of installation fasteners used may need to be increased provide the desired level of moisture resistance.
  • Page 12: Power Supply Cautions

    3. Unscrew the screws from the middle three (3) terminals, align the Ring Terminals and reattach the screws. 4. Replace the Power Input Terminal Block's clear plastic cover. • Confirm that the ring terminal wires are connected correctly. • The torque required to tighten these screws is 0.5 to 0.6 N•m. Power Supply Cautions Power Supply Cautions Please pay special attention to the following instructions when connecting the power...
  • Page 13: Screen Display Adjustment

    USB Cable Strap Removal 1) Push in the cable strap's stopper with a standard flat-blade screwdriver until the cable strap band unlocks, and remove the strap. 2) Disconnect the USB cable. • If the stopper will not move, press on <A> (shown in figure) to free the strap from the strap holder.
  • Page 14: Using The Osd

    Using the OSD Icons on the screen are used to operate the OSD. When you start up the OSD, the main menu appears. Touching the icon of the item you want to adjust displays its submenu or setting change screen. In the setting change screen, icons are used to change the setting.
  • Page 15 OSDH-POSITION Adjustment buttons Applies the setting and then returns to the main menu. Cancels the setting and then returns to the main menu. PHASE Adjustment buttons Applies the setting and then returns to the main menu. Cancels the setting and then returns to the main menu. BACKLIGHT Adjustment buttons Applies the setting and then returns to the main menu.
  • Page 16: Replacing The Backlight

    POLARITY LOCK If an analog RGB interface is used and the horizontal display position exceeds the normally adjustable range, setting the POLARITY LOCK feature to ON may allow you to adjust the display position. (Default: OFF <Disabled>) • This setting is enabled after the OSD is closed. Applies the setting and returns to the main menu.
