- Page 1 XO-324 FREQUENCY DIVIDER N Instruction manual...
- Page 2 We take this opportunity to thank you for buying this product. We recommend you read the instruction manual before switching on the machine and follow the instructions that are given. Keep the manual for future reference. SECURITY AND THE ENVIRONMENT ELECTRICAL SECURITY Check that the current in the mains connection where the machine is to be installed corresponds to the power supply of the machine.
- Page 3 The characteristics of the equipment and the content of the manual can change without forewarning. FONESTAR, S.A. does not assume responsibilities regarding the inappropriate use of the equipment or the information supplied in this instruction manual, and specifically disclaims any implied liability for marketability or fitness for any other use.
- Page 4 DESCRIPTION - 3-way stereo active crossover frequency divider with subwoofer. - Audio signal control with individual adjustment of the gains level of the filter in each way (bass, mid, treble and subwoofer), as well as the frequency cutoff of the subwoofer filter and the mid-bass and mid treble filters.
- Page 5 14.- LOW CUT 30 Hz: bass cutoff with a high pass filter 30 Hz cut off frequency and a slope of 12 dB/octave, it is used to minimize problems caused by subsonic signals, to avoid noise and buzzing and to prevent bass echoes in the loudspeakers.
- Page 6 CONNECTION Switch off all the equipment and disconnect it from the mains before making any connections. Connect the audio source to the frequency divider input (using the XLR input or the 6.3 mm stereo jack input), normally it will be the signal from a mixer. Adjust the filter parameters in accordance with the audio system characteristics.
-
Page 7: Specifications
SPECIFICATIONS XO-324 CHARACTERISTICS 3-way stereo active crossover frequency divider with subwoofer. INPUTS 2 balanced lines (channel L and R), XLR female and 6.3 mm jack 100 000 Ω CONTROLS Gain level of the bass, mid, treble and subwoofer filters Frequency cut-off for the mid-bass, mid-treble and subwoofer filters Cut-off filter in the bass of each channel and subwoofer. -
Page 8: Declaration Of Conformity
This product has been tested and has passed the corresponding quality control prior to being put on the market. FONESTAR guarantees the suitability of the product for its specified use during a period of 2 years from the delivery date and commits itself to repair or substitute the goods as expressed in the Spanish law ‘La Ley General para la Defensa de los...
