Wen 70730 Instruction Manual
  1. Manuals
  2. Brands
  3. Wen Manuals
  4. Saw
  5. 70730
  6. Instruction manual
Wen 70730 Instruction Manual

Wen 70730 Instruction Manual

10? dual speed sliding compound miter saw
Hide thumbs

Advertisement

Quick Links

LISTED
E493385
For replacement parts visit
WENPRODUCTS.COM
Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
SLIDING COMPOUND
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
10˝ DUAL SPEED
MITER SAW
(M-F 8AM-5PM CST)
Model # 70730
bit.ly/wenvideo

Advertisement

loading

Related Manuals for Wen 70730

Summary of Contents for Wen 70730

  • Page 1 WENPRODUCTS.COM IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Know your Miter Saw Assembly and Adjustments Operation Maintenance Exploded View & Parts List Warranty TECHNICAL DATA Model Number: 70730 120 V, 60 Hz, 15A Motor: Speed 1: 2000 RPM No-Load Speed: Speed 2: 4500 RPM Blade Model Number: 70730-002 10˝...

  • Page 3: Introduction

    INTRODUCTION Thanks for purchasing the WEN Miter Saw. This is an exciting moment. You have received your new tool, opened the box, and are now about to read through the instruction manual. This manual contains special messages to bring attention to potential safety concerns, as well as helpful assembly and operating information. Please read all the information carefully before the assembly and operation of your miter saw in order to help avoid injury to yourself and damage to the machine.

  • Page 4: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING! Read all safety warnings and all instructions. Failure to follow the warnings and instruc- tions may result in electric shock, fire and serious injury. To avoid mistakes and serious injury, do not plug in your tool until the following steps have been read and understood.
  • Page 5 GENERAL SAFETY RULES WARNING: Dust generated from certain materials can be hazardous to your health. Always operate the tool in a well-ventilated area and wear dust mask. Use dust collection systems when processing wood and plastics. Dust extractors or dust bags must not be connected when processing metals. POWER TOOL USE AND CARE 1.

  • Page 6: Specific Rules For The Miter Saw

    SPECIFIC RULES FOR THE MITER SAW WARNING: Be sure to read and understand all the specific rules for your miter saw before attempting to assemble or operate your miter saw. SAW BLADE SAFETY 1. Always wear protective gloves when handling saw blades. 2.
  • Page 7 SPECIFIC RULES FOR THE MITER SAW SECURE YOUR WORKPIECE 1. Always position the workpiece on the miter table and firmly against the fence. Never perform any operation freehand. 2. Use a clamp or other securing methods to support the workpiece whenever possible. 3.
  • Page 8 SPECIFIC RULES FOR THE MITER SAW (Continued) 2. The following metals are recommended for cutting: aluminum, mild steel, bronze alloy and copper alloy. It is not recommended to cut pure copper. DANGER: Do not cut magnesium or magnesium alloys. Serious accident and even death could occur. 3.

  • Page 9: Electrical Information

    ELECTRICAL INFORMATION FOR ALL DOUBLE-INSULATED TOOLS Double insulation is a concept in safety in electric power tools, which eliminates the need for the usual three-wire grounded power cord. All exposed metal parts are isolated from the internal metal motor components with protecting insulation. Double insulated tools do not need to be grounded. WARNING: The double insulated system is intended to protect the user from electric shock resulting from a break in the tool’s internal insulation.

  • Page 10: Unpacking And Transporting

    UNPACKING & TRANSPORTING UNPACKING THE MITER SAW Open the packaging and take out all loose parts from the box. Using the carrying handle and the slide rail, care- fully lift the saw from the packaging and place it on a level work surface. Make sure all the components are ac- counted for before discarding the packaging.

  • Page 11: Know Your Miter Saw

    KNOW YOUR MITER SAW Operating Handle Workpiece Support Table Blade Guard Lever Fixed Stop Rail Motor Movable Stop Rail Blade Guard Clamp Assembly Arbor Safety Guard Slide Bar Saw Blade Sliding Lock Knob Laser Dust Port Fence On/Off Switch Stationary Table Speed Adjustment Switch Miter Table Carrying Handle...

  • Page 12: Assembly And Adjustments

    ASSEMBLY AND ADJUSTMENTS Without plugging in your miter saw, read through and become familiarized with the following procedures of handling and adjusting your miter saw. Operating Handle Blade Guard Lever Slide Lock Knob Release Knob Deep groove Shallow groove Bevel Lock Bevel Scale 1.
  • Page 13 ASSEMBLY AND ADJUSTMENTS Clamp Knob Clamp Lock Screws Miter Lock Clamp Assembly Support Table Miter Stop Lever Miter Scale Table Lock Screws 4. TO ADJUST THE MITER ANGLE 5. TO INSTALL THE SUPPORT TABLE The rotary table can be adjusted from 0° to 45° to both left Attach the support tables by mounting them into the and right to create miter cuts.

  • Page 14: Bench Mounting

    ASSEMBLY AND ADJUSTMENTS WARNING: Remove the power plug before performing adjustments on the miter saw. Wear work gloves when handling saw blades to protect your hands from possible injuries. Fig. 1 SWITCH LOCK The hole on the trigger (Fig. 1) is a safety feature that enables the switch to be locked off.
  • Page 15 ASSEMBLY AND ADJUSTMENTS SETTING THE BLADE SQUARE WITH THE TABLE 1. Lower the saw arm to its lower position and lock the release knob. 2. Slide the saw arm to the back and tighten the sliding knob. 3. Set the miter table to 0° and tighten the miter lock. 4.
  • Page 16 ASSEMBLY AND ADJUSTMENTS WARNING: Remove the power plug before performing adjustments on the miter saw. Wear work gloves when handling saw blades to protect your hands from possible injuries. CHANGING THE SAW BLADE DANGER! Never try to use a blade larger than the stated capacity of the saw.
  • Page 17 ASSEMBLY AND ADJUSTMENTS 10. Reinstall the outer flange, washer and flange screw. Hold Blade rotate direction down the spindle lock (Fig. 10 - 1) and tighten the flange screw with the allen wrench. 11. Return the arbor safety guard back in place, and tighten it back onto the screw on the right.
  • Page 18 ASSEMBLY AND ADJUSTMENTS LIMITING THE CUTTING DEPTH The saw cutting depth can be adjusted using the depth adjust- ment screw located beside the laser switch. 1. Loosen the nut on the depth adjustment screw (Fig. 14 - 1). 2. Rotate the screw (Fig. 14 - 2) in or out to set the required cut- ting depth.

  • Page 19: Operation

    OPERATION WARNING: Be sure to read and understand all the specific rules for your miter saw before attempting to assemble or operate your miter saw. 1. RAISE THE SAW ARM Before operation, raise the saw arm from the lower position. Slightly press down the saw arm to pull out the release knob (Fig.
  • Page 20 OPERATION 3. SLIDING FUNCTION For materials width<4 inches (100 mm) When cutting materials with a width less that 4 inches, the sliding mechanism isn’t necessary. Loosen the slide lock knob (Fig. 16 - 1) and use the operating handle to push back the saw arm.

  • Page 21: Performing The Cut

    OPERATION WARNING: Before operating the miter saw, make sure to equip yourself with dust mask, ear protec- tion, safety glasses and work gloves for protection from possible injuries. Tie back long hair and do not wear loose clothing or jewelry. 7.

  • Page 22: Maintenance

    MAINTENANCE WARNING: Always ensure that the tool is switched off and the plug is removed from the outlet before making any adjustments or maintenance procedures. Any damage to this tool should be repaired and carefully inspected by qualified repair personnel before use. Have your power tool serviced by a qualified repair person using only identical replacement parts to maintain the safety of the power tool.

  • Page 23: Exploded View & Parts List

    EXPLODED VIEW & PARTS LIST...
  • Page 24 EXPLODED VIEW & PARTS LIST Part No. Part Description Qty. Part No. Part Description Qty. 70730-001 Outer Pressure Block 70730-055 Handle Seat 70730-002 216 Blade 70730-056 Pressure Block 70730-003 Inner Pressure Block 70730-057 Cable Shield 70730-004 Spindle 70730-058 Cable 70730-005...
  • Page 25 70730-224 ST2.9x9 Cross Recessed Pan head Tapping 70730-113 Wool Gasket Clamp Screws 70730-114 Bevel Locking Handle 70730-225 M5X30 Cross Recessed pan head Screw Kit 70730-115 Turnable Bevel Locking Spring 70730-226 M4X30 Cross Recessed Pan Head Tapping 70730-116 Turnable Oblique Screw Bolt...

  • Page 26: Warranty

    WARRANTY STATEMENT WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of two (2) years from date of purchase.
  • Page 27 THANKS FOR REMEMBERING...
