3
A
"CLICK"
3
A
8
Assembly
3A. Attach both of the Top Legs
to the Front Legs (curved bar),
as shown.
Make sure BOTH Top Legs are
securely attached and both pins
on either side of the Legs are
engaged.
3B. Check to make sure that the
legs are assembled correctly
with the clips on both of the Top
Legs facing in, as shown.
Assembly
4
FRONT LEGS
(curved bar)
4. Place the Youth Stool Base
onto the floor with the under-
side of the base facing up.
Position the Legs so that the
Front Legs (curved bar) are at
the front of the Youth Stool
Base.
Then Line up the Legs with the
grooves on the underside of the
Youth Stool Base and snap the
Legs into the Youth Stool Base.
The Legs cannot be removed
once installed. Make sure the
Legs are securely attached to
the Youth Stool Base by pulling
up on the Legs.
9
