PARTS LIST

Please see the parts list drawings for help with finding and identifying each part
along with corresponding part numbers.
RESISTORS:
Description
100Ω 1W
150Ω 5W
470Ω 1W
1.5kΩ 1/2W
5.6kΩ 1/2W
6.8kΩ 1/2W
10kΩ 1/2W
10kΩ 1W
100kΩ 1/2W
220kΩ 1/2W
220kΩ 1W
470kΩ 1/2W
1MΩ 1/2W
TERMINAL STRIPS:
Description
st
5 lug terminal strip (1
rd
5 lug terminal strip (3
st
7 lug terminal strip (1
nd
2 lug terminal strip (2
TRANSFORMERS:
Description
Power Transformer 269EX
Output Transformer P-T31
CAPACITORS:
Description
150pF 500V
250pF 500V
.022µF 400V
.047µF 400V
.1µF 400V
22µF 50V
47µF 350V
100µF 100V
Quantity
3
1
1
2
1
1
1
1
3
1
1
1
1
Quantity
lug common) 3
lug common) 1
th
& 7 lug common) 1
lug common) 1
Quantity
1
1
Quantity
1
1
1
2
1
2
3
1
HARDWARE:
Description
#8 self-tap screws
#6 screws
#6 hex nuts
#6 lock washers
#4 screws
#4 hex nut
3/8" lock washers
TUBES:
Description
12AX7/ECC803
6BQ5/EL84
MISCELLANEOUS PARTS:
Description
Solid state diode 1N4007
250kΩ audio push-pull pot
1MΩ audio push-pull pot
knobs
Input jack (switched)
output jack
9 pin miniature tube socket
preamp tube shield
EL84 tube retainer
Rubber Grommet (3/8" center)
Rubber Grommet (1/4" center)
red jewel
Power switch (3 pos. prog.)
1A fuse
Fuse holder
Light bulb
Lamp holder
Handle with mounting hardware
Rubber bumpers
Power cord
Steel chassis box and cover
Labels
Green 20 AWG wire
White 20 AWG wire
Black 22 AWG wire
4
Quantity
4
13
13
6
4
4
5
Quantity
1
1
Quantity
2
2
1
3
1
1
2
1
1
4
1
1
1
1
1
1
1
2
4
1
1/each
1 set
4 feet
6 feet
1 foot
