Bosch Rexroth AG, VT-VSPA2-1-2X/V0/T., RE 30110-B/11.2012

5.2.1

Block diagrams/pin assignments of the amplifier card

Fig. 1: Block diagrams/pin assignments of the amplifier card VT-VSPA../T1
