- Page 1 PDF provided by Conference Room AV ClearOne 910-001-013W Ceiling Microphone Array Kit - White...
- Page 2 Ceiling Microphone Array INSTALLATION MANUAL...
-
Page 4: Table Of Contents
Table of Contents INTRODUCTION ..................... 1 Product Overview ......................1 Device Application ......................1 INSTALLATION ...................... 2 Physical Characteristics ....................2 Microphone Array Dimensions (Excluding Cables and Mounting) .......2 Cables ..........................2 Pass-through Mounting Assembly ................3 Tools Required .......................3 Determining the Placement ...................3 Installing the Microphone Array ..................4 SOFTWARE SETUP OF THE CEILING MICROPHONE ARRAY ......7 Converge Pro Microphone Array Setup .................7 Interact Pro Microphone Array Setup ................9... -
Page 5: Introduction
Introduction PRODUCT OVERVIEW The ClearOne Ceiling Microphone Array enhances any conferencing application which demands high-quality audio. The Ceiling Microphone Array is easily installed and combines affordability with exceptional audio quality. The Ceiling Microphone Array features three microphones that are mounted together into a single unit array, providing the rich sound of three individual unidirectional microphones while maintaining full 360 degree coverage. -
Page 6: Installation
Installation PHYSICAL CHARACTERISTICS Microphone Array Dimensions (Excluding Cables and Mounting) Length: 3.3 in (8.38 cm) Diameter: 1.5 in (3.81 cm) CABLES Two cables and a mixer adapter are used for connecting from the microphone array through the pass-through Mounting Assembly to the mixer. • One 4-pin mini-XLR cable is used for connecting the microphone array to the pass-through Mounting Assembly. -
Page 7: Pass-Through Mounting Assembly
PASS-THROUGH MOUNTING ASSEMBLY This assembly includes a threaded body with integrated mini-XLR and RJ45 connectors, and the required washers and nuts for fastening in a suspended ceiling tile. Microphone Array End Cable to Mixer End Includes 4-pin Mini-XLR Connector Includes Female RJ45 Connector TOOLS REQUIRED You will need a drill and a 1-inch hole saw bit to install the mounting adapter, and an adjust- able wrench to tighten the adapter fittings. -
Page 8: Installing The Microphone Array
INSTALLING THE MICROPHONE ARRAY 1. Drop the ceiling tile where you have selected to install the microphone array. 2. Run the 25-ft RJ45 cable from the mixer location into the space above the suspended ceiling and down through the opening of the removed tile to conceal the cable. 3. - Page 9 Above Ceiling Tile Surface Below Ceiling Tile Surface 5. Plug the RJ45 cable into the top end of Mounting Assembly, then lift the ceiling tile back into place. 6. Make sure the mini-XLR cable is fed through the grommet. Connect the mini-XLR connector into the receiving plug at the bottom of the Mounting Assembly, then slide the Grommet over the cable and connector snugging it over the Mounting Assembly against the ceiling tile.
- Page 10 7. Attach the Microphone Array to the hanging end of the mini-XLR cable. 8. Connect the RJ45 Male to Mixer adapter cable for your mixer: The Converge Pro requires the RJ45 to mini-Phoenix adapter cable. The RJ45 to XLR-M adapter is for the Interact Pro and Interact AT mixers.
-
Page 11: Software Setup Of The Ceiling Microphone Array
Software Setup of the Ceiling Microphone Array The Ceiling Microphone Array can be used with the ClearOne Converge Pro, Interact Pro, and Interact AT audio conferencing mixers. Each Ceiling Microphone Array requires 3 microphone inputs. Attention Installers: You must apply the software setup and filter settings in the audio conferencing mixer to obtain the best performance from the ClearOne Ceiling Microphone Array. - Page 12 6. Click on the Filter Tab. 7. Add 3 filters Filter 1 is a PEQ filter with the center frequency at 100 Hz with a gain of 5 dB and a Q of 0.40 Filter 2 is a PEQ filter with the center frequency at 4000 Hz with a gain of -2 dB and a Q of 0.27 Filter 3 is a Low Pass filter set at 12000 Hz 8.
-
Page 13: Interact Pro Microphone Array Setup
INTERACT PRO MICROPHONE ARRAY SETUP 1. With the Interact software connect to the Interact Pro. 2. In the Interact Software go to the Mic Settings screen 3. Verify P Pwr (Phantom Power) is turned on. The Ceiling Microphone Array requires phan- tom power for operation. - Page 14 9. Other settings in the Microphone Settings screen can be set or adjusted based on your application. 10. Repeat the filter setup for the other 2 Ceiling Microphone Array inputs. INSTALLATION MANUAL...
-
Page 15: Interact At Microphone Array Setup
INTERACT AT MICROPHONE ARRAY SETUP 1. With the Interact software connect to the Interact AT. 2. In the Interact Software go to the Mic Settings screen 3. Verify P Pwr (Phantom Power) is turned on. The Ceiling Microphone Array requires phan- tom power for operation. - Page 16 9. Other settings in the Microphone Settings screen can be set or adjusted based on your application. 10. Repeat the filter setup for the other 2 Ceiling Microphone Array inputs. INSTALLATION MANUAL...
-
Page 17: Compliance
Compliance COMPLIANCE OVERVIEW ROHS COMPLIANCE All components and processes used to produce the Ceiling Microphone Array will comply with the RoHS initiative. SUSTAINABILITY The Ceiling Microphone Array is compliant with the WEEE recycling initiative. It is made from easily recyclable materials such as aluminum and steel. ELECTRICAL SAFETY ADVISORY This equipment uses DC power supplied from an external source which can be subjected to electrical surges, typically lightning transients which are very destructive to customer terminal... -
Page 18: Service And Support
1.800.705.2103 E-mail: techsales@ClearOne.com Product Returns All product returns require a Return Material Authorization (RMA) number. Contact ClearOne Technical Support before returning your product. Make sure you return all the items and packing materials that originally shipped with your product. CLEARONE LOCATIONS... - Page 19 Ceiling Microphone Array Installation Manual ClearOne Document 800-001-013 - Jan. 9, 2012 (Rev. 1.3) © 2012 ClearOne All rights reserved. No part of this document may be reproduced in any form or by any means without written permission from ClearOne. ClearOne reserves specific privileges.
- Page 21 ClearOne 5225 Wiley Post Way Suite 500 Salt Lake City, UT 84116 Telephone 1.800.283.5936 1.801.974.3760 1.801.974.3669 E-mail tech.support@clearone.com On the Web www.clearone.com...
