SERVICE PARTS
7505T-B4
1048075
1166882
84100
1115287
1036389
1104495
29296
1153137**
1217943
101131
1046153
**Color code must be specified when ordering
1230970-2A-D
Single Hole Kitchen Faucet
1148476**
1016503
1130269
1066106
1099016**
1232536
22352
1128531
1151299
1150881
58946
1229445
880096
PURIST
Installation INSTRUCTIONS
BEFORE YOU BEGIN
All information is based on the latest product information available at the time of publication. Kohler Co. reserves
the right to make changes in product characteristics, packaging, or availability at any time without notice.
Please leave these instructions for the consumer. They contain important information.
NOTES:
1. Flush the water supply pipes thoroughly to remove debris.
2. For new installations, assemble the faucet to sink before installing.
3. The highest working pressure for handspray & shower head is 0.5MPa(5bar). If it exceeds 0.5MPa(5bar), a
pressure reducer is needed. The highest water and environment temperature is 60ºC. Please keep handspray,
shower head and the shower arm away from heater, or it may become damaged and cause injury to the user.
HANDLE OPERATION
Open the handle gently. Turn clockwise for cold water, counter-clockwise for hot water.
ROUGH-IN DIMENSIONS
1243258**
833438
834705**
4
1230970-2A-D
7505T-B4
Single Hole Kitchen Faucet
93
1700
G1/2˝
PURIST
203
Ø33~Ø42
616
1
