FWB multiBALL Setup Manual page 9

Step 6
Connect sensor cables
!
The plugs are equipped with a guide to ensure correct
connection. Make sure to gently find the guide before
pushing the plugs together and screwing them tight!
Multiball setup and connection plan
SX LS1
TXZS1
SY
LS4
TXZS3
LS5
TXES2
LR1
RXZS1
RX
RX RY
SX SY
Lvx X MB X Lvx Y MB Y
CAN/RS232
COM 1 HDMI HDMI HDMI
Computer
LAN
B.1-B.8 h
LS2 LS3
TXZS2 TXES1
TOP
LR2 LR3
RXZS2 RXES1
Calibration of the light grid:
Before the first power on after mounting the light bars to their final position put switch 3
(the array of tiny switches) up on both of the LVX-devices. Then Power on the System and
SEA
check that the green LED below the orange LED is lit. When interrupting a beam the green
light should go off. Check for both Axis X and Y. Then put down the switch 3 (to off). Now
EMA
the light grid is ready to use
Power
Power
Connect the light bars with each other. The open and labeled
plugs have to be connected to the sensor cables.
Use connection diagram!
Put all the cables into the Base Profiles. Any spare cable can
Projector
be arranged in the top Base Profile. To prevent the cables
from falling back out, bend the square flaps with a screw
driver to hold the cables in place.
RY
LR4
RXZS3
LR5
RXES2
