FWB multiBALL Setup Manual page 6

Step 3
Mount the Light bars
Description
MB Lightbar Top Left
MB Lightbar Top Centre
MB Lightbar Top Right
MB Lightbar Leftside Up
MB Lightbar Leftside Down
MB Lightbar Bottom Left
MB Lightbar Bottom Centre
MB Lightbar Bottom Right
MB Lightbar Rightside Up
MB Lightbar Rightside Down
Red surface of the bars facing towards the inside!
Cables towards the outside of the frame
Do not over-tighten the bolts!
LS4
Red
Cables
Surface
LS5
Sticker
LS1
LS2
LS3
LS4
LS5
LR1
LR2
LR3
LR4
LR5
LS3
LS2
LS1
LR1
LR2
LR3
Use small black bolts provided, using additional bolt
adhesive is recommended
LR4
LR5
