Summary of Contents for FWB multiBALL
- Page 1 Setup Guide Fun With Balls GmbH...
- Page 2 What’s inside the box Speaker Box with Processing Unit Frame (x10) Light Bar (x10) Cover (x10) Sensor Cable (x4) Light Bar Bolt M2 (x40) Cover Bolt M6 (x40)
-
Page 3: Recommended Equipment
Recommended Equipment Rolling Scaffolding Spirit Level (Impact) Drill Allen® Key Set... - Page 4 Step 1 Arrange the Frames Description Sticker MB Frame Top Left MB Frame Top Middle MB Frame Top Right MB Frame Rightside Up MB Frame Rightside Down MB Frame Bottom Right MB Frame Bottom Middle MB Frame Bottom Left MB Frame Leftside Down MB Frame Leftside Up FR10...
- Page 5 Step 2 Mount Frames Max. 5cm Mount profiles to the wall 1 bottom - fix all screws and we advice to keep the distance of about 5cm only or less from the floor for the ease of handling. 2 sides - only fix the top screw for each profile to hold it in place 3 top - try if the distance to the sides is correct and the top fits...
- Page 6 Step 3 Mount the Light bars Cables Surface Description Sticker MB Lightbar Top Left MB Lightbar Top Centre MB Lightbar Top Right MB Lightbar Leftside Up MB Lightbar Leftside Down MB Lightbar Bottom Left MB Lightbar Bottom Centre MB Lightbar Bottom Right MB Lightbar Rightside Up MB Lightbar Rightside Down Red surface of the bars facing towards the inside!
- Page 7 Step 4 Open multiBALL Console Carefully lift up the cover and make sure you disconnect the Remove the 8 small bolts holding the cover. speaker cables!
- Page 8 Step 5 Mount multiBALL Console ca. 5cm Use this step to connect the LAN, HDMI and Power Cables.
- Page 9 Step 6 Connect sensor cables Multiball setup and connection plan B.1-B.8 h TXZS1 TXZS2 TXES1 TXZS3 RXZS3 RXES2 TXES2 RXZS1 RXZS2 RXES1 Calibration of the light grid: Before the first power on after mounting the light bars to their final position put switch 3 (the array of tiny switches) up on both of the LVX-devices.
- Page 10 Step 7 Calibrate LVX 1. Power ON Computer 2. Power OFF the LVX’s (disconnect plug) 3. Flip switch #3 on both LVX with a small screw driver 4. Power ON the LVX´s (re-connect plug) 5. Check if both green and orange lights on the LVX´s are ON. 6.
- Page 11 Step 8 Mount Covers CV10 Description Sticker MB Cover Top Left MB Cover Top Centre MB Cover Top Right MB Cover Rightside Up MB Cover Rightside Down MB Cover Bottom Right MB Cover Bottom Centre MB Cover Bottom Left MB Cover Leftside Down MB Cover Lefttside Up CV10 Carefully slide on the covers and avoid pinching or bending...
- Page 12 To get a picture, always make sure you power on the align the picture so it perfectly fits into the frame. projector first and then the multiBALL system. If the game does not fit in the visible picture, get in touch Now its time to test the system for the first time.
- Page 13 Step 10 : Final Mount multiBALL Console cover Use this step to adjust the volume of the amplifier. The volume can also be adjusted in the menu so try to find the Don´t forget to re-connect the speaker cables best level suitable for you.
-
Page 14: Maintenance
Maintenance Vacuum Light Bars once a week (with covers on) Use this step to adjust the volume of the amplifier. The volume can also be adjusted in the menu so try to find the Don´t forget to re-connect the speaker cables best level suitable for you. - Page 15 Thank you! FWB Team...
