Operating instructions
WB-200 thermal imaging camera
Item No. 1897504

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WB-200 and is the answer not in the manual?

Questions and answers

Related Manuals for VOLTCRAFT WB-200

Summary of Contents for VOLTCRAFT WB-200

  • Page 1 Operating instructions WB-200 thermal imaging camera Item No. 1897504...

  • Page 2: Table Of Contents

    Table of contents Page Introduction ................................3 Explanation of symbols ............................3 Intended use ................................4 Delivery content ..............................4 Safety instructions ...............................5 Notes on rechargeable batteries ..........................6 a) General information ............................6 b) Additional information on lithium rechargeable batteries ................6 Operating elements .............................7 Product description ..............................8 Inserting and charging the battery ........................8 10.

  • Page 3: Introduction

    Voltcraft offers you reliable technology at an extraordinarily favourable cost-performance ® ratio. We are confident that starting with Voltcraft will be the beginning of a long, successful relationship. We hope ® you enjoy your new Voltcraft product! ®...

  • Page 4: Intended Use

    3. Intended use The WB-200 thermal imaging camera enables non-contact infrared temperature measurement from -10 to +400 °C with imaging temperature display. The IR sensor (bolometer matrix) has a resolution of 80 x 60 pixels and enables simultane- ous measurement of 4800 temperature points. The temperature points are shown in a false colour thermal image on the display.

  • Page 5: Safety Instructions

    5. Safety instructions These instructions contain important information on how to use the thermal imaging camera cor- rectly. Please read them carefully before using the thermal imaging camera for the first time. Damage caused due to failure to observe these instructions will void the warranty. We shall not be liable for any consequential damage.

  • Page 6: Notes On Rechargeable Batteries

    6. Notes on rechargeable batteries Make sure that you have read and understood the following information and safety instructions before handling rechargeable batteries. a) General information • Do not leave rechargeable batteries lying around unattended. Children or pets may swallow them. If rechargeable batteries have been swallowed, seek medical attention immediately! •...

  • Page 7: Operating Elements

    • The rechargeable battery should be removed from the product if it is not used for a long period of time to avoid damage through leaking. Leaking or damaged batteries may cause acid burns when they come into contact with skin. Therefore, use suitable protective gloves to handle damaged batteries. •...

  • Page 8: Product Description

    8. Product description The thermal imaging camera has a graphic TFT colour display. This display can be used for all necessary displays and to implement all settings. The main menu, which can be called up via a multi-function button, allows you to set the operating parameters. The arrow buttons allow easy navigation in the menu.

  • Page 9: Inserting And Removing The Memory Card

    • To turn the camera on, press and hold down the red on/off button on the keypad below the display for approx. two seconds. • The camera will turn on and display the “VOLTCRAFT” start screen for approx. four seconds. The image sensor will be calibrated at the same time. This is indicated by a quiet clicking sound.

  • Page 10: B) Control Keypad

    b) Control keypad Different buttons are used to control and set the measuring instrument. The buttons have the following functions: On/off button (3) To turn the device on or off, press and hold down the button for approx. two seconds. Automatic power-off can be set in the menu.

  • Page 11: C) Display Elements And Symbols

    c) Display elements and symbols The following symbols and information are shown on the display. 1 “G” symbol for “Gain” for setting the temperature ranges High Gain: Small temperature range, high detail resolution Low Gain: Large temperature range, low detail resolution 2 “Crosshairs”...

  • Page 12: D) System Settings

    d) System settings The measuring instrument allows the system data relevant to the user to be set via a menu. Such data includes the menu language, units of measurement, time and date, etc. These system settings must be made in advance so measurements can be stored with a time stamp, etc. •...
  • Page 13 Setting the menu language • On initial operation, set the menu language to your national language. • Turn on the measuring instrument and press the SET button. • Use the cursor buttons to select the gear symbol and press the “SET” button to confirm the selection. •...
  • Page 14 -10 to +400 °C Warning on Warning off -10 to +400 °C Warning on Warning off About Model: WB-200 Capacity: xxxx Available: xxxx Version: xxx Product ID: XXXXXXXXX Recovery Format SD The duration of the formatting process depends on the memory card size. “Formatting...” will be displayed during formatting.

  • Page 15: E) Setting The Measurement Range

    e) Setting the measurement range Set the measurement range to expand the scope of application of the camera. There are two ranges: High Gain The camera reduces the measurement range to the most commonly used temperature range and thus increases the detail display. This range is used to display precise temperature differences.

  • Page 16: F) Setting The Temperature Markers

    f) Setting the temperature markers By default, the spot temperature for the thermal image is displayed on the up- per left corner of the screen. You can use various settings to mark the actual measuring point. The middle measuring point can be displayed, in which the temperature measurement takes place.

  • Page 17: G) Setting The Colour Palette

    g) Setting the colour palette Set the colour palette to choose the optimal display contrast for your measure- ment application. There are three colour palettes. Iron palette Typical colour palette for thermal image applications. The cool spots are dis- played dark and turn from red to white for the hot spots. Rainbow palette The cool spots are displayed dark and turn from bright colours to white for the hot spots in rainbow mode.

  • Page 18: H) Image Gallery

    h) Image gallery The saved images can be viewed directly on the camera. In addition, the thermal image parameters can be displayed and unnecessary images can be deleted directly. To view/delete the saved images, proceed as follows: • Press the “SET” button to open the settings menu. •...

  • Page 19: Taking Measurements

    12. Taking measurements In order to obtain precise measured values, the measuring instrument must be adjusted to the ambient temperature. Allow the device to adjust to the ambient temperature after relocation. Lengthy IR measurements of high temperatures at a small measuring distance cause self-heating of the measuring instrument and thus an inaccurate measurement.

  • Page 20: C) Saving The Screen Content

    c) Saving the screen content IR thermal images or screenshots of measured values can be stored on the removable microSD memory card. The images are saved in bitmap format (.bmp) and can be reused by all graphics and table editing programs. This allows for logging of measurement series.

  • Page 21: Cleaning And Maintenance

    13. Cleaning and maintenance a) General information To ensure the accuracy of the thermal imaging camera over a long period of time, it should be calibrated at least once a year. The measuring instrument is absolutely maintenance-free except for occasional cleaning and battery replacement. Regularly check the device for technical safety, for example, for damage to the casing or deformation, etc.

  • Page 22: Disposal

    14. Disposal Electronic products are raw material and do not belong in the household waste. At the end of its service life, dispose of the product according to the relevant statutory regulations. Remove the inserted battery cell and dispose of it separately from the product. Disposal of used batteries/rechargeable batteries! You are required by law to return all used batteries.

  • Page 23: Technical Data

    16. Technical data Measuring tolerances These accuracy readings are valid for one year at a temperature of +23 °C (± 5 °C) and a relative humidity of less than 75%, non-condensing. The accuracy of measurements may be affected when the device is used in a high-frequency electromagnetic field. Measurement range .........-10 to +400 °C Accuracy ............±...
  • Page 24 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.

This manual is also suitable for:
