- Page 1 MODEL:NF-168 Your excellent helper in cable test! INSTRUCTION MANUAL INSTRUCTION MANUAL INSTRUCTION MANUAL INSTRUCTION MANUAL RJ45/RJ11/BNC WIRE TRACKER ORIGINAL ORIGINAL AUTHENTIC AUTHENTIC REV1.0...
- Page 2 Hunt cable at the other end Connect launcher and telephone wire port to be hunted in right way with receiver Connect launcher and LAN cable Hunt cable at the other end port to be hunted in right way with receiver Your excellent helper in cable test!
- Page 3 Please read and learn safety instructions before use or maintain the equipment Please store the test in right place and operate in correct way in case of the sharp probe hurts. Never expose the equipment directly in the sun. Never put the equipment in the place with much dust, humidity and high temperature (over 40 Please use battery according to the specification;...
-
Page 4: Table Of Contents
Contents Brief Introduction ............01 Overview ................01 Product features ..............02 Product interface and keypad functions ..03 Accessories ............Operation methods ...........05 Usage of transmitter ............05 Usage of receiver ............05 Hunting test ............Network line ..............06 Telephone line ..............06 Monitoring line ..............07 Metal line ................07 Wire sorting ............ -
Page 5: Brief Introduction
Brief Introduction The service manual for user here covers all products of NF-168 (all instructions are suitable for all products as shown in figure below unless there is another regulation): NF-168 POWER NF-168 SCAN STATUS SCAN TEST VERIFY Emitter Receiver Overview NF-168 is an updated item after NF-801. -
Page 6: Product Features
Product features: Tracing network line (4 cores) directly when connected with switch or router. (NF-801 don't). The wire can be hunted directly in connection with Ethernet switch/ router /PC terminal of different models in startup. the wire can also be hunted directly such as 5E, 6E, telephone line, coaxial cable and other cables. -
Page 7: Product Interface And Keypad Functions
Product Interface and Keypad Introduction RJ45 RJ11 Scan indicator NF-168 STATUS DIP switch Probe SCAN LED indicator TEST VERIFY Signal indicator wire sorting indicator toggle button LED indicator NF-168 POWER Function switch SCAN Emitter Volume Spotlight switch Earphone Receiver Your excellent helper in cable test! -
Page 8: Accessories
Accessories RJ11 cable Crocodile clip RJ45 cable Earphone 9V battery The accessories are included in the whole set, their usage are as below. RJ45 cable Connect 8-core network cable with transmitter or reiceiver. Crocodile clip clip the wire cores to test if necessary. RJ11 cable Connect telephone line (2/4/6 cores) with transmitter of reiceiver. -
Page 9: Operation Methods
Operation methods Usage of transmitter Open battery cover, install DC 9V battery in launcher, push the key to “scan”, the indicator flashes, which means the transmitter is normal. Connect two ends of network line to the RJ45 port of launcher and remote identifier separately. then hold the receiver to find the target line. -
Page 10: Hunting Test
Hunting test Network line (as below) 1. Open battery cover, install DC 9V battery in launcher, push the key to “scan”, its indicator flashes, which means the transmitter work well. 2. Connect one end of network line to the RJ45 port of launcher. 3. -
Page 11: Monitoring Line
Monitoring line(as below) 1. Open battery cover, install DC 9V battery in launcher,push the key to “scan”, its indicator flashes, which means the transmitter work well. 2. Connect one end of BNC line to the BNC port of launcher. 3. push the key to “scan” of receiver, then its indicator flashes, which means the receiver is normal. -
Page 12: Wire Sorting
Wire sorting ( RJ45 as an example) 1. Connect two ends of network line to the RJ45 port of launcher and receiver separately. 2. And push the key to “test”, the wire sort indicators will flash, which means the transmitter works well. (adjust its speed by press the button of “Set”) 3.If the wire is normal, and the GND is not connected, then the 8 indicators will flash one by one. -
Page 13: Other Functions
Other functions (1) Low-voltage hint function When the battery voltage is low, push the function button to “scan” or “test” , at this time, both the scan indicator and wire sorting indicator will flash, which means the battery should be replaced. -
Page 14: Packing List
Packing list 6. RJ45 adapter line 1PCS 1. Emitter 1PCS 2. Receiver 1PCS 7. Cable Clip 1PCS 3. Laminated battery of 9V 2PCS 8. User manual 1PCS 4. Earphone 1PCS 9. Kit 1PCS 5. RJ11 Adapter line 1PCS 10. Color box 1PCS Your excellent helper in cable test! -
Page 15: Diagram Of Series Products
NF-306 NF-868 NF-8208 NF-801B NF-806R NF-816 NF-468L NF-3468 NF8108-M NF-388 NF-903 NF-906A Your excellent helper in cable test! - Page 16 Your excellent helper in cable test! SHENZHEN NOYAFA ELECTRONIC CO.,LTD...
