User's Guide
Instructions for Installation and Operation
2.4 GHZ SPREAD SPECTRUM REMOTE CONTROLS
Handheld Transmitter
Model KTXW24SSA1
KTXW24SSA2
KTXW24SSA4
KTXW24SSA6
KTXW24SSA12
Remote Control Receiver w/Relays
Model RCR24SSA-6R
Long Range Wireless Applications
1
This page intentionally left blank.
2
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Applied Wireless KTXW24SSA1
Summary of Contents for Applied Wireless KTXW24SSA1
- Page 1 User’s Guide This page intentionally left blank. Instructions for Installation and Operation 2.4 GHZ SPREAD SPECTRUM REMOTE CONTROLS Handheld Transmitter Model KTXW24SSA1 KTXW24SSA2 KTXW24SSA4 KTXW24SSA6 KTXW24SSA12 Remote Control Receiver w/Relays Model RCR24SSA-6R Long Range Wireless Applications...
-
Page 2: Remote Control Receiver
Relay #6 channels 7 to 12. Relay #1 The receiver can quickly “learn” up to 60 Applied Wireless transmitters with Relay #2 different address codes. All keyfob transmitters come from the factory with a unique ID code. A receiver will only respond to the transmitter whose ID code Relay #3 has been “learned”. - Page 3 RCR24SSA-6R Programming and Configuration Momentary Mode (factory-default) Transmitter Learn Mode A relay energizes when its associated button on the transmitter is pressed. The relay deactivates when the transmitter’s button is released (or reception of the The receiver will learn up to 4 transmitter IDs, storing the IDs in non-volatile flash transmitter’s signal ceases).
- Page 4 24-VAC coil (AW PN 269006, 25A contactor). For low voltage loads over 10 Amps, Applied Wireless offers internal 16A relay option or high current relays (AWPN 269007, 30A 12VDC Relay) that can be...
- Page 5 Board Switch & Jumper Locations RCR24SSA-6R Programming and Configuration Frequency Setting (DIP Switch S2) It is recommended that you do not change this setting unless needed. In order for more than one system to operate in the same area, up to 16 different frequency settings are available.
- Page 6 RCR24SSA-6R Receiver Block Diagram RCR24SSA-6R Receiver Package Information 3.85 1 .36 .1 90 A NTEN NA +1 2 TO 24 V AC/D C +1 2 V 1 .239 1 .42 N C6 A N TENNA RELA Y 6 NO 1 N O 6 N C5 PO W ER...
- Page 7 RCR24SSA-12R Receiver Block Diagram Ordering Information Model 6-Button Watertight 12-Button Frequency Number Transmitter Transmitter (MHz) ANTENN A + 1 2 TO 24 V 2400- RCR24SSA-6R KTXW24SSA2, -4, -6 AC/DC + 1 2 V 2483 RCR24SSA-6R KTX24SSA12 N C1 N O 1 + 1 2 V Receiver Electrical Characteristics Parameter...
- Page 8 Application Circuit – DC Motor Forward/Reverse Circuit For Models: KTXW24SSAn and HTXW24SSAn where n=number of channels: This is an example of using the RCR24SSA-6R Receiver for wireless FCC ID: UY124 forward and reverse remote control of a DC motor. The wiring diagram shows the “This device complies with Part 15 of the FCC Rules. Operation is subject to the motor connected to Relays 1 and 2.
- Page 9 You must first contact AW at the following address/phone for assistance: Any cost or expense related to repairing or CONSEQUENTIAL DAMAGES correcting the installation of an AW AW expressly disclaims liability for incidental APPLIED WIRELESS, INC. product. consequential damages caused...
-
Page 10: Troubleshooting Guide
Receiver Antenna connected, vertically oriented and placed preferably at least 7' high and away from metal surfaces. Copyright 2014 by Applied Wireless, Inc. All rights reserved. Antenna will not work inside a Specifications subject to change without notice. metal box...
