User's Guide
Instructions for Installation and Operation
2.4 GHZ SPREAD SPECTRUM REMOTE CONTROLS
Handheld Transmitter
Model KTXW24SSA1
KTXW24SSA2
KTXW24SSA4
KTXW24SSA6
KTX24SSA12
Remote Control Receiver w/Relays
Model RCR24SSA-6R
Long Range Wireless Applications
1
This page intentionally left blank.
2
Advertisement
Related Manuals for Applied Wireless KTXW24SSA1
Summary of Contents for Applied Wireless KTXW24SSA1
- Page 1 User’s Guide This page intentionally left blank. Instructions for Installation and Operation 2.4 GHZ SPREAD SPECTRUM REMOTE CONTROLS Handheld Transmitter Model KTXW24SSA1 KTXW24SSA2 KTXW24SSA4 KTXW24SSA6 KTX24SSA12 Remote Control Receiver w/Relays Model RCR24SSA-6R Long Range Wireless Applications...
-
Page 2: Remote Control Receiver
6 (default) or channels 7 to 12. Bank A, Relay #6 Bank A, Relay #1 The receiver can quickly “learn” up to 60 Applied Wireless transmitters with different address codes. All keyfob transmitters come from the Bank A, Relay #2 factory with a unique ID code. - Page 3 RCR24SSA-6R Programming and Configuration Transmitter Learn Mode Momentary Mode (factory-default) The receiver will learn up to 60 transmitter IDs. A relay energizes when its associated button on the transmitter is To learn a transmitter: pressed. The relay deactivates when the transmitter’s button is released 1.
- Page 4 24-VAC coil (AW PN 269006, 25A contactor). For low voltage loads over 10 Amps, Applied Wireless offers internal 16A relay option or high current relays (AWPN 269007, 30A 12VDC Relay) NOTE: When a KTX24SSA-12 transmitter controls two RCR24SSA-6R that can be controlled by the RCR receiver.
- Page 5 Board Switch & Jumper Locations RCR24SSA-6R Programming and Configuration Frequency Setting (DIP Switch S2) It is recommended that you do not change this setting unless needed. In order for more than one system to operate in the same area, up to 16 different frequency settings are available.
- Page 6 RCR24SSA-6R Receiver Block Diagram RCR24SSA-6R Receiver Package Information 3.85 1 .36 .1 90 AN TEN NA +1 2 TO 24 V AC/D C +1 2 V 1 .239 1 .42 N C6 A NTENNA RELAY 6 NO 1 N O6 N C5 POW ER +1 2 V...
- Page 7 RCR24SSA-12R Receiver Block Diagram Ordering Information Model 6-Button Watertight 12-Button Frequency Number Transmitter Transmitter A NTENNA (MHz) +1 2 TO 24 V AC /DC 2400- RCR24SSA-6R KTXW24SSA2, -4, -6 + 1 2 V 2483 RCR24SSA-6R KTX24SSA-12 NC 1 NO 1 Receiver Electrical Characteristics + 1 2 V NC 2...
-
Page 8: Not Covered
ARRANTY This is an example of using the RCR24SSA-6R Receiver for wireless Products manufactured by APPLIED WIRELESS, INC. (AW) and sold to purchasers in the USA are forward and reverse remote control of a DC motor. The wiring diagram warranted by AW according to the following terms and conditions. You should read this Warranty shows the motor connected to Relays 1 and 2. -
Page 9: Troubleshooting Guide
Antenna Receiver Antenna You must first contact AW at the following address/phone for assistance: connected, vertically oriented and placed APPLIED WIRELESS, INC. 1250 Avenida Acaso, Suite F preferably at least 7' high Camarillo, CA 93012 and away from metal Phone: (805) 383-9600 surfaces. - Page 10 Applied Wireless products are designed and manufactured with pride in the United States of America Copyright 2014 by Applied Wireless, Inc. All rights reserved. Specifications subject to change without notice. PPLIED IRELESS 1250 Avenida Acaso, Unit F, Camarillo, CA 93012 Phone: 805-383-9600 Fax: 805-383-9001 Email: info@appliedwireless.com...
