Southwire Shoreline Reels RW Instructions Manual

IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
WARNING
– When using electric appliances, basic precautions should always
be followed, including:
• Read all instruction before using the appliance.
• To reduce risk of injury, close supervision is necessary when an appliance is used near children.
• Do not contact moving parts.
• Only use attachments and accessories recommended or sold by manufacturer.
• Do not use outdoors.
• Turn the power switch to the off position when the appliance is not in use and before servicing or cleaning.
• To reduce the risk of electric shock, disconnect the 12VDC power source prior to proceeding.
PLEASE READ THESE INSTRUCTIONS CAREFULLY.
In the event you have any questions concerning use or care of this product, please contact the sales department at Southwire Company, LLC.
WASHDOWN/SHORE WATER HOSE REELS
Tools Required: Drill, Wire Stripers, 5/16 Wrench, Tape Measure, Phillips Screwdriver
Parts Included: 1 Hose Reel
Additional Parts: (Available from Southwire) Switch assembly MH2021, Floor Hatch, and Under Coach Roller Guide

Installation Procedure

1. Identify compartment where the hose reel will be installed. To simplify the installation, it is strongly recommended that the hose reel
be installed in the compartment that stores the existing water hose.
2. Measure the compartment to insure there is enough space for the reel. Dimensional drawings are available at rvpower.southwire.com
Do not forget to leave room for the water hose to exit through the floor or wall directly in front of or below the hose reel.
3. Determine if you want the hose to exit through a side door or floor port. For proper operation the hose exit must be centered with the
center of the spool. The distance away from the spool is not important, only that it is centered. If the exit is not centered the hose will
wrap on the side of the spool closest to the exit and could bind on the reel.
4. Place the hose reel in the compartment.
5. Mark the floor, wall, or compartment where mounting bolts or screws will be located. Remove reel from compartment and drill holes
for mounting bolts or screws. If reel is to be hung from the top of a compartment it must be installed into a steel frame component. Hang-
ing reels from a wooden compartment is not recommended. If mounting on a plastic floor, a stiffening board or plate must be added.
6. Place hose reel back in compartment and install mounting screws or bolts.
7. If installing floor or wall hatch, drill or cut opening. For proper operation the hose exit must be centered with the center of the spool.
Mount the floor or wall hatch.
8. If using Southwire switch assembly MH2021, mount switch face plate in desired location using appropriate hardware. If using alter-
nate switch not supplied by Southwire, mount switch according to manufactures instructions. It may be necessary to mount switch
after wiring to help with the routing and termination of wires. Be sure to mount and secure all wires to prevent any possible mechani-
cal damage to outer insulation on the wires.
For technical assistance, please call 1-800-780-4324 x 20311
Manufactured by Southwire Company, LLC, 4525 140th Avenue North, Suite 900, Clearwater, Florida 33762
MODEL #RW

INSTALLATION INSTRUCTIONS

© 2017 Southwire Company, LLC. All rights reserved. * Trademark of Southwire Company, LLC. Registered in the United States.
505-00084C
