Camera Connection Diagram

Your Smart
Device
Router
PoE Switch/Injector
Network Cable
3 English
PoE IP Camera
Network Cable
Power Adapter

Set up the Camera on Reolink App (For Smartphone)

Download and install the Reolink App on App Store (for iOS) or Google Play (for Android).
Get it on
Available on the
• Add the Camera in the Same Network
(In LAN)
1. Connect your smartphone to the Wi-Fi network of your router.
2. Launch Reolink App. The camera will automatically display in the
camera list in LAN.
3. Tap screen to create a login password and name your camera.
4. Start live view or go to " " for more configurations.
