Summary of Contents for HIKVISION DS-2CC5181PN-VF
- Page 1 Day/Night High-definition Dome Camera V1.1.0 User Manual...
- Page 2 Day/Night High-definition Dome Camera·User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer. This manual applies to DS-2CC5181P(N)-VF, DS-2CC5191P(N)-VF, DS-2CC51A1P(N)-VF dome Camera. This manual may contain several technical incorrect places or printing errors, and the content is subject to change without notice.
- Page 3 Day/Night High-definition Dome Camera·User Manual Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 4 Day/Night High-definition Dome Camera·User Manual 2002/96/EC (WEEE directive): Products marked with this symbol cannot be disposed of as unsorted municipal waste in the European Union. For proper recycling, return this product to your local supplier upon the purc hase of equivalent new equipment, or dispose of it at designated collection points.
- Page 5 Day/Night High-definition Dome Camera·User Manual Safety Warnings and Cautions Please pay attention to the following warnings and cautions: Hazardous Voltage may be present: Special measures and precautions must be taken when using this device. Some potentials (voltages) on the device may present a hazard to the user. This device should only be used by Employees from our company with knowledge and training in working with these types of devices that contain live circuits.
- Page 6 Day/Night High-definition Dome Camera·User Manual attached is also connected to properly wired grounded receptacles and are approved medical devices. Power Connect and Disconnect: The AC power supply cord is the main disconnect device to mains (AC power).The socket outlet shall be installed near the equipment and shall be readily accessible.
- Page 7 Day/Night High-definition Dome Camera·User Manual Perchlorate Material: Special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate. This notice is required by California Code of Regulations, Title 22, Division 4.5, Chapter 33: Best Management Practices for Perchlorate Materials. This device includes a battery which contains perchlorate material. Taiwan battery recycling: Please recycle batteries.
- Page 8 Day/Night High-definition Dome Camera·User Manual Lead Content: Please recycle this device in a responsible manner. Refer to local environmental regulations for proper recycling; do not dispose of device in unso rted municipal waste.
- Page 9 Day/Night High-definition Dome Camera·User Manual Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions” Warnings: Serious injury or death may occur if any of the warnings are neglected.
- Page 10 Day/Night High-definition Dome Camera·User Manual the Limited Power Source with AC 24V or DC 12V according to the IEC60950-1 standard. Please refer to technical specifications for detailed information. Input voltage should meet both the SELV(Safety Extra Low Voltage) and the Limited Power Source with AC 24V or DC 12V according to the IEC60950-1 standard.
- Page 11 Day/Night High-definition Dome Camera·User Manual Do not drop the camera or subject it to physical shock. Do not touch CCD (Charge Coupled Device) modules with fingers. If cleaning is necessary, use clean cloth with a bit of ethanol and wipe it gently. If the camera will not be used for an extended period, please replace the lens cap to protect the CCD from dirt.
-
Page 12: Table Of Contents
Day/Night High-definition Dome Camera·User Manual Table of Contents 1 Introduction..............1 1.1 Product Features ..........1 1.2 Function Summary ..........2 2 Installation ..............5 2.1 Ceiling mounting ..........5 2.2 In ceiling mounting with gang box ......9 ... -
Page 13: Introduction
Day/Night High-definition Dome Camera·User Manual 1 Introduction 1.1 Product Features This camera adopts high performance CCD and advanced print circuit board design technology. It possesses of high resolution, low distortion, and low noise features, etc. It is extremely suitable for supervisory system and image process system. Adopt high performance SONY CCD, and supply high definition ... -
Page 14: Function Summary
Day/Night High-definition Dome Camera·User Manual Support auto iris Support Privacy mask with 8 optional colors and 8 configurable areas Advanced 3-axis design allows this dome camera to be adjusted 0-355° horizontally and 0-180° vertically to meet different mounting requirements Adopt advanced double-plate design to guarantee the heat ... - Page 15 Day/Night High-definition Dome Camera·User Manual DAY/NIGHT Auto Switch: The cameras deliver color images during the day. And as light diminishes at night, the cameras switch to night mode and deliver black and white images with high quality. AGC: AGC is a control circuit that automatically changes the gain of a receiver or other piece of equipment, so that the desired output signal remains essentially.
- Page 16 Day/Night High-definition Dome Camera·User Manual front to make it clear, but this causes the over-exposure of the background where the light is strong. Figure 1-2 BLC OFF and BLC ON...
-
Page 17: Installation
Day/Night High-definition Dome Camera·User Manual 2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Note: Please ensure that the wall is strong enough to withstand three times the weight of the camera and then install the camera securely. - Page 18 Day/Night High-definition Dome Camera·User Manual 3. Attach the drill template (supplied) to the place where you want to fix the camera. 4. Drill four screws holes according to the number 2 circles on the drill template as shown in Figure 2-2. Figure 2-2 The Drill Template 5.
- Page 19 Day/Night High-definition Dome Camera·User Manual Note: Please use expansion screws if the dome camera is mounted to cement wall. Ceiling Black Base Screws Figure 2-3 Mounting the Base 9. Route the cables through the hole in the center of the drill template.
- Page 20 Day/Night High-definition Dome Camera·User Manual 12. Connect the video output connector to the monitor. Connect the power connector to the power supply. 13. Three-axis adjustment. 1). View the camera image using the monitor. 2). Rotate the panning table to adjust the panning position of the camera.
-
Page 21: In Ceiling Mounting With Gang Box
Day/Night High-definition Dome Camera·User Manual 2). Loosen the zoom lock lever and move the lever between TELE and WIDE to obtain the appropriate angle of view. 3). Tighten the zoom lock lever. 4). Loosen the focus lock lever and move the lever between FAR and NEAR to obtain the optimum focus. - Page 22 Day/Night High-definition Dome Camera·User Manual Screws Figure 2-7 Disassembling 5. Attach the drill template (supplied) to the place where you want to fix the camera. 6. Drill two screws holes according to the two circles on the drill template as shown in Figure 2-8. 7.
- Page 23 Day/Night High-definition Dome Camera·User Manual 8. Install the gang junction box in the ceiling. by aligning the two screw holes with the two screw holes of the drill template. 9. Attach the inceiling mount to the ceiling by aligning the number 2 small holes of the inceiling mount with the two holes on the drill template.
- Page 24 Day/Night High-definition Dome Camera·User Manual Figure 2-10 Securing the Camera 14. Connect the video output connector to the monitor. Connect the power connector to the power supply. 15. Three-axis adjustment. 1). View the camera image using the monitor. 2). Rotate the panning table to adjust the panning position of the camera.
- Page 25 Day/Night High-definition Dome Camera·User Manual Tilting Lock Screw Panning Table Figure 2-11 Lens Adjustment 16. Zoom and focus adjustment. 1). View the camera image using the monitor. 2). Loosen the zoom lock lever and move the lever between TELE and WIDE to obtain the appropriate angle of view. 3).
-
Page 26: In Ceiling Mounting Without Gang Box
Day/Night High-definition Dome Camera·User Manual Figure 2-12 Lower Dome Installation 2.3 In ceiling mounting without gang Steps: 1. Rotate the lower dome anticlockwise to remove it. 2. Remove the inner black liner. 3. Loosen the two screws as shown in Figure 2-13. 4. - Page 27 Day/Night High-definition Dome Camera·User Manual 5. Attach the drill template (supplied) to the place where you want to fix the camera. 6. Drill two screws holes according to the two circles on the drill template as shown in Figure 2-14. 7.
- Page 28 Day/Night High-definition Dome Camera·User Manual Note: The inceiling mount is not supplied. Ceiling Inceiling mount Figure 2-15 Inceiling Mount 12. Route the cables through the hole in the center of the inceiling mount. 13. Align the two screw holes of the camera with the number 3 holes of the inceiling mount.
- Page 29 Day/Night High-definition Dome Camera·User Manual 1). View the camera image using the monitor. 2). Rotate the panning table to adjust the panning position of the camera. The adjusting range is from 0 degree to 355 degrees. 3). Loosen the tilting lock screw. 4).
- Page 30 Day/Night High-definition Dome Camera·User Manual 4). Loosen the focus lock lever and move the lever between FAR and NEAR to obtain the optimum focus. 5). Tighten the focus lock lever. 18. Rotate the inner black liner clockwise back to the camera. 19.
-
Page 31: Menu Description
Day/Night High-definition Dome Camera·User Manual 3 Menu Description 3.1 MAIN MENU Steps: 1. Press the button to access the main menu or the submenu. 2. Set the menu button up/down to position the cursor. 3. Set the menu button left/right to select the different options. Figure 3-1 Main Menu... -
Page 32: Lens Setting
Day/Night High-definition Dome Camera·User Manual 3.2 LENS Setting After moving the cursor to LENS, set the menu button up/down to select MANUAL or AUTO. Selecting MANUAL mode, you have to adjust the LENS IRIS manually. Selecting AUTO mode, press the button to enter the AUTO IRIS ... -
Page 33: Shutter/Agc Setting
Day/Night High-definition Dome Camera·User Manual 3.3 SHUTTER/AGC Setting SHUTTER/AGC allows you to adjust how the system balances SHUTTER and AGC settings in different light conditions. You can set the different shutter and AGC value according to the luminance level of the situation. You can choose MANUAL and AUTO mode for the shutter and AGC. - Page 34 Day/Night High-definition Dome Camera·User Manual 1/100k are selectable. The AGC value can be set between 6 and 44.8. Figure 3-4 AUTO SETUP In the AUTO SETUP submenu (Figure 3-4), you can adjust the BRIGHTNESS value. The system will automatically adjust the SHUTTER, AGC and AUTO IRIS settings according to the BRIGHTNESS setting.
-
Page 35: White Balance Setting
Day/Night High-definition Dome Camera·User Manual option is provided. BRIGHTNESS The value ranges from 0 to 255. In LOW LUMINANCE condition, the AGC can be adjusted automatically according to the BRIGHTNESS value. MODE Only AGC is available. ×1.00, ×0.75, ×0.50 and ×0.25 are BRIGHTNESS selectable. - Page 36 Day/Night High-definition Dome Camera·User Manual Selecting this feature, the system suppresses the color rolling under the fluorescent light when processing the color balance. USER 1 This mode is the indoor mode. It is suitable for indoor application. B-GAIN It’s used to adjust the picture output in the blue range.
- Page 37 Day/Night High-definition Dome Camera·User Manual R-GAIN The R-GAIN value ranges from 0 to 255. MANUAL Selecting MANUAL and pressing the button to enter the MANUAL WB submenu. Customize the LEVEL value on your demand. Figure 3-6 MANUAL WB Auto Tracking White Balance In ATW mode, white balance is continuously being adjusted in real-time according to the color temperature of the scene...
-
Page 38: Backlight Setting
Day/Night High-definition Dome Camera·User Manual DELAY CNT It’s the delay time between monitoring the light conditions changing and adjusting the white balance. ATW FRAME It’s used to adjust the image size of the ATW image. × 0.50, ×1.00, ×1.50 and × 2.00 are available. -
Page 39: Picture Adjust Setting
Day/Night High-definition Dome Camera·User Manual If there’s a strong backlight, the object in front of the backlight appears silhouetted or dark. BLC can correct the exposure of the subject. But the backlight environment is overexposed. HLC(Highlight Compensation) HLC masks strong light sources that usually flare across a scene. This makes it possible to see the detail of the image that would normally be hidden. -
Page 40: Atr Setting
Day/Night High-definition Dome Camera·User Manual Adjust this feature to change the color of the image. The value ranges from 0 to 255. GAIN Adjust this feature to change the depth of the color. The value ranges from 0 to 255. Figure 3-8 PICT ADJUST 3.7 ATR Setting ATR is the digital dynamic range function which can adjust the... -
Page 41: Motion Detection Setting
Day/Night High-definition Dome Camera·User Manual LUMINANCE There are MID, HIGH, LOW selectable, standing for middle, high and low luminance respectively. CONTRAST There are MID, HIGH, LOW, MIDLOW and MIDHIGH selectable. Figure 3-9 ATR 3.8 MOTION DETECTION Setting There are two kinds of MOTION DET panes, BLOCKDISP and MONITOR AREA. - Page 42 Day/Night High-definition Dome Camera·User Manual 2. Position the cursor on DETECT SENSE, set the menu button left/right to adjust the sensitivity level. 3. Position the cursor on BLOCK DISP, set the menu button left/right to select ENABLE. 4. Press the button to enter the setup interface of the detection panes.
- Page 43 Day/Night High-definition Dome Camera·User Manual 4. Position the cursor on AREA SEL to select one area. There are four areas available. 5. Set the values of TOP, BOTTOM, LEFT and RIGHT. The size and position of the area is defined by these values. And after you set all this value, you can see a frame on the image.
-
Page 44: Privacy Mask Setting
Day/Night High-definition Dome Camera·User Manual 3.9 PRIVACY MASK Setting This feature allows you to cover certain areas which you don’t want to be viewed or recorded. The size, color, transparency of the areas is adjustable. Steps: 1. After moving the cursor to PRIVACY, press the button to enter PRIVACY submenu. -
Page 45: Day/Night Setting
Day/Night High-definition Dome Camera·User Manual Figure 3-11 PRIVACY 3.10 DAY/NIGHT Setting There are five DAY/NIGHT modes selectable: AUTO, COLOR, and B/W. COLOR mode is used for normal lighting conditions. B/W mode can increase the sensitivity in low light conditions. AUTO Mode Setting In AUTO mode, the day mode and the night mode can switch automatically. - Page 46 Day/Night High-definition Dome Camera·User Manual 1. After moving the cursor to DAY/NIGHT, set the menu button left/right to select AUTO. 2. Press the button to enter the submenu. BURST Select ON or OFF to enable or disable this feature. DELAYCNT The value ranges from 0 to 255.
-
Page 47: Nr Setting
Day/Night High-definition Dome Camera·User Manual Figure 3-12 DAY/NIGHT B/W Mode Setting In the B/W submenu, you can enable or disable the BURST. Figure 3-13 B/W 3.11 NR Setting This feature is used to reduce the noise in the video signal. After moving the cursor to NR, press the button to enter the NR submenu. -
Page 48: Camera Id Setting
Day/Night High-definition Dome Camera·User Manual Figure 3-14 NR 3.12 CAMERA ID Setting In Camera ID submenu, you can customize the camera ID. It also allows you to adjust the camera ID position on the monitor screen. Select OFF, if you want to disable the Camera ID. ... - Page 49 Day/Night High-definition Dome Camera·User Manual 4. Repeat the steps 1 through 3 to select other characters. Modifying the camera ID Steps: 1. Position the cursor on one of the arrows. 2. Press the button to position the cursor on the character that needs to modify.
-
Page 50: Sync/Pixel Correct Setting
Day/Night High-definition Dome Camera·User Manual Figure 3-15 CAMERA ID 3.13 SYNC/PIXEL CORRECT Setting Both internal and line lock synchronization are available. (Only the camera which supports DC 12 V and AC 24 V power has line lock synchronization.) If 12V DC power supply is applied, SYNC mode is internal ... -
Page 51: Language Setting
Day/Night High-definition Dome Camera·User Manual 3.14 LANGUAGE Setting You can adjust the language of the on-screen menu. The factory default language is English. Steps: 1. Move the cursor to LANGUAGE. 2. Set left/right to select the language you need. 3.15 CAMERA RESET Setting After moving the cursor to CAMERA RESET, press the button to reset all camera settings to factory default parameters. -
Page 52: Appendix
Day/Night High-definition Dome Camera·User Manual Appendix Table 1 DS-2CC5181P(N)-VF Specification DS-2CC5181P(N)-VF Model Parameter 600 TVL CCD ICR Dome Camera Camera Image Sensor 1/3” SONY Super HAD CCD II Signal System PAL/NTSC PAL: 752 (H) × 582 (V) Effective Pixels NTSC: 768 (H) × 494 (V) Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), Min. - Page 53 Day/Night High-definition Dome Camera·User Manual Angle Adjustment Pan: 0 - 355°, Tilt: 0 - 180°, Rotation: 0 - 355° Day & Night IR cut filter with auto switch Horizontal 600 TVL (Color), 650 TVL (B/W) Resolution Synchronization Internal/Power synchronization 1Vp-p composite output (75 Ω/BNC) Video Output Test monitor out [1Vp-p composite output (75 Ω/BNC), device line]...
- Page 54 Day/Night High-definition Dome Camera·User Manual -10 °C - 60 °C (14 °F - 140 °F) Operating Conditions Humidity 90% or less (non-condensing) Power Supply 24 V AC ± 10%, 12 V DC ± 10% Max. 4 W Power Consumption (Max. 4.5 W with IR cut filter on) Dimension Φ...
-
Page 55: Table 2 Ds-2Cc5191P(N)-Vf
Day/Night High-definition Dome Camera·User Manual Table 2 DS-2CC5191P(N)-VF Specification DS-2CC5191P(N)-VF Model Parameter 650 TVL CCD ICR Dome Camera Camera Image Sensor 1/3” SONY EXview HAD CCD II Signal System PAL/NTSC PAL: 976 (H) × 582 (V) Effective Pixels NTSC: 976 (H) × 494 (V) Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), Min. - Page 56 Day/Night High-definition Dome Camera·User Manual Horizontal 650 TVL (Color), 700 TVL (B/W) Resolution Synchronization Internal/Power synchronization 1Vp-p composite output (75 Ω/BNC) Video Output Test monitor out [1Vp-p composite output (75 Ω/BNC), device line] S/N Ratio More than 62 dB Menu Camera ID On/Off (52 letters, adjusted position) D/N Mode...
- Page 57 Day/Night High-definition Dome Camera·User Manual Power Supply 24 V AC ± 10%, 12 V DC ± 10% Max. 4 W Power Consumption (Max. 4.5 W with IR cut filter on) Dimension Φ 136 × 101 mm (Φ 5.35” × 3. 98”) Weight 800 g (1.76 lbs) Dimension...
-
Page 58: Table 3 Ds-2Cc51A1P(N)-Vf
Day/Night High-definition Dome Camera·User Manual Table 3 DS-2CC51A1P(N)-VF Specification DS-2CC51A1P(N)-VF Model Parameter 700 TVL CCD ICR Dome Camera Camera Image Sensor 1/3” SONY EXview HAD CCD II Signal System PAL/NTSC PAL: 976 (H) × 582 (V) Effective Pixels NTSC: 976 (H) × 494 (V) Color: 0.001 Lux @ (F1.2, AGC ON), B/W: 0.0001 Lux @ (F1.2, AGC ON), Min. - Page 59 Day/Night High-definition Dome Camera·User Manual Horizontal 700 TVL Resolution Synchronization Internal/Power synchronization 1Vp-p composite output (75 Ω/BNC) Video Output Test monitor out [1Vp-p composite output (75 Ω/BNC), device line] S/N Ratio More than 62 dB Menu Camera ID On/Off (52 letters, adjusted position) D/N Mode Auto /Day/Night ATW/PUSH/USER1/USER2/ANTI CR/MANUAL/PUSH...
- Page 60 Day/Night High-definition Dome Camera·User Manual Power Supply 24 V AC ± 10%, 12 V DC ± 10% Max. 4 W Power Consumption (Max. 4.5 W with IR cut filter on) Dimension Φ 136 × 101 mm (Φ 5.35” × 3. 98”) Weight 800 g (1.76 lbs) Dimension...
