Avsl Mercury AMPLUG02 User Manual

Plug-in 2-way

AMPLUG02

PLUG-IN 2-WAY DISTRIBUTION

AMPLIFIER

Please read through this manual carefully before use. This product is strictly

for indoor use only, please install this product in dry and cool environment

Power:

Frequency range:

Gain per split:

Noise :

Impedance:

Max output level:

Dimensions & weight:

Thank you for choosing this Mercury plug-in distribution amplifier. It is designed to amplify

weak FM/DAB/TV signals from the aerial and distribute them to 2 outputs. Simply connect the

aerial and TV, plug into the mains socket and it is ready to use.

CAUTION

and keep out of the reach of children and pets.

230Vac, 50Hz

47 – 862MHz

10-20dB

<4dB

75Ω

90dBuV

135 x 75 x 42mm, 240g

Item ref: 130.036UK

User Manual

Table of Contents

Do you have a question about the Mercury AMPLUG02 and is the answer not in the manual?

Page 1: User Manual
AMPLUG02 Item ref: 130.036UK PLUG-IN 2-WAY DISTRIBUTION User Manual AMPLIFIER CAUTION Please read through this manual carefully before use. This product is strictly for indoor use only, please install this product in dry and cool environment and keep out of the reach of children and pets. SPECIFICATION: Power: 230Vac, 50Hz...
Page 2 This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its useful life. The goods must be disposed of according to your local council guidelines. Errors and omissions excepted. Copyright© 2014. AVSL Group Ltd 130.036 UK User Manual...
