- Page 1 INSTALLATION MANUAL • Thank you for purchasing this ecox product. • Before using this machine, please read this manual and retain it for future reference. EDEM EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 2: Table Of Contents
Pipe length connection instructions – refrigerant Piping cut pipe remove burrs flare pipe ends connect pipes air evacuation evacuation instructions note on adding refrigerant electrical and gaS leak checkS teSt run euroPean diSPoSal guidelineS EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 3: Safety Precautions
When the unit is checked for leaks, proper record-keeping of all If the chosen location cannot support the unit’s weight, or the checks is strongly recommended. installation is not done properly, the unit may drop and cause serious injury and damage. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 4: Accessories
Remote control illustration Φ 6.35( 1/4 in) Connecting pipe assembly Liquid side Φ 9.52( 3/8in) Parts you must purchase. Consult the dealer about Φ 9.52( 3/8in) the pipe size. Gas side Φ 12.7( 1/2in) Φ 16( 5/8in) EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 5 INSTALLATION INSTRUCTIONS - INDOOR UNIT Attach Mounting Plate Drill Wall Hole (Page 11) (Page 11) EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
- Page 6 Connect Piping Connect Wiring Prepare Drain Hose (Page 23) (Page 14) (Page 12) Wrap Piping and Cable (Page 16) Mount Indoor Unit (Page 16) EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 7: Unit Parts
Remote holder Outdoor unit power cable (some units) Fig. 2.1 NOTE Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be slightly different. The actual shape shall prevail. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 8 Wrap those cables not connected with terminals with insulation tapes, so that they will not touch any electrical components. Secure the cable onto the control board with the cord clamp. EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 9: Indoor Unit Installation
(e.g., TV, radio, computer) The default position for all piping is the right side of the indoor unit (while facing the unit). However, the unit can accommodate piping to both the left and right. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 10: Attach Mounting Plate To Wall
If the wall is made of brick, concrete, or similar material, drill 5mm- diameter (0.2in-diameter) holes in the wall and insert the sleeve anchors provided. Then secure the mounting plate to the wall by tightening the screws directly into the clip anchors. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 11 Height of mounting plate Width of indoor unit relative to plate Height of indoor unit relative to plate Recommended position of wall hole (both to the left and right of mounting plate) Relative distances between screw holes EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 12: Prepare Refrigerant Piping
Right rear Refer to Fig. 3.4 for details. CAUTION Be extremely careful not to dent or damage the piping while bending them away from the unit. Any dents in the piping will affect the unit’s performance. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 13: Connect Drain Hose
Make sure to arrange the drain hose according to Fig. 3.5 . DO NOT kink the drain hose. DO NOT create a water trap. DO NOT put the end of drain hose in water or a container that will collect water. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 14: Connect Signal Cable
OFF THE MAIN POWER TO THE SYSTEM . maximum current is indicated on the nameplate located on the side panel of the unit. Refer to this nameplate to choose the right cable, fuse, or switch. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 15 While crimping wires, make sure you clearly distinguish the Live (“L”) Wire from other wires. Open front panel of the indoor unit. Using a screwdriver, open the wire box cover on the right side of the unit. This will reveal the terminal block. EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 16: Wrap Piping And Cables
Using adhesive vinyl tape, attach the drain hose to the underside of the refrigerant pipes. Using insulation tape, wrap the signal wire, refrigerant pipes, and drain hose tightly together. Double-check that all items are bundled in accordance with Fig. 3.12 . EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 17: Outdoor Unit Installation
Near animals or plants that will be harmed by hot air discharge Near any source of combustible gas In a location that is exposed to large amounts of dust In a location exposed to a excessive amounts of salty air EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 18: Install Drain Joint
CAUTION In cold climates Make sure that the drain hose is as vertical as possible to ensure swift water drainage. If water drains too slowly, it can freeze in the hose and flood the unit. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 19: Anchor Outdoor Unit
Hammer expansion bolts into the pre-drilled holes. Remove the nuts from expansion bolts, and place outdoor unit on bolts. Put washer on each expansion bolt, then replace the nuts. Using a wrench, tighten each nut until snug. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 20: Connect Signal And Power Cables
Step 4: Connect signal and power cables The outside unit’s terminal block is protected by an electrical wiring cover on the side of the unit. A comprehensive wiring diagram is printed on the inside of the wiring cover. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 21 Using wire strippers, strip the rubber jacket from both ends of cable to reveal about 15cm (6in) of the wires inside. Strip the insulation from the ends of the wires. Using a wire crimper, crimp u-lugs on the ends of the wires. EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 22: Refrigerant Piping Connection
Make sure that the pipe is cut at a perfect 90° angle. Refer to Fig. 5.1 for bad cut examples. Measure the distance between the indoor and outdoor units. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 23: Remove Burrs
Place flaring tool onto the form. Turn the handle of the flaring tool clockwise until the pipe is fully flared. Remove the flaring tool and flare form, then inspect the end of the pipe for cracks and even flaring. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 24: Connect Pipes
Torque Requirements table below. Loosen the flaring nut slightly, then tighten again. CAUTION Do not use excessive torque Excessive force can break the nut or damage the refrigerant piping. You must not exceed torque requirements shown in the table above. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 25 While firmly gripping the body of the valve, use a torque wrench to tighten the flare nut according to the correct torque values. Loosen the flaring nut slightly, then tighten again. Repeat Steps 3 to 6 for the remaining pipe. EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 26: Air Evacuation
Check to make sure that both high pressure and low-pressure pipes between the indoor and outdoor units are connected properly in accordance with the Refrigerant Piping Connection section of this manual. Check to make sure all wiring is connected properly. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 27: Note On Adding Refrigerant
Fixed-frequency R410A: (Pipe length – standard length) x 20g/m (Pipe length – standard length) x 40g/m (Pipe length – standard length) x 0.21oZ/ft (Pipe length – standard length) x 0.42oZ/ft CAUTION DO NOT mix refrigerant types. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 28: Electrical And Gas Leak Checks
Performing gaS leak checkS the leakage. After confirming that the all pipe connection points DO NOT leak, replace the valve cover on the outside unit. EDEM SPLIT-TYPE ROOM AIR CONDITIONER... -
Page 29: Test Run
Indoor unit responds to remote controller COOL – Select lowest possible temperature HEAT – Select highest possible temperature Let each function run for 5 minutes, and perform the following checks: EDEM SPLIT-TYPE ROOM AIR CONDITIONER... - Page 30 Lift the front panel of the indoor unit, and raise it until it clicks in place. The MANUAL CONTROL button is located on the right-hand side of the unit. Press it 2 times to select the COOL function. See Fig 8.1 . Perform Test Run as normal. EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
-
Page 31: European Disposal Guidelines
Hazardous substances may leak into the ground water and enter the food chain. The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. EDEM SPLIT-TYPE ROOM AIR CONDITIONER...
