INSTALLATION MANUAL Thank you for purchasing this ecox product Before using this machine, please read this manual and retain it for future reference. NACM / EACM NACM / EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 2: Table Of Contents
If the area where the air conditioner is going to remain idle, shut down your computer for saving energy. In unconditioned spaces should reduce the heat load introduced by excessive lighting or equipment remain on unnecessarily. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 3: Installation Precautions
Be sure to follow all the precautions below, they are all important for ensuring safety. This symbol indicates the possibility of death or serious injury. This symbol indicates the possibility of injury or damage to property. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... - Page 4 Do not modify the length of the power supply cord or use of extension cord, and do not share the single outlet with other electrical appliances. Otherwise, it will cause fire or electrical shock. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE...
-
Page 5: Select The Best Location
Ga s side Φ12.7(1/2in) Φ 16(5/8in) Remot e controlle r Self-tapping Screw B ST2.9X10 Except the above parts provided,the other Optional parts needed during installation you must Remote controller holder parts purchase. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 6: Installation Plate Mounting
5mm diameter holes in the wall.Insert Clip anchor for appropriate mounting screws. Fit the installation plate on the wall with five or eight type A screws. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 7: Connect The Cable To The Indoor Unit
An individual branch circuit and single receptacle used only for this air conditioner must be available. See the following table for suggested wire sizes and fuse specifications: NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 8: Connective Pipe And Drainage Installation
Figure on the right. Because the condensed water from rear of the indoor unit is gathered in ponding box and is piped out of room. Do not put anything else in the box. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 9: Outdoor Insallation Precaution
Firmly hold copper pipe in a die in the dimension shown in the conditioner should be firm, stable and reliable. table below. Be sure there is no obstacle which block radiating air. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... -
Page 10: Connect The Cable To The Outdoor Unit
Securely tighten the valve stem cap with a spanner or the like. Insulate unused cords (conductors) with PVC-tape. Process them so they do not touch any electrical or metal parts. Valve stem cap tightening torque. See Tightening torque table. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE... - Page 11 Press the Manual control button to select the AUTO or COOL, the unit will operate under Forced AUTO or COOL mode (see User Manual for details). The test operation should last about 30 minutes. NACM/EACM ROOM AIR CONDITIONER - SPLIT WALL-MOUNTED TYPE...
