Sharp PG-M20 Series Quick Start Reference Sheet

Hide thumbs
1
2
3
4
5

Advertisement

Quick Links

Download this manual
NOTE: This one-page document is intended only as a quick reference for installation – please read
the SP Controls Application Note for a complete description of this projector driver prior to installation.
I. Driver Features
1. Input Selection Mapping
Selection 1:
DVI
Selection 2:
S-VIDEO
Selection 3:
VIDEO
Selection 4:
VIDEO
2. Hidden Function Mapping (Default Configuration)
Using the ON button as a shift key, press the following buttons to access the specified projector features.
Selection 1:
ENTER
Selection 2:
UNDO
Selection 3:
ADJ LEFT
Selection 4:
ADJ RIGHT
Off:
MENU
Volume Up:
ADJ UP
Volume Down:
ADJ DOWN
3. Other Driver Features
Power Status Feedback Method
Control Wiring:
II. Wiring Specifications
NOTE: For a wiring diagram, please see the SP Controls Application Note.
1. Infrared Emitter:
Wire the Panel IR/Serial port to a female 1/8" Mini as follows:
IR/SER to
tip
GND to
ring
Connect to the included IR Emitter and attach the emitter bud to any projector IR window.
III. Additional Projector Information
There are settings on the Sharp PG-M20x projector that will affect how the SmartPanel will work. In order
to receive the best performance, set the following options to OFF in the projectors menu screens.
Press the MENU button either using the SmartPanel hidden functions or the Sharp remote control. Then
change the following settings.
1. In the Options menu screen turn Auto Power Off to OFF
2. In the Options menu screen turn the Power Save to OFF
3. In the Options menu screen turn the Auto Search to OFF
DR-SHP20 – 9/17/03
Sensor
IR-Emitter
SP Controls reserves the right to modify specifications without notice at any time.
Quick Start Reference Sheet
Sharp PG-M20x
Revision A
