Building Automation
Industrial Automation
Systems
Hardware and Engineering
XStart
11/01 AWB2700-1426GB
For Immediate Delivery call KMParts.com at (866) 595-9616

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XStart and is the answer not in the manual?

Questions and answers

Related Manuals for Moeller XStart

Summary of Contents for Moeller XStart

  • Page 1 Building Automation Industrial Automation Systems Hardware and Engineering XStart 11/01 AWB2700-1426GB For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 2 No part of this manual may be reproduced in any form (printed, photocopy, microfilm or any other process) or processed, duplicated or distributed by means of electronic systems without written permission of Moeller GmbH, Bonn For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 3 Warning! Dangerous electrical voltage! Before commencing the installation • Disconnect the power supply of the device. • Suitable safety hardware and software measures should be implemented for the • Ensure that devices cannot be accidentally I/O interface so that a line or wire breakage restarted.
  • Page 4 • Measures should be taken to ensure the • Installations fitted with frequency inverters proper restart of programs interrupted must be provided with additional after a voltage dip or failure. This should monitoring and protective devices in not cause dangerous operating states even accordance with the relevant safety regulations etc.

  • Page 5: Table Of Contents

    Reversing starter without AGM auxiliary contacts Reversing starter with AGM auxiliary contacts Mounting / Dismounting Chapter Overview Mechanical Mounting – General Mounting Regulations – Mounting XStart Base Modules – Plugging the Performance Modules – Coding For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 6 Maximum Number of Modules Connection to a Moeller PLC PS4-341-MM1 with LE4-504-BS1 – Reading-in the GSD file – Configuring the XI/ON Station with XStart – Example of Diagnostics with a Moeller PLC PS4-341-MM1 Connection to a Siemens S7-300 PLC – Reading-in the GSD File –...
  • Page 7 11/01 AWB2700-1426GB Contents Appendix Glossary Abbreviations Ordering Information and Accessories – XStart – Accessories Index For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 8 11/01 AWB2700-1426GB For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 9: About This Manual

    This manual contains detailed information about mounting / dismounting as well as electrical installation of motor star- ters from the XStart series. It is valid only in conjunction with the manual „XI/ON PROFIBUS-DP", AWB2700-1394GB. All descriptions, safety and warning notes as well as all...

  • Page 10: Prescribed Use

    In accordance with DIN VDE 0105-100 only qualified electricians or personnel that have received electrotech- nical instructions are permitted to carry out the electrical installation and commissioning of XStart. For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 11: Explanation Of The Symbols Used

    11/01 AWB2700-1426GB Explanation of the Symbols Used Explanation of the Symbols Used This sign can be found next to all warning notes that indi- cate a safety hazard. This can relate to probable danger to personnel or damage to the system (hardware and software).
  • Page 12 11/01 AWB2700-1426GB For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 13: Introduction To Xstart

    11/01 AWB2700-1426GB 1 Introduction to XStart Chapter Overview This chapter describes the basic features of XStart and contains an overview of the XStart components. The Basic Concept The XStart Components – Direct starter – Reversing starter – Base module – Accessories for distribution of power...
  • Page 14 • Reversing starters with AGM auxiliary contacts • Reversing starters without AGM auxiliary contacts The XStart modules are made up of a base module and a performance module. This performance module contains the successful motor-protective circuit-breaker PKZM0 as well as one or two contactors.
  • Page 15 XStart reversing starter module Flexibility You can adapt XStart to exactly match your plant. XStart can be added to any point on your XI/ON station, which enables you to divide your station into plant areas of applications to suit your needs.

  • Page 16: The Xstart Components

    11/01 AWB2700-1426GB Introduction to XStart Easy to operate All XStart modules are made up of a base module and a performance module. To mount, simply press the complete module on to the two top-hat rails. The base module can be mounted first, and the performance module added later.

  • Page 17: Direct Starter

    11/01 AWB2700-1426GB The XStart Components Direct starter The direct starter is composed of a PKZM0 motor starter and a DILEM contactor to turn the motor on and off. It is used to both control and monitor the connected motor as well as to route the main and auxiliary power.

  • Page 18: Reversing Starter

    11/01 AWB2700-1426GB Introduction to XStart Reversing starter The reversing starter is composed of a PKZM0 motor starter and two DILEM contactor one for the right-handed and one for the left-handed rotation of the motor. It is used to both control and monitor the connected motor as well as to route the main and auxiliary power.

  • Page 19: Base Module

    11/01 AWB2700-1426GB The XStart Components Base module The base module is used for fixing the performance module to the top-hat rails. It contains the electronics, which monitor and the correct functioning of the performance module generate error or diagnostic messages when neces- sary.

  • Page 20: Accessories For Distribution Of Power

    To reduce wiring costs, accessories are available for distribu- tion of power. Should it be planned to mount several XStart modules next to one another, the power can be supplied via a power supply terminal. This power distributor is available for opera- ting currents up to a maximum of 63 A.

  • Page 21: Technical Data

    11/01 AWB2700-1426GB 2 Technical Data Chapter Overview You can find the following subjects in this chapter: Introduction Dimensions General Technical Data Diagnostic Messages of the Performance Module Module Parameters Direct Starter Without AGM Auxiliary Contacts Direct Starter With AGM Auxiliary Contacts Reversing starter without AGM auxiliary contacts Reversing starter with AGM auxiliary contacts For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 22: Introduction

    Technical Data Introduction This chapter contains the technical data and additional infor- mation for the individual XStart modules. The chapter is composed of the general technical data, the description of the individual modules, wiring and electrical circuit diagrams as well as information concerning para- meter and diagnostic options.
  • Page 23 The module abbreviations are explained as follows: Table 1: Legend of module abbreviations Abbreviations Description Example Performance module XS1-DS0-340-K06 System identification for XStart Function of the performance module: Direct starter XS1-DS0-340-K06 Function of the performance module: Reversing starter XS1-RS0-340-K06 Function of the performance module: Standard XS1-DS0-340-K06...
  • Page 24 11/01 AWB2700-1426GB Technical Data The following abbreviations are used in the technical data and wiring diagrams: Table 2: Technical abbreviations and symbols Abbreviation Designation Rated operational current Nominal current via supply terminal Nominal current via the module bus Rated conditional short-circuit current Rated uninterrupted current L1, 2, 3 Phase conductor 1, 2, 3...

  • Page 25: Dimensions

    11/01 AWB2700-1426GB Dimensions Dimensions Dimensions for direct starter The dimensions relate to the complete module (performance module including base module). Dimensions in mm/inch (W x L x H) without AGM auxiliary detector 45 x 128 x 300 / 1.77 x 5.04 x 11.81 with AGM auxiliary detector 90 x 128 x 300 / 3.54 x 5.04 x 11.81...
  • Page 26 11/01 AWB2700-1426GB Technical Data Dimension drawings All dimensions are shown in mm. Figure 7: Front view of direct starter without AGM Figure 8: Front view of direct starter with AGM For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 27 11/01 AWB2700-1426GB Dimensions Figure 9: Front view of reversing starter with / without AGM Figure 10: Side view of XStart complete with base module For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 28: General Technical Data

    Technical Data General Technical Data The detailed technical data for the PKZM0 and DILEM used in XStart can be found in the main catalogue, "Industrial Switching Devices", HPL0211-2002D, in chapter 05 for DILEM and 08 for PKZM0. Table 3: Technical Data for XStart...
  • Page 29 11/01 AWB2700-1426GB General Technical Data General Information Tightening torque of the connection screws 1.7 Nm Mechanical lifespan of the DILEM contactors 10 x 10 Main supply circuit Rated operational voltage U 415 V AC Rated operational power P see Ordering Information Rated insulation voltage U 690 V Rated conditional short-circuit current I...

  • Page 30: Diagnostic Messages Of The Performance Module

    11/01 AWB2700-1426GB Technical Data Diagnostic Messages of The performance module has two LEDs on the front „RUN" the Performance Module and "ERROR", with the aid of which different operating statuses or faults can be indicated. ERROR Figure 11: LEDs for indicating diagnostics For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 31: Diagnostic Messages Of The Performance Module

    11/01 AWB2700-1426GB Diagnostic Messages of the Performance Module Table 4: Diagnostic messages via LED Display Operating Meaning Remedy mode Green, flashing, Start standby Normal operation , PKZM0 0.5 Hz mode is ON, DILEM is OFF Green Normal Normal operation , PKZM0 operation is ON, DILEM is ON PKZM0 is switched off;...

  • Page 32: Module Parameters

    11/01 AWB2700-1426GB Technical Data Module Parameters The following parameters can be set for XStart: Table 5: Parameters for XStart Parameter name Value Kind of power module Direct -on-line-starter Reversing-starter Trip indicating AGM without AGM with AGM Power level 0.06 kW 0.09 kW...
  • Page 33 11/01 AWB2700-1426GB Module Parameters The value of the parameter „accepted highes kW ratings" means by how many performance classes the performance module used can deviate upwards. Downward deviations are generally only permissible if the value „Ident-bypass" has been set in the process data. The parameter „AGM: accepted deviation"...

  • Page 34: Direct Starter Without Agm Auxiliary Contacts

    11/01 AWB2700-1426GB Technical Data Direct Starter Without AGM Auxiliary Contacts Figure 12: Direct starter without AGM Logic Galvanic isolation 24 V DC Auxiliary connection Galvanic isolation PKZMO DILEM Field Figure 13: Block diagram For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 35 11/01 AWB2700-1426GB Direct Starter Without AGM Auxiliary Contacts Table 6: Module overview Designation Rated Rated Rated uninter- Classification operational operational rupted current I type power P current I at 400 V AC at 400 V AC at 400 V AC XS1-DS0-340-K06 0.06 kW 0.21...
  • Page 36 11/01 AWB2700-1426GB Technical Data Wiring diagram U V W Figure 15: Wiring diagram direct starter without AGM XS1-DS0-340-xKx For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 37: Direct Starter With Agm Auxiliary Contacts

    11/01 AWB2700-1426GB Direct Starter With AGM Auxi- liary Contacts Direct Starter With AGM Auxiliary Contacts Figure 16: Direct starter with AGM Logic Galvanic isolation 24 V DC Auxiliary connection Galvanic isolation PKZMO DILEM with AGM Field Figure 17: Block diagram For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 38 11/01 AWB2700-1426GB Technical Data Table 7: Module overview Designation Rated Rated Rated uninter- Classification operational operational rupted current I type power P current I at 400 V AC at 400 V AC at 400 V AC XS1-DS0-341-K06 0.06 kW 0.21 0.25 XS1-DS0-341-K09 0.09 kW...
  • Page 39 11/01 AWB2700-1426GB Direct Starter With AGM Auxi- liary Contacts Wiring diagram U V W Figure 19: Wiring diagram direct starter with AGM XS1DS0-341-xKx For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 40: Reversing Starter Without Agm Auxiliary Contacts

    11/01 AWB2700-1426GB Technical Data Reversing starter without AGM auxiliary contacts Figure 20: Reversing starter without AGM Logic Galvanic isolation 24 V DC Auxiliary connection Galvanic isolation PKZMO DILEM DILEM Field Figure 21: Block diagram For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 41 11/01 AWB2700-1426GB Reversing starter without AGM auxiliary contacts Table 8: Module overview Designation Rated Rated Rated uninter- Classification operational operational rupted current I type power P current I at 400 V AC at 400 V AC at 400 V AC XS1-RS0-340-K06 0.06 kW 0.21...
  • Page 42 11/01 AWB2700-1426GB Technical Data Wiring diagram U V W Figure 23: Wiring diagram reversing starter without AGM XS1-RS0-340-xKx For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 43: Reversing Starter With Agm Auxiliary Contacts

    11/01 AWB2700-1426GB Reversing starter with AGM auxiliary contacts Reversing starter with AGM auxiliary contacts Figure 24: Reversing starter with AGM Logic Galvanic isolation 24 V DC Auxiliary connection Galvanic isolation PKZMO DILEM DILEM with AGM Field Figure 25: Block diagram For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 44 11/01 AWB2700-1426GB Technical Data Table 9: Module overview Designation Rated Rated Rated uninter- Classification operational operational rupted current I type power P current I at 400 V AC at 400 V AC at 400 V AC XS1-RS0-341-K06 0.06 kW 0.21 0.25 XS1-RS0-341-K09 0.09 kW...
  • Page 45 11/01 AWB2700-1426GB Reversing starter with AGM auxiliary contacts Base module Figure 26: Base module XS1-XBMS-RS0-A Wiring diagram U V W Figure 27: Wiring diagram reversing starter with AGM XS1-RS0-341-xKx For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 46 11/01 AWB2700-1426GB For Immediate Delivery call KMParts.com at (866) 595-9616...

  • Page 47: Mounting / Dismounting

    Chapter Overview You can find the following subjects in this chapter: Chapter Overview Mechanical Mounting – General Mounting Regulations – Mounting XStart Base Modules – Plugging the Performance Modules – Coding Maximum Number of Modules Dismounting – Dismounting XStart Modules –...
  • Page 48 • These two top hat rails have a concentric distance of 125 mm / 4.92 inch. • It is not necessary to supply XStart with 24 V DC auxiliary voltage via a separate power distribution module. If however a potential isolation to the remaining XI/ON modules is required, a power distribution module can be mounted before the first XStart module from the left.
  • Page 49 11/01 AWB2700-1426GB Mechanical Mounting Mounting rails To mount XStart, a second mounting rail is required to be mounted at a concentric distance of 125 mm / 4.92 inch below the mounting rail for the XI/ON station. Both moun- ting rails should be mounted on the same mounting plate.
  • Page 50 11/01 AWB2700-1426GB Mounting / Dismounting Figure 30: Front view of direct starter without AGM auxiliary detector Figure 31: Front view of direct starter with AGM, reversing starter with and without AGM For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 51 XI/ON modules to the left of the XStart modules. • If you wish to extend an existing XI/ON station with XStart modules, you must first remove the end plate along with the end bracket. The procedure for their removal is described in the section "Dismounting from the Mounting...
  • Page 52 Repeat the steps if you wish to mount further XStart modules. Plugging the Performance Modules • The appropriate XStart base module must already be mounted. It is recommended to blow clean the station using compressed air before plugging the performance modules.
  • Page 53 The circuit-breaker on the XStart module must be set to „OFF" when the performance module is being mounted. For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 54 Coding The coding of the base module and the corresponding performance module is done electronically: Appropriate parameterization of the XStart module allows you to determine which type of performance module with which performance class can be operated by the correspon- ding base module.
  • Page 55 11/01 AWB2700-1426GB Maximum Number of Modules Maximum Number of A maximum of 20 XStart modules can be used in a XI/ON Modules station as direct starters without AGM auxiliary detectors. The following table offers an overview of the maximum number of different XStart module types, on condition that...
  • Page 56 Dismounting XStart Modules Please observe: • You can remove the XStart modules as a complete module. • You can remove the performance module first and then remove the base module. The appropriate procedures are described in the following sections.
  • Page 57 30 mm. Push the XStart module upwards until you notice a firm resistance. Tilt the top of the XStart module towards you and away from the mounting rail. Remove the XStart module from the mounting rail. Dismounting Performance Modules Please observe: No tools are required to dismount the performance modules.
  • Page 58 11/01 AWB2700-1426GB Mounting / Dismounting Proceed as follows to dismount the XStart perfor- mance modules: Figure 35: Dismounting the performance modules - step 1 Open both retaining brackets on the upper and lower ends of the performance module upwards. The performance module is no longer fixed to the base module.
  • Page 59 11/01 AWB2700-1426GB Dismounting Figure 37: Removing the performance module from the base module Close both retaining brackets on the upper and lower ends of the performance module. This unlocks the performance module. The performance module is removed by holding it at both ends and squarely pulling it away from the base module.
  • Page 60 11/01 AWB2700-1426GB Mounting / Dismounting Dismounting Base Modules Follow the procedure described in the section „Dismounting XStart Modules" to dismount base modules. For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 61 You can find the following subjects in this chapter Chapter Overview General Notes Potential Relationships Electromagnetic Compatibility – Ensuring Electromagnetic Compatibility – Grounding of Inactive Metal Components Wiring – Wiring an XStart Module – Wiring Several XStart Modules For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 62 The potential relationships of a XI/ON station are characte- rized by the following features: • The system's joint power supply to the XI/ON gateway, XI/ON I/O modules and XStart modules as well as the field supply for the XI/ON I/O modules is distributed via the Bus Refreshing module.
  • Page 63 The following block diagram represents the possible arran- gement of a typical XI/ON station with XStart modules. Figure 39: Block diagram of a XI/ON station with XStart modules Please refer to chapter 7 of the „XI/ON PROFIBUS-DP" manual for further notes concerning potential relation- ships in a XI/ON station.
  • Page 64 11/01 AWB2700-1426GB Electrical Installation Ensuring Electromagnetic Compatibility The EMC of XI/ON modules is guaranteed if the following basic rules are adhered to during installation: • Correct and large surface grounding of inactive metal components • Correct shielding of cables and devices •...
  • Page 65 11/01 AWB2700-1426GB Electromagnetic Compatibility Earth-Free Operation Observe all relevant safety regulations when operating an earth-free system. Protect against high frequency interference signals In order to comply with radiation limit values in accor- dance with EN 55011/ 2000, the supply cables of the module XN-BR-24VDC-D for supplying the gateway with power are to be fed through a ferrite ring (PS416-ZBX- 405).
  • Page 66 The auxiliary circuit is automatically created following the mounting of base and performance modules. Wiring an XStart Module The power supply to the XStart module is fed from above via three conductors. The connection is achieved via screw terminals.
  • Page 67 For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 68 Three-phase commoning link for up to 4 direct starters without AGM auxiliary contacts. c Direct starter without AGM auxiliary contact Several XStart modules can be supplied with power via a joint three-phase commoning link. This requires the power supply to be applied only once via the power supply terminal.
  • Page 69 Maximum Number of Modules Connection to a Moeller PLC PS4-341-MM1 with LE4-504-BS1 – Reading-in the GSD file – Configuring the XI/ON Station with XStart – Example of Diagnostics with a Moeller PLC PS4-341-MM1 Connection to a Siemens S7-300 PLC – Reading-in the GSD File –...
  • Page 70 Please refer to the manual „XI/ON PROFIBUS-DP", AWB2700-1394GB for further information concerning PROFIBUS-DP and XI/ON. The connections of XStart to a Moeller PLC and a Siemens PLC are described. Designations for hardware and software used in this chapter are registered and protected trademarks of the respective manufacturer.
  • Page 71 PROFIBUS-DP Standard. XStart is available only in the module description according to type version. That means, the XStart modules are depicted with a special identification format. This enables an exact identification of the XStart modules. The XI/ON gateway will accept replacement modules of an identical type only.
  • Page 72 11/01 AWB2700-1426GB Connection to PROFIBUS-DP Parameterization for Each XStart module requires 3 bytes of parameters in the XStart PROFIBUS-DP telegram. The following table shows the struc- ture of these 3 bytes. Table 11: Parameters for XStart Byte Parameter name Value...
  • Page 73 PROFIBUS-DP master used. Diagnostic Messages for XStart modules require 1 byte for diagnostic data in a XStart PROFIBUS-DP telegram. The following table shows the struc- ture of this diagnostic byte:...
  • Page 74 11/01 AWB2700-1426GB Connection to PROFIBUS-DP Process Data XStart has 1 byte of input data and 1 byte of output data available. The following table shows the respective struc- ture: Table 13: Process data Process data Contents Value Meaning Input data...
  • Page 75 A XI/ON station can consist of a XI/ON gateway, a Bus Modules Refreshing module and a maximum of 20 XStart modules as direct starters without AGM auxiliary detectors. The follo- wing table offers an overview of the maximum number of...
  • Page 76 11/01 AWB2700-1426GB Connection to PROFIBUS-DP Connection to a Moeller The following describes the integration of XStart in a XI/ON PLC PS4-341-MM1 with station that is connected to a Moeller PLC PS4-341-MM1 via LE4-504-BS1 the local expansion module LE4-504-BS1. The Moeller configuration software „CFG-DP", version 2.0 is used to configure the XI/ON station in this example.
  • Page 77 Connection to a Moeller PLC PS4-341-MM1 with LE4-504- Configuring the XI/ON Station with XStart Proceed as follows to insert your XStart modules in a new or in an existing XI/ON station: Double click the corresponding XI/ON station or insert an new XI/ON station in your fieldbus structure.
  • Page 78 LE4-504-BS1. The diagnostics are described in the dialog box „Extended Device Diagnostic": Figure 45: Diagnostic description of a XI/ON station with XStart a Diagnostic bytes 0 to 2 b Diagnostic bytes 9 to 12...
  • Page 79 9 to 12 Diagnostic bytes of the modules capable see section „Diagnostic Messages of diagnosis in the XI/ON station (Bus for XStart" in this chapter as well Refreshing module, 3 XStart modules) as chapter 4 of the manual „XI/ON PROFIBUS-DP"...
  • Page 80 11/01 AWB2700-1426GB Connection to PROFIBUS-DP Connection to a Siemens The following describes the integration of XStart in a XI/ON S7-300 PLC station that is connected to a Siemens S7-300 PLC. The software package „SIMATIC Manager" Version 5.0.5.0 from Siemens is used in this example.
  • Page 81 Connection to a Siemens S7- 300 PLC Configuring the XI/ON Station with XStart Proceed as follows to insert your XStart modules in a new or in an existing XI/ON station: Select the corresponding XI/ON station in the PROFIBUS- DP structure or insert a new XI/ON station.
  • Page 82 Setting the Parameters for XStart Modules Double-click the corresponding entry in the module list to open the DP Slave Properties dialog box of an XStart module. It is possible to set various parameters in this dialog box: Figure 47: Parameterization of an XStart module...
  • Page 83 11/01 AWB2700-1426GB Connection to a Siemens S7- 300 PLC The individual diagnostics are shown in a table of variables. Example: Figure 48: Diagnostics description in the software STEP 7 - table of variables For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 84 11/01 AWB2700-1426GB Connection to PROFIBUS-DP The operands have the following meanings: Table 16: Operands legend Operand Status value Meaning DB101.DBW PLC- internal information DB101.DBW PLC- internal information DB99.DBB 2072 B#16#08 Station status byte 1 DB99.DBB 2073 B#16#0C Station status byte 2 DB99.DBB 2074 B#16#00 Station status byte 3...
  • Page 85 11/01 AWB2700-1426GB Appendix Glossary Trip-indicating auxiliary contact, additional switch with which a PKZM0 can be extended Ambient temperature, open Temperature of the room (for example, workshop, swit- (see IEV 441-11-13) chroom) in which the switching device is installed. Back-of-hand proof A switching device whose electrically live parts cannot be touched within in an imaginary sphere with a diameter of 50 mm is said to be back-of-hand proof.
  • Page 86 11/01 AWB2700-1426GB Appendix Overvoltage category Code number for overvoltages, for example, due to light- (see IEC/EN 60 947-1) ning strike or switching operations that can possible occur at the point of installation. Industrial switching devices are covered by overvoltage category III. In accordance with the overvoltage categories, the use of switching devices is permissible in the following areas of applications: Overvoltage category IV:...
  • Page 87 11/01 AWB2700-1426GB Glossary Protection against direct contact Protective measures incorporated in the design, which prevent direct touch (without tools) of live plant compon- ents (safe from finger touch, back-of-hand proof). Rated conditional short-circuit Short-circuit current that can be carried through a short- current I (see IEC/EN 60 947-1 / IEV circuit safety facility, for example, a switching device...
  • Page 88 11/01 AWB2700-1426GB Appendix Shock resistance Characteristic of a switching device, to survive sudden movements without alterations to the operating status and without damage. The contacts of switching devices that are in operation are not allowed to lift; the main contacts of switches that are not in operation are not allowed to hit together.
  • Page 89 Abbreviations Tabelle 17: Legend of module abbreviations Abbreviations Description Example Performance module XS1-DS0-340-K06 System identification for XStart Function of the performance module: Direct starter XS1-DS0-340-K06 Function of the performance module: Reversing XS1-RS0-340-K06 starter Function of the performance module: Standard XS1-DS0-340-K06...
  • Page 90 11/01 AWB2700-1426GB Appendix Ordering Information and XStart Accessories Base modules XS1-XBMS-DS0-A XS1-XBMS-RS0-A Performance modules Direct starter without AGM XS1-DS0-340-K06 XS1-DS0-340-K09 XS1-DS0-340-K18 XS1-DS0-340-K25 XS1-DS0-340-K55 XS1-DS0-340-K75 XS1-DS0-340-1K5 XS1-DS0-340-2K2 Direct starter with AGM XS1-DS0-341-K06 XS1-DS0-341-K09 XS1-DS0-341-K18 XS1-DS0-341-K25 XS1-DS0-341-K55 XS1-DS0-341-K75 XS1-DS0-341-1K5 XS1-DS0-341-2K2 For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 91 11/01 AWB2700-1426GB Ordering Information and Accessories Base modules XS1-XBMS-DS0-A XS1-XBMS-RS0-A Performance modules Reversing starter without AGM XS1-RS0-340-K06 XS1-RS0-340-K09 XS1-RS0-340-K18 XS1-RS0-340-K25 XS1-RS0-340-K55 XS1-RS0-340-K75 XS1-RS0-340-1K5 XS1-RS0-340-2K2 Reversing starter with AGM XS1-RS0-341-K06 XS1-RS0-341-K09 XS1-RS0-341-K18 XS1-RS0-341-K25 XS1-RS0-341-K55 XS1-RS0-341-K75 XS1-RS0-341-1K5 XS1-RS0-341-2K2 For Immediate Delivery call KMParts.com at (866) 595-9616...
  • Page 92 11/01 AWB2700-1426GB Appendix Accessories Designation Type Mechanical accessories Lockable finger-grip knob for locking the XStart module as a main switch in AK-PKZ0 accordance with VDE 0113 Sealing device to protect against manipulation, sealable with commercially PL-PKZ0 available seal wire Electrical accessories Three-phase commoning link for 2 direct starters without AGM B3.0/2-PKZ0...
  • Page 93 11/01 AWB2700-1426GB Index Index AGM ............13, 14, 29 auxiliary circuit ..........25, 62 auxiliary contact ..........13, 14 base module ..........12, 15, 47 circuit-breaker .............49 coding ............15, 50 contactor ............13, 14 diagnostic bytes ..........75, 80 diagnostic messages ..........69 diagnostic messages via LED .......27 DILEM ............13, 14 dimension drawings ........22, 45 dimensions ............21...
  • Page 94 11/01 AWB2700-1426GB Index ferrite ring ............61 grounding ............60 GSD ..............66 LEDs for indicating diagnostics ......26 main supply circuit ........25, 62 maximum number of modules ......71 module parameters ..........28 motor starter ..........13, 14 mounting rails ..........44, 61 normal operation ..........27 parameters ............28, 68 performance class .........29, 50 performance module .......12, 48, 54...
  • Page 95 11/01 AWB2700-1426GB Index technical data ............24 three-phase commoning ........64 three-phase commoning link .......16 touch potential ............60 trip-indicating ..........13, 14 XStart module .............10 For Immediate Delivery call KMParts.com at (866) 595-9616...
