Pinnacle Protemp PT-170T-IDF-EU User's Manual And Operating Instructions

Pinnacle Protemp PT-170T-IDF-EU User's Manual And Operating Instructions

Advertisement

CONSUMER: READ AND SAVE THESE INSTRUCTIONS
GENERAL HAZARD WARNING:
DANGER
READ AND UNDERSTAND ALL OF THE INSTRUCTIONS IN THIS MANUAL
BEFORE ASSEMBLING, STARTING, OR SERVICING THE HEATER. Be sure to comply with the
instructions and warnings provided with this heater. Failure to comply can result in fire or explosion
that can cause property loss, bodily injury, or loss of life. Only persons who can follow and
understand these instructions should operate or service this heater.
NOT FOR USE IN RESIDENTIAL LIVING AREAS OR IN ENCLOSED SPACES
DANGER
WITHOUT ADEQUATE VENTILATION. INDOOR USE PERMITTED ONLY FOR
THE TEMPORARY HEATING OF BUILDINGS OR STRUCTURES UNDER CONSTRUCTION,
ALTERATION OR REPAIR. This is an unvented portable heater that uses air (Oxygen) from within
the area in which it is used. Failure to provide adequate combustion and ventilation air will result in
asphyxiation, carbon monoxide poisoning, bodily injury or death. Refer to "Ventilation" on Page 8-9
This appliance shall be installed in accordance with the rules in force,
WARNING
and used only in sufficiently ventilated space. Consult instructions before
installation and use of this appliance.
Fax: (215)-891-8461
Model Numbers
PT-100T-IDF-EU / PT-170T-IDF-EU
© 2014 Pinnacle Products International, Inc.
668 Stony Hill Road #302 Yardley, PA 19067 USA
• Web: www.protemp-intl.com • Email: info@pinnacleint.com
User's Manual &
Operating Instructions
®
732000001-14

Advertisement

loading
Need help?

Need help?

Do you have a question about the Protemp PT-170T-IDF-EU and is the answer not in the manual?

Questions and answers

Summary of Contents for Pinnacle Protemp PT-170T-IDF-EU

  • Page 1 WARNING and used only in sufficiently ventilated space. Consult instructions before installation and use of this appliance. © 2014 Pinnacle Products International, Inc. 668 Stony Hill Road #302 Yardley, PA 19067 USA Fax: (215)-891-8461 • Web: www.protemp-intl.com • Email: info@pinnacleint.com...
  • Page 2: Table Of Contents

    Read The Instruction manual: When this symbol is WARNING! Never touch heater until heater marked on a product, it means that the instruction has cooled off. manual must be read. © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 3: Safety Information

    Btu / Hr heater rating. Refer to “Ventilation” on once it is plugged in, it can start at anytime in page 8-9 for further instructions. accordance with the thermostat setting. © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 4 Models: PT-170T-IDF-EU Exhaust Vent Handle Upper Shell Hot Air Outlet Extension Cord Wrap Lower Shell Fuel Cap Drain Plug Fuel Tank Thermostat Knob Power Switch Figure 2 LED Displays © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 5 38 mm Screws (6) Nuts (10) Lock Washers (10) Flat Washers (10) Axle Nuts (2) Spacers (2) Axle (1) Cord Wraps (2) Wheels (2) Wheel Frame (1) Handle (1) © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 6 NOTE: Use lock washers and flat washers as shown in figure 4 to secure the wheel frame and handle to the tank. Figure 4 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 7 38 mm Screws (4) Nuts (12) Lock Washers (12) Flat Washers (12) Axle Nuts (2) Spacers (2) Cord Wraps (2) Wheels (2) Wheel Frame (1) Handle (1) Axle (1) © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 8 NOTE: Use lock washers and flat washers as shown in figure 6 to secure the wheel frame and handle to the tank. Figure 6 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 9: Operation

    NOTE: Paraffin should only be stored in a blue with other fuel types. container that is clearly marked “Paraffin.” Never store paraffin in a red container. Red is associated with gasoline. © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 10: Ventilation

    Follow the ventilation configurations below to properly vent your heater for indoor use. MIN 4M MAX 8M MIN 5M 100° MIN 2M MIN 4.5M 120° © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 11 7. The heater will ignite once the setting temperature is higher than the ambient room temperature. Control Panel Setting Temperature Room Temperature Power Switch Thermostat Knob Figure 7 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 12: Maintenance

    To clean dirt from nozzle, blow compressed air through nozzle front. It may be necessary to soak the nozzle in paraffin to loosen any dirt particles. © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 13: Wiring Diagram

    NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® Wiring Diagram THERMOSTAT EARTH LINE IGNITOR SOLENOID 230V ~ 50Hz MOTOR NEUTRAL POWER SWITCH TEMPERATURE SENSOR PHOTOCELL Figure 10 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 14: Troubleshooting Guide

    3. Fuse is blown. connection and test the power 4. Improper electrical connection supply. between temperature limit sensor 3. Check / replace the fuse. and circuit board. 4. Inspect all electrical connections. © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 15: Exploded View

    NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® Exploded View - 100T-IDF © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 16 NEVER LEAVE HEATER UNATTENDED WHILE BURNING OR WHILE CONNECTED TO A POWER SOURCE ® Exploded View - 170T-IDF © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 17: Parts List

    73-001-0200 Air Outlet 73-001-0355 Ceramic Fiber Bracket 73-010-1101 Ceramic Fiber Fixed Support 73-010-1201 Ceramic Fiber 73-010-1001 Upper Front Shell 73-001-0102 Combustion Chamber 73-010-0102 Exhaust Hood / Flue Collar 73-010-0152 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 18 Rear Guard 73-016-0052 Fuel Filter Joint 2 73-003-2001 Sleeve 73-020-2001 Motor 73-020-1000 Motor Support 73-020-0103 Pump 73-020-0151 Back Frame 73-041-1001 Cord Holder 73-041-1002 Oil Pipe 73-003-0132 Back Support 73-041-0115 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 19 Front Support 73-041-0112 Bottom Shell 73-001-0201 Air Outlet 73-001-0351 Ceramic Fiber Bracket 73-010-1100 Ceramic Fiber Fixed Support 73-010-1200 Ceramic fiber 73-010-1000 Upper Front Shell 73-001-0101 Shell Support Ring 73-001-1000 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
  • Page 20 Back Frame 73-041-0102 Cord Holder 73-041-0103 Power Cord 73-034-0100 Lock 73-003-1200 Oil Pipe 300 mm 73-003-0302 Oil Pipe 350 mm 73-003-0301 Oil Pipe 400 mm 73-003-0300 Back Support 73-041-0113 © 2014, Pinnacle Products International, Inc. Indirect Fired Heater User’s Manual...
