Bauer Ecostar 6000 Update Manual

Hide thumbs Also See for Ecostar 6000:
1
2
3
4
5
6
7
8
9
Table of Contents

Advertisement

Quick Links

Download this manual
Ecostar 6000
Update Guide
c Bauer GmbH
V3.0

Advertisement

Chapters

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ecostar 6000 and is the answer not in the manual?

Questions and answers

Related Manuals for Bauer Ecostar 6000

Summary of Contents for Bauer Ecostar 6000

  • Page 1 Ecostar 6000 Update Guide c Bauer GmbH V3.0...

  • Page 2: Table Of Contents

    Contents Attention ..............................1 Software Update ............................. 2 Possibility 1 ............................2 Step1: Preparing the USB stick ......................2 Step2: Disconnect the power supply ....................3 Step3: Plug in the USB stick ......................3 Step 4: Plug in the power supply ..................... 4 Step 5: Remove USB stick / power reset ..................

  • Page 3: Software Update

    There are two possibilities to update the Ecostar. The following steps describes how to make a successful update. Possibility 1 Step1: Preparing the USB stick Download the actual version from the homepage e.g. “Ecostar 6000 VXX.XX.zip”. Unpack this file and copy the four files on an empty USB stick: Bios.inf Ecostar.bin EEPROM.BAK...

  • Page 4: Step2: Disconnect The Power Supply

    Step2: Disconnect the power supply Remove the plug of the at the battery or unplug the connector at the backside of the Ecostar6000 Figure 2 - Power supply Step3: Plug in the USB stick Plug in the USB stick at the USB port at the backside of the Ecostar6000. Figure 3 - USB stick Update Guide 08.

  • Page 5: Step 4: Plug In The Power Supply

    Step 4: Plug in the power supply After connecting the power supply the Ecostar6000 checks if there is an USB stick connected. If the USB stick is recognized, a special update melody comes up and the controller starts to update the software.

  • Page 6: Attention

    There is a second possibility to update the Ecostar if the update was not successful. Possibility 2 Step1: Preparing the USB stick Download the actual version from the homepage e.g. “Ecostar 6000 VXX.XX.zip”. Unpack this file and copy the four files on an empty USB stick: Bios.inf Ecostar.bin EEPROM.BAK...

  • Page 7: Step2: Plug In The Usb Stick

    Step2: Plug in the USB stick Plug in the USB stick at the USB port at the backside of the Ecostar6000. Figure 8 - USB stick If the USB stick was recognized the USB symbol is shown at the right corner. Figure 9 - USB symbol Step3: Backup Menu Press “Menu”...

  • Page 8: Step 5: Remove Usb Stick / Power Reset

    Figure 10 – Backup page 2 Press „restart“, a special update melody comes up and the controller starts to update the software. During the update the display is black but at the back there should flushing three led’s. Figure 11 - LED's flushing The update is ready when the homescreen is shown on the display.

  • Page 9: Step6: Check The Software Version

    Step6: Check the software version Check if the correct version is installed. This information is available at “Menu” -> “Service / Info” -> “Info”. Figure 13 - installed SW version List of figures Figure 1 - Update Files ............................. 2 Figure 2 - Power supply ............................
