- Page 1 Ecostar 6000 Update Guide c Bauer GmbH V3.0...
-
Page 2: Table Of Contents
Contents Attention ..............................1 Software Update ............................. 2 Possibility 1 ............................2 Step1: Preparing the USB stick ......................2 Step2: Disconnect the power supply ....................3 Step3: Plug in the USB stick ......................3 Step 4: Plug in the power supply ..................... 4 Step 5: Remove USB stick / power reset .................. -
Page 3: Software Update
There are two possibilities to update the Ecostar. The following steps describes how to make a successful update. Possibility 1 Step1: Preparing the USB stick Download the actual version from the homepage e.g. “Ecostar 6000 VXX.XX.zip”. Unpack this file and copy the four files on an empty USB stick: Bios.inf Ecostar.bin EEPROM.BAK... -
Page 4: Step2: Disconnect The Power Supply
Step2: Disconnect the power supply Remove the plug of the at the battery or unplug the connector at the backside of the Ecostar6000 Figure 2 - Power supply Step3: Plug in the USB stick Plug in the USB stick at the USB port at the backside of the Ecostar6000. Figure 3 - USB stick Update Guide 08. -
Page 5: Step 4: Plug In The Power Supply
Step 4: Plug in the power supply After connecting the power supply the Ecostar6000 checks if there is an USB stick connected. If the USB stick is recognized, a special update melody comes up and the controller starts to update the software. -
Page 6: Attention
There is a second possibility to update the Ecostar if the update was not successful. Possibility 2 Step1: Preparing the USB stick Download the actual version from the homepage e.g. “Ecostar 6000 VXX.XX.zip”. Unpack this file and copy the four files on an empty USB stick: Bios.inf Ecostar.bin EEPROM.BAK... -
Page 7: Step2: Plug In The Usb Stick
Step2: Plug in the USB stick Plug in the USB stick at the USB port at the backside of the Ecostar6000. Figure 8 - USB stick If the USB stick was recognized the USB symbol is shown at the right corner. Figure 9 - USB symbol Step3: Backup Menu Press “Menu”... -
Page 8: Step 5: Remove Usb Stick / Power Reset
Figure 10 – Backup page 2 Press „restart“, a special update melody comes up and the controller starts to update the software. During the update the display is black but at the back there should flushing three led’s. Figure 11 - LED's flushing The update is ready when the homescreen is shown on the display. -
Page 9: Step6: Check The Software Version
If there is a big system update available for the Ecostar6000 it is also necessary to install or to update the language files. For this the newest versions are available to download at the Bauer homepage. Step1: Preparing the USB stick Download the actual version from the homepage e.g. -
Page 10: Step3: Plug In The Usb Stick
Figure 15: Sytem setting Press button next „select language Figure 16 - change language The list of all imported language appears -> delete the selected language by pressing “delete” Figure 17 - delete language After pressing delete the Ecostar is making a reset, this can take several seconds. Step3: Plug in the USB stick Plug in the USB stick at the USB port at the backside of the Ecostar6000 Update Guide... -
Page 11: Step4: Import The New Language Files
Figure 18 - USB stick Step4: Import the new language files . At “Menu” -> “base setting” -> press button where the actual selected language is shown e.g. “Deutsch” Figure 19 - Base setting Press button next “import language” Figure 20 - import language The language files at the USB stick is shown in a list Update Guide 08. -
Page 12: Step5: Select The Language
Figure 21 - list of files Select the language file and press “import”. The import can take several seconds because the Ecostar6000 makes an software reset. Step5: Select the language After the newest language version is installed it only has to change to this newest version. This can be done at the language menu by pressing the button next to “select language”... -
Page 13: List Of Figures
List of figures Figure 1 - Update Files ............................. 2 Figure 2 - Power supply ............................3 Figure 3 - USB stick ..............................3 Figure 4 - LED's flushing ............................4 Figure 5 - homescreen ............................. 4 Figure 6 - installed SW version ..........................4 Figure 7 - Update Files .............................
