PWRLink™ II 4100S Series
Optical Transmitter
Product Manual
Manual Part No.: 700-0052017
Rev A
March 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PWRLink II 4100S Series and is the answer not in the manual?

Questions and answers

Related Manuals for Harmonic PWRLink II 4100S Series

Summary of Contents for Harmonic PWRLink II 4100S Series

  • Page 1 PWRLink™ II 4100S Series Optical Transmitter Product Manual Manual Part No.: 700-0052017 Rev A March 2006...
  • Page 2 Copyright 2006 Harmonic Inc Harmonic continues to improve and enhance all product designs. Specifications are subject to change without notice. Harmonic and logo design, eXchange, MAXLink, METROLink, NETWatch, PWRBlazer, TRANsend, and “Redefining the Network” are trademarks of Harmonic Inc. YAGLink and PWRLink are registered trademarks of Harmonic Inc.

  • Page 3: Table Of Contents

    Table of Contents Chapter 1 Overview About This Manual ..........1-1 Description .
  • Page 4 Disclaimer ............6-2 Appendix A Technical Specifications Appendix B HLP 4200WD Menu Display Appendix C Using Modulated Carriers Appendix D Harmonic Inc. – Offices Copyright © 2006 Harmonic Inc.

  • Page 5: Chapter 1 Overview

    Description The PWL 4100S transmitter is a compact plug-in module designed for use in the Harmonic HLP 4200 equipment platform. An HMC 4001 module carrier is needed to mount the transmitter in the platform. Harmonic has optimized the PWRLink II family of transmitter modules for high-performance transmission of RF broadband information over optical fiber networks.
  • Page 6 Transmitter performance is optimized by combining state-of-the-art 1310 nm distributed feedback (DFB) laser technology and patented pre-distortion linearization circuitry. Harmonic has designed the PWRLink II family for integration into networks with advanced element management systems; each transmitter module employs a microprocessor-based communication and monitoring architecture.
  • Page 7 Figure 1-2. PWL 4100S block diagram The PWL 4100S transmitter is a compact plug-in module that mounts easily in Harmonic’s HLP 4200 platform via the HMC 4001 module carrier. See Figure 1-3 for a functional diagram of the HLP 4200 platform. The transmitter module draws power from the platform’s 24 VDC power bus, and...

  • Page 8: Applications

    45 to 1003 MHz frequency band. The 1310 nm optical signal transmitted by a PWRLink II module can be received by optical receivers and nodes manufactured by Harmonic or other major broadband equipment manufacturers. To learn more about equipment compatibility and broadband network design and optimization, contact customer service.

  • Page 9: Chapter 2 Installing The Pwl 4100S Transmitter

    Save the shipping material for future use. If the container or the equipment is damaged, notify both the freight carrier and Harmonic. See Appendix D, Harmonic Inc. – Offices for contact information. CAUTION: Before removing equipment from its antistatic bag, touch a ground point for several seconds.
  • Page 10 +24 VDC bus of the HLP 4200. For additional information on the HLP 4200 platform, see the HLP 4200 Platform Product Manual. For additional information on platform controllers and/or power supply options, see the respective Harmonic manual for each component . 2–2...

  • Page 11: Connecting The Fiber Cable

    Section 2.2. 2. Determine the connector type on the PWL 4100S. The standard optical connector recommended by Harmonic is SC/APC. Other connector types can be special ordered. 3. Verify that the type of connector on the fiber cable is the same as what is on the PWL 4100S, for example, SC/APC.

  • Page 12: Connecting The Rf Broadband Input

    (female F-type) located on the front panel of the transmitter module, as shown in Figure 1-1 on page 1-2. The monitor level is 20 dB below the input level to the transmitter ±1 dB. 2–4 Copyright © 2006 Harmonic Inc.

  • Page 13: Chapter 3 User Interface Options

    PWL 4100S performance. The Autosetup and Reset to Factory Settings commands are available only through this interface. For initial setup of the transmitter, Harmonic recommends using the HLP 4200WD display, if available. • NETWatch Site Controller Element Management System Once installed and configured, NETWatch Site Controller provides a...

  • Page 14: Hlp 4200Wd Display

    NETWatch Site Controller. Instructions for navigating the Main menu are provided in Section 4.4.1 Step- by-Step Setup Instructions on page 4-7. Figure 3-1. HLP 4200WD platform Main menu display 3–2 Copyright © 2006 Harmonic Inc.
  • Page 15 HLP 4200WD Display After you navigate the HLP 4200WD’s Main menu and select a specific PWL 4100S module, the Transmitter menu appears. The Transmitter menu is organized into five sub-menus: • Transmitter Status • Transmitter Diagnostics • Transmitter Setup • Transmitter Adjustments •...
  • Page 16 User Interface Options Figure 3-2. HLP 4200WD platform Transmitter menu display chart 3–4 Copyright © 2006 Harmonic Inc.

  • Page 17: Transmitter Status

    HLP 4200WD Display 3.1.1 Transmitter Status The Transmitter Status menu lets you obtain the transmitter serial number, firmware version, and basic operating mode parameters. 3.1.2 Transmitter Diagnostics The Transmitter Diagnostics menu allows you to: • Determine the laser power • Determine the heat sink temperature 3.1.3 Transmitter Setup The Transmitter Setup menu allows you to:...

  • Page 18: Netwatch Site Controller

    NETWatch Site Controller Instruction Manual. Front Panel RF Adjustment NOTE: Harmonic recommends that you use the front panel RF Adjustment control only if the interface options described in Section 3.1 and Section 3.2 are not available.

  • Page 19: Chapter 4 Transmitter Setup

    • How to set up via NETWatch Site Controller • How to set up via the transmitter’s front panel controls NOTE: For initial setup of the transmitter, Harmonic recommends using the HLP 4200WD platform’s push buttons and display, if available. If...

  • Page 20: Factory-Optimized Settings

    Transmitter Setup Factory-Optimized Settings The Harmonic factory optimizes the performance of each model in the PWL 4100S series prior to shipment. The factory setup is listed in Table 4-1. Table 4-1: Factory Setup Loading 80 unmodulated System M (NTSC) channels from 45 to 550 MHz;...

  • Page 21: Fine-Tuning Each Transmitter

    8.5 dB. Fine-Tuning Each Transmitter Harmonic recommends fine-tuning each transmitter to fit your specific requirements and preferences precisely. You can modify the transmitter configuration to trade off CNR performance for improved CSO and CTB distortion performance.

  • Page 22: Autosetup, Automatic Gain Control, And Manual Gain Control

    Gain Control The Autosetup feature enables you to quickly set the internal drive level to the laser as close as possible to the optimal value determined at the Harmonic factory. The transmitter operates in either the Automatic Gain Control (AGC) mode or the Manual Gain Control (MGC) mode.
  • Page 23 Figure 4-2. RF drive level as a function of channel loading Even if you plan to add more video channels in the future, Harmonic recommends that you use 15 dBmV per channel to ensure that the system is easy to upgrade.

  • Page 24: Automatic Gain Control And Manual Gain Control

    When you select AGC, the input level to the transmitter laser remains at its previously established value. When you use AGC mode with the PWL 4100S, Harmonic recommends that you drive the transmitters 3 dB harder so that they can better compensate for the increased variation in the RF input signal.

  • Page 25: Setup Via Hlp 4200Wd Display

    Setup via HLP 4200WD Display Setup via HLP 4200WD Display This section provides instructions for setting up the PWL 4100S via the push buttons and LCD display of the HLP 4200WD equipment platform. To quickly and easily set up and review the PWL 4100S monitoring and control parameters, use the HLP 4200WD front panel.

  • Page 26: Fine-Tuning The Transmitter

    Fine-Tuning the Transmitter The setup instructions described in Section 4.4.1 will normally bring the transmitter to optimal operating conditions. Harmonic recommends fine- tuning each transmitter to your specific requirements and preferences. If the factory-optimized RF level is not suitable for your particular application, you can use the following procedure to adjust the internal RF pad.

  • Page 27: Setup Via Netwatch Site Controller

    first two setup options, described in Section 4.4 and Section 4.5, are not available. NOTE: For initial setup of the transmitter, Harmonic recommends that you use the HLP 4200WD platform display interface, if available, and that you follow the setup procedure in Section 4.4.
  • Page 28 4. Using the RF Adj control on the front panel, adjust the RF input level to the value given in Table 4-1, Factory Setup, on page 4-2. For further details on how to use the RF adjustment switch, see Section 3.3 Front Panel RF Adjustment on page 3-6. 4–10 Copyright © 2006 Harmonic Inc.

  • Page 29: Chapter 5 Maintenance

    (CNR) performance and, in some cases, distortion performance. Therefore, Harmonic recommends that you clean all mating fiber connectors, before connecting them to an optical device. In addition, if you suspect that the optical connector of a PWL 4100S may have been exposed to contamination (by a dirty fiber cable connector, for...

  • Page 30: Cleaning Patch Cord Or Pigtail Fiber Optical Connectors

    Should a fan failure occur, contact Harmonic’s technical service (see 6.2 In Case of Problems on page 6-1). To replace the fan: 1.
  • Page 31 Fan Replacement Phillips Screws Figure 5-1. HMC 4001 fan replacement PWRLink™ II 4100S Series Optical Transmitter Product Manual Rev A (3/06) 5–3...
  • Page 32 Maintenance 5–4 Copyright © 2006 Harmonic Inc.

  • Page 33: Chapter 6 Troubleshooting

    RMA number on the shipping container when returning the unit, and with all correspondence regarding the unit. To return the unit, send it to one of the Harmonic Headquarters addresses listed in Appendix D, Harmonic Inc. – Offices. Please add the note: Attn.: Customer Service...

  • Page 34: Disclaimer

    Harmonic assumes no responsibility or liability arising from the use of the products described herein, except as expressly agreed to in writing by Harmonic. The use and purchase of this product does not convey a license under any patent rights, copyrights, trademark rights, or any intellectual property rights of Harmonic.
  • Page 35 Appendix A Technical Specifications Link Performance Carrier-to-Noise (CNR): See Figure A-1 Carrier-to-CSO: >64 dB Carrier-to-CTB: >69 dB In Figure A-1, CNR and optical fiber loss are plotted against each other 1,3,4 for PWL 4100S series transmitters with 80 NTSC (System M) channels running.
  • Page 36 Input level range per unmodulated analog channel: 15 to 22 dBmV Operational bandwidth: 45 to 1003 MHz Frequency response: <1 dB peak-to-valley RF attenuator adjustment range: 10 dB Impedance: 75 ohm Return loss: >16 dB Level control: manual (MGC)/automatic (AGC); auto setup feature A–2 Copyright © 2006 Harmonic Inc.
  • Page 37 Technical Specifications User Interface Front panel Bi-state status LED: Normal = Green, Alarm = Red Module selection indicator: Yellow LED RF attenuation adjustment Monitor point: Flatness: ±0.5dB Return loss: >16 dB Connector type: Female F Level: -20 ±1.5 dB below input Rear panel RF input connector type: Female F Optical output (for connector types available, see Section A.8)
  • Page 38 = Connector Type: AS, AF, US, UF or AE AS = SC/APC AF = FC/APC US = SC/UPC UF = FC/UPC AE = E2000 SC/APC is the connector type recommended by Harmonic. Other connector types available upon request. A–4 Copyright © 2006 Harmonic Inc.
  • Page 39 Technical Specifications Laser Radiation Warning Complies with 21 CFR 1040.10 and 1040.11 except for deviations pursuant to Laser Notice No. 50, dated (July 26, 2001) as applicable to Class 1M Laser Products. This light emission device is classified to IEC 60825-1:1993 + A1 + A2 CAUTION: INVISIBLE LASER RADIATION.
  • Page 40 Harmonic will ensure that all products that cannot be re-used will be recycled in compliance with the WEEE Directive. To that end, users are advised that (1) Harmonic equipment is not to be discarded in household or office garbage, (2) customers may consult the Harmonic web site (www.harmonicinc.com) for additional and updated...

  • Page 41: Appendix B Hlp 4200Wd Menu Display

    Appendix B HLP 4200WD Menu Display Figure B-1 and Figure B-2 provide a flowchart of the commands and messages in the Transmitter Menu of the HLP 4200WD platform display. In these figures, push-button commands are framed in ovals, and resultant display messages are framed in rectangular boxes.
  • Page 42 HLP 4200WD Menu Display Figure B-1. HLP 4200WD platform Transmitter menu display, levels 0 and 1 B–2 Copyright © 2006 Harmonic Inc.
  • Page 43 HLP 4200WD Menu Display Figure B-2. HLP 4200 WD platform Transmitter menu display, level 2 PWRLink™ II 4100S Series Optical Transmitter Product Manual Rev A (3/06) B–3...
  • Page 44 HLP 4200WD Menu Display B–4 Copyright © 2006 Harmonic Inc.

  • Page 45: Appendix C Using Modulated Carriers

    This appendix provides information about setting up PWRLink™ II 4100S Series Optical Transmitters for use with modulated carriers. PWL 4100S transmitters are adjusted at the Harmonic factory for specified CNR, CSO and CTB using NTSC unmodulated carriers. When the carriers are modulated: •...
  • Page 46 However, Autosetup will not satisfy all applications. You also need to fine- tune the transmitter to fit your specific requirements and preferences precisely. You can accomplish this by adjusting the pad manually after following the Autosetup procedure. See Chapter 4, Transmitter Setup. C–2 Copyright © 2006 Harmonic Inc.
  • Page 47 Using Modulated Carriers Figure C-1. RF spectrum with modulated carriers PWRLink™ II 4100S Series Optical Transmitter Product Manual Rev A (3/06) C–3...
  • Page 48 Using Modulated Carriers C–4 Copyright © 2006 Harmonic Inc.

  • Page 49: Appendix D Harmonic Inc. - Offices

    Appendix D Harmonic Inc. – Offices Assistance For technical support and customer service, call toll free: 800.730.4099. Harmonic’s web address is www.harmonicinc.com. Worldwide Technical Support and Asia Pacific Headquarters Return Materials Authorization Harmonic Limited Suite 703-704, CMG Asia Tower Tel: 1.800.730.4099 (inside U.S.)
  • Page 50 Harmonic Inc. – Offices D–2 Copyright © 2006 Harmonic Inc.

This manual is also suitable for:

Pwl 4105sPwl 4102sPwl 4103sPwl 4108sPwl 4107sPwl 4106s ... Show all
