Instructions for fitting,
installation and operation
Read and save these instructions!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EBC10 and is the answer not in the manual?

Questions and answers

Summary of Contents for Exodraft EBC10

  • Page 1 EBC10 EBC10 ALARM RESET Instructions for fitting, installation and operation Read and save these instructions!
  • Page 2: Table Of Contents

    Pressure-controlled regulation of exodraft chimney fan ........
  • Page 3 3120049-EBC10-UK Symbol Legend: The following terms are used throughout this manual to bring attention to the presence of potential hazards or to important information concerning the product. Prohibition symbol: Failure to observe instructions marked with a prohibition symbol may result in serious injury or death.
  • Page 4: Product Information

    4 • Product information 4 • Product information Product information Description The EBC10 (exodraft Boiler Control) is a specially designed control component for constant pressure regulation of chimney draft. Layout of the instructions The EBC10 can control an exodraft chimney fan.
  • Page 5: Delivery

    Measures pressure in chimney. Isolation switch REP-AFB Isolation switch Temperature 1100755 Measures the temperature in the chimney sensor Fitting 1.3.1 Cable length Max. cable length between EBC10 and XTP: 100 m. Max. cable length between EBC10 and chimney fan / fan: 100 m.
  • Page 6: Connection Diagram

    12 • Please note that the EBC10 is supplied with only 2 m of hose. *The default setting of the EBC10 is for negative pressure regulation, but local authority requirements may state that positive pressure must be maintained.
  • Page 7: Layout Of The User Interface

    3120049-EBC10-UK Product information • 7 Product information • 7 Make sure to position the pressure transducer the right way up. Do not blow into the valves on the XTP. Outdoor fitting of the pressure transducer (XTP) When fitting the pressure transducer outdoors, make sure to position it in a place where it is not affected by wind, rain, etc.
  • Page 8: Light Emitting Diodes And Terminal Board

    Meaning when the light diode is … 1, 2 & 3 SUPPLY IN 230-240VAC +/- 10% green: the EBC10 is connected to a power supply 4, 5 & 6 FAN OUT green: the triac output is active 7 & 8...
  • Page 9: Display

    Product information • 9 Product information • 9 1.4.3 Display The diagram below shows the layout of the display on the EBC10. All possible display values are stated: Pos. Shows … Symbol indicating the connection of Z-wave (Not included in EBC10) Symbol for service menu Symbol for alarms.
  • Page 10: Introduction To The User Interface

    Alarms • Setpoints • Parameters Menu structure The menu system in the EBC10 contains: • User menu (for operation by daily users). • Service menu (for operation by qualified technical staff ). Layout of the user interface The user interface is operated through four buttons with the following functions:...
  • Page 11: Set-Up

    To set the pressure in the chimney, follow the procedure detailed below. Step. Action... The display shows... • Start the heating system. • The EBC10 displays the actual pressure (in this example 30 Pa) • Briefly press to enter the user menu • Press •...
  • Page 12: Service Menu

    3120049-EBC10-UK 12 • Product information 12 • Product information Service menu The service menu is only to be operated by qualified staff. For an overview of the service menu, see page 13. Operation of the user menus is described in sections 2.
  • Page 13: Overview Of The Service Menu

    3120049-EBC10-UK Product information • 13 Product information • 13 1.7.1 Overview of the service menu Base settings for the The service menu is built up in four levels: three applications Menu level 1 Menu level 2 Menu level 3 Function...
  • Page 14 3120049-EBC10-UK 14 • Product information 14 • Product information Base settings for the The service menu is built up in four levels: three applications Menu level 1 Menu level 2 Menu level 3 Function Default Configuration Exit settings PDS/AUX config...
  • Page 15: Changing Between The Operating Functions

    Product information • 15 1.7.2 Changing between the operating functions ( Default operating function As its base function, the EBC10 is factory set to pressure-controlled regulation of exodraft chimney fans (operating function 1 How to change the operating function: Step Action...
  • Page 16: Pressure-Controlled Regulation Of Exodraft Chimney Fan

    The isolation switch is not supplied by exodraft. Available as an extra. Sample wiring diagrams As a constant pressure regulator for exodraft chimney fans, the EBC10 can be connected to a range of different signals. The following pages are sample wiring diagrams, and show the following: •...
  • Page 17: Single Boiler Application

    Pressure control • 17 3120049-EBC10-UK 2.4.1 Single boiler application This example shows how to connect a voltage signal (18–230 V AC/DC) for the EBC10 to start/stop the fan from the boiler: • Connect the supply voltage to terminals 1–3 •...
  • Page 18: Single Boiler Application With Potential Free Contact In Boiler

    18 • Pressure control 2.4.2 Single boiler application with potential free contact in boiler This example shows how to connect a potential free contact to the EBC10 to start/stop the fan: • Connect the supply voltage to terminals 1–3 •...
  • Page 19: Single Boiler Application With Extra Fail-Safe Protection Using Pds

    3120049-EBC10-UK 2.4.3 Single boiler application with extra fail-safe protection using PDS This example shows how to connect a PDS to the EBC10. The PDS carries out extra fail-safe protection. • Connecting a PDS: Œ Remove the factory fitted loop between terminals 26 and 28 Œ...
  • Page 20: Solid Fuel Boiler With Temperature Sensor

    3120049-EBC10-UK 20 • Pressure control 2.4.4 Solid fuel boiler with temperature sensor The example shows how to connect the temperature sensor to the EBC20 in order to stop and start the fan through the temperature in the chimney • Connect the supply voltage to terminals 1–3.
  • Page 21: User Menu

    You can always undo an action (that you have not confirmed by pressing ) and return to the operation screen by RESET pressing Alarms For alarm handling (menu 4), see page 23. Set-up For setting up the EBC10, see section 1.6 Set-up, page 11.
  • Page 22: Commissioning

    Turning the ventilator on and off by means of a temperature sensor in the flue The EBC10-boiler control can turn the ventilator on and off automatically by means of the temperature sensor, however the ventilator can also be turned on and off manually.
  • Page 23: List Of Alarms And Troubleshooting

    Automatic reset If menu 25 is set to automatic reset (1), the EBC10 will attempt to reset an alarm every 10 seconds. If error persists, check the alarm overview (next page) for solution. Manual reset If menu 25 is set to manual reset (2), alarms must be manually reset.
  • Page 24: Alarm Overview

    Error in Safety relay circuit Error in Safety relay circuit Reset to defaults (menu 18). Error in Safety relay circuit Turn the EBC10 off. Safety No HeartBeat Restart again. Safety input circuit error If error persists, contact dealer (defective unit).
  • Page 25: More Troubleshooting

    List of alarms and troubleshooting • 25 More troubleshooting 3.2.1 Program running If there is doubt about whether the EBC10 is running: Check if the control LEDs are flashing. To view the control LEDs: Remove the front panel. control LEDs This work must be performed by a qualified electrical engineer.
  • Page 26: Technical Specifications

    T4 A Ambient temperature: -20 °C to 60 °C Regulation range: -500 Pa to 500 Pa Wiring from EBC10 to chimney fan / fan Max. 100 m. Inputs Digital inputs (BOILER 1 IN ): 18 to 230 VAC / VDC...
  • Page 27: Eu Declaration Of Conformity

    3120049-EBC10-UK Technical specifications • 27 EU declaration of conformity Declaration of Conformity DK: EU-Overensstemmelseserklæring NL: EU-Conformiteits verklaring GB: Declaration of Conformity SE: EU-Överensstämmelsedeklaration DE: EU-Konformitätserklärung EU-Vaatimustenmukaisuusvakuutus FR: Déclaration de conformité de l’Union Européenne ESS-Samræmisstaðfesting NO: EU-Samsvarserklæring Dichiarazione di Conformità Unione Europea exodraft a/s C.F.
  • Page 28 DK: exodraft a/s NO: exodraft a/s DE: exodraft GmbH C. F. Tietgens Boulevard 41 Storgaten 88 Soonwaldstraße 6 DK-5220 Odense SØ NO-3060 Svelvik DE-55569 Monzingen Tel: +45 7010 2234 Tel: +47 3329 7062 Tel: +49 (0)6751 855 599-0 Fax: +45 7010 2235...
