5. Commissioning and Test Software

5.1 STARTING THE SOFTWARE

Commissioning / Test software is supplied to check the operation of the Twin Rotor
MIMO System, before using the MATLAB driven control software.
Windows 95 installation
Insert the MIMO Commissioning / Test software disk in drive A: From the
Windows 95 Start menu click on RUN and use the browse feature to locate the
MIMOTST.EXE program on drive A:
Windows 3.1 installation
Insert the MIMO Commissioning / Test software disk in drive A: Start File Manager
and click on the MIMOTST.EXE program drive A:. Click on RUN from the File
manager File menu.
DOS installation
Insert the MIMO Commissioning / Test software disk in drive A: Type in the
following DOS commands.

5.2 SOFTWARE OPERATION

After starting the MIMO commissioning and test software you will see the following screen
presented.
33-007-0
> A:
> MIMOTST
Fig 5.1. Start screen
