  • Page 1 www.stigagames.com ASSEMBLY INSTRUCTION MANUAL MONTERINGSANVISNING SLAM 30” HOOP ART. NO. 61-4803-30...
  • Page 2 ENGLISH STIGA Slam 30” Hoop - Art.no. 61-4803-30 OWNER’S MANUAL 1. Read this manual carefully before starting assembly. Read each step completely before beginning each step. 2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering parts.
  • Page 3 SVENSKA STIGA Slam 30” Hoop - Art.no. 61-4803-30 ÄGARMANUAL 1. Läs manualen noggrant innan montering. Fullfölj varje steg innan du påbörjar ett nytt. 2. Mindre delar kan fraktas inuti större delar. Vänligen kontrollera alla delar innan montering eller beställning av reservdelar.
  • Page 4 CONTENT / INNEHÅLL Pack contents Pos. PC(S) / Description Benämning / Fig. ANTAL Backboard Backboard Korg Wall bracket Väggfäste Bolts Bultar Wall anchor Plugg Spring Washer Fjäderbricka Washers Bricka...
  • Page 5 Solid Wood: Drill 1/8”pilot hole at all STEP 1 / STEG 1 , flat washer into each pilot hole. Solid B STIGA Slam 30” Hoop - Art.no. 61-4803-30 Marks. Tap wall anchors into each hole flat washer into each pilot hole. Tighten...
  • Page 6 STEP 2 / STEG 2 STIGA Slam 30” Hoop - Art.no. 61-4803-30 ENGLISH 1. Place the rim (P2) against the wall in the desired position. Check for squareness with a spirit level. Mark the two hole positions through the bracket with a marker pen.
  • Page 7 STEP 3 / STEG 3 STIGA Slam 30” Hoop - Art.no. 61-4803-30 ENGLISH 1. Position the wall brackets (P5) on either side of the backboard and mark the hole positions through the bracket with a marker pen. 2. See illustration on page 5: A) If you have a solid wood wall.
  • Page 8 DISTRIBUTORS, where you can find detailed contact information. On the webpage you will also find the STIGA Games assortment and manuals for download. 8200-0507-09 A05 / 2015-12-16 © Copyright STIGA Sports AB.
