O W N E R ' S M A N U A L
1. Read this manual carefully before starting assembly. Read each step completely before beginning
each step.
2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons
before assembling or ordering parts.
3. To make assembly easier, use the Hardware Identifier on page 2 to identify and sort all
fasteners. Check all cartons for kits. All hardware may not be located in one kit.
4. Do not tighten hardware until instructed to do so. If hardware is tightened too soon, mounting holes
may not align and parts may not easily fit together. Leave locknuts slightly loose until you are instructed to
tighten them.
5. Tools required for assembly: Phillips Screwdriver, Two 9/16" Wrenches, One 7/16" Wrench.
Note: Adjustable wrenches can be substituted for wrenches.
6. Save this instruction manual and your proof of purchase (receipt) in the event that the
manufacturer has to be contacted for replacement parts.
Please Do Not Return This Product To The Store!
Contact Escalade
Phone:
1-866-873-3528
Fax:
1-866-873-3533
E-mail:
tabletennis@escaladesports.com
Mailing Address (correspondence only):
Escalade Sports
PO Box 889
Evansville, IN 47706
Please visit our World Wide Web site at:
ON-LINE TROUBLE SHOOTING
ON-LINE PARTS REQUESTS
ADDITIONAL ESCALADE
Escalade® Sports products may be manufactured and/or licensed under the following patents.
6120397, 5816957, 5769744, 5119741, 4911085, 4717157, D460140, D420563, 8414431
Additional patents may be pending. One or more of the listed patents and/or pending patents may cover specific product.
®
Sports customer service department at:
®
SPORTS PRODUCT INFORMATION
Toll – Free !
Toll – Free !
www.escaladesports.com
TECHNICAL ASSISTANCE
FREQUENTLY ASKED QUESTIONS
TABLE TENNIS TABLE
MODEL NO.
T8525
2L-4140-04
2013 Escalade Sports

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STS 520 and is the answer not in the manual?

Questions and answers

Related Manuals for Stiga STS 520

Summary of Contents for Stiga STS 520

  • Page 1 TABLE TENNIS TABLE MODEL NO. T8525 O W N E R ' S M A N U A L 1. Read this manual carefully before starting assembly. Read each step completely before beginning each step. 2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering parts.
  • Page 2 5/16-18 x 3 Hex Head Bolt Spacer Bushing (Qty. 4) (Qty. 4) Spacer 3/8 Push Nut (Qty. 8) 1/4-20 Locknut (Qty. 4) (Qty. 20) 1/4-20 X 3 Hex Head Bolt 1/4-20 X 3 1/4 Hex Head Bolt (Qty. 4) (Qty. 4) 1/4-20 X 4 Hex Head Bolt 1/4-20 X 2 Hex Head Bolt (Qty.
  • Page 3 ATTACHING LEGS TO TABLE TOPS CAUTION AT LEAST TWO ADULTS ARE NEEDED TO COMPLETE THE FOLLOWING STEPS! Rail not shown for clarity. 2. Leave top halves #1 in shipping carton as shown above or lay them on a carpeted floor (to protect them from damage and scratches ).
  • Page 4 ATTACHING NAME PANELS TO LEGS AT LEAST TWO ADULTS ARE NEEDED TO COMPLETE THE CAUTION FOLLOWING STEPS! DO NOT LEAVE TABLE UNATTENDED UNTIL ASSEMBLY IS COMPLETE! Detail D HELPFUL HINT: Start at the bottom and insert two 8. With a helper , hold top halves about 14 ½ inches bolts #26 UPWARD through upright assemblies #11 apart.
  • Page 5 ATTACHING LINKAGE TO LEGS Detail F Detail E 10. Attach linkages #24 to upright assembly #11 using 11. Attach other end of linkages #24 to leg assembly bolts #27, spacers #18, and locknuts #28. (See #10 using bolts #22, spacers #18, and locknuts Detail E).
  • Page 6 ATTACHING CASTERS Detail G 13.Put caps #15 into ends of caster beams #12 (see Detail G). 14 . A ttach one non-locking caster #13 and one locking caster #14 to each caster beam #12 with push nuts #17. (See Detail G). Note: Use a hammer to tap push nuts onto casters securely.

  • Page 7: Making Final Adjustments

    SETTING TABLE UPRIGHT At least two adults are needed to complete the following steps. Be sure top halves are locked in safety latches! Be sure CAUTION that both locking casters are locked! You must use a 8" stack of magazines (or similar block) to protect the casters when lifting table upright! 8”...

  • Page 8: Finishing The Assembly

    FINISHING THE ASSEMBLY NOT E: If sides of table are not even with one another, loosen the bottom four bolts that were loosened in the previous page and push both sides inward as shown until they are even. Retighten bolts when sides are even. OPERATING INSTRUCTIONS ALWAYS LOCK TABLE TOP HALVES IN SAFETY LATCHES WHEN STORING, ALWAYS LOCK TABLE TOP HALVES IN SAFETY LATCHES WHEN STORING,...

  • Page 9: One-Year Limited Warranty

    ONE YEAR LIMITED WARRANTY This consumer warranty extends to the original consumer purchase of any ESCALADE ® SPORTS Product (hereinafter referred as the "Product"). WARRANTY DURATION: This Product is warranted to the original consumer purchase of a period of one (1) year from the original purchase.
  • Page 10 Use PART # column QTY. column refers to T8525 PARTS LIST when calling for the total number of replacement parts. pieces in product. ITEM # PART# DESCRIPTION QTY. ITEM # PART# DESCRIPTION 4A-6324-01 Table Top Half 7B-4059-02 Nylon Spacer 2S-4668-02 Side Rail - Right Hand 7B-6240-03 Spacer Bushing...
