- Page 1 ASSEMBLY INSTRUCTION MANUAL MONTERINGSANVISNING RIM 45 CM ART. NO. 61-4800-45...
- Page 2 ENGLISH STIGA Rim 45 cm - Art.no. 61-4800-45 OWNER’S MANUAL 1. Read this manual carefully before starting assembly. Read each step completely before beginning each step. 2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering parts.
- Page 3 SVENSKA STIGA Rim 45 cm - Art.no. 61-4800-45 ÄGARMANUAL 1. Läs manualen noggrant innan montering. Fullfölj varje steg innan du påbörjar ett nytt. 2. Mindre delar kan fraktas inuti större delar. Vänligen kontrollera alla delar innan montering eller beställning av reservdelar.
- Page 4 CONTENT / INNEHÅLL STIGA Rim 45 cm - Art.no. 61-4800-45 Pos. PC(S) / Description Benämning / Fig. ANTAL Hoop Korg Nät Washer M10 Bricka M10 Spring Washer M10 Fjäderbricka M10 Bolt 10 x 80 mm Bult 10 x 80 mm...
- Page 5 STEP 1 / STEG 1 STIGA Rim 45 cm - Art.no. 61-4800-45 ENGLISH NET AND RIM ASSEMBLY 1. Take the loops at the top edge of the net. Hook one loop over and around center of one rim hook. Pull loop down to secure loop within the rim hook.
- Page 6 65mm. To accomodate the bolts (A) and plugs (D). STEP 2 / STEG 2 STIGA Rim 45 cm - Art.no. 61-4800-45 cket (H) so that the holes align with the holes on the backboard (E).
- Page 7 STEP 2 / STEG 2 STIGA Rim 45 cm - Art.no. 61-4800-45 ENGLISH 1. Place the Rim (P1) against the wall in the desired position. Check for squareness with a spirit level. Mark the four hole positions through the holes with a marker pen.
- Page 8 DISTRIBUTORS, where you can find detailed contact information. On the webpage you will also find the STIGA Games assortment and manuals for download. 8200-0507-12 A01 / 2015-12-17 © Copyright STIGA Sports AB.
