- Page 1 www.stigagames.com ASSEMBLY INSTRUCTION MANUAL MONTERINGSANVISNING GUARD 34” ART. NO. 61-4820-34...
- Page 2 ENGLISH STIGA Guard 34” - Art.no. 61-4820-34 OWNER’S MANUAL 1. Read this manual carefully before starting assembly. Read each step completely before beginning each step. 2. Some smaller parts may be shipped inside larger parts. Check inside all parts and cartons before assembling or ordering parts.
- Page 3 SVENSKA STIGA Guard 34” - Art.no. 61-4820-34 ÄGARMANUAL 1. Läs manualen noggrant innan montering. Fullfölj varje steg innan du påbörjar ett nytt. 2. Mindre delar kan fraktas inuti större delar. Vänligen kontrollera alla delar innan montering eller beställning av reservdelar.
- Page 4 CONTENT / INNEHÅLL STIGA Guard 34” - Art.no. 61-4820-34 Pos. PC(S) / Description Benämning / Fig. ANTAL Backboard Backboard Korg Base Bottom Pole Nedre stolpe Middle Pole Mittstolpe Top Pole Övre stolpe Support Arm Stödarm Wheel Axle Hjulaxel Pole Bracket Stolpfäste...
- Page 5 CONTENT / INNEHÅLL STIGA Guard 34” - Art.no. 61-4820-34...
- Page 6 STEP 1 / STEG 1 STIGA Guard 34” - Art.no. 61-4820-34...
- Page 7 STEP 1 / STEG 1 STIGA Guard 34” - Art.no. 61-4820-34 Pos. / PC(S) / Description Benämning Fig. ANTAL Base Bottom Pole Nedre stolpe Support Arm Stödarm Axle Hjulaxel Wheel Hjul Plastic nut Plastskruv Base cap Baslock Lock Nut M8...
- Page 8 STEP 2 / STEG 2 STIGA Guard 34” - Art.no. 61-4820-34...
- Page 9 STEP 2 / STEG 2 STIGA Guard 34” - Art.no. 61-4820-34 Pos. / PC(S) / Description Benämning Fig. ANTAL Backboard Backboard Korg Pole Bracket Stolpfäste Lock Nut M6 Mutter M6 Washer M6 Bricka M6 Bolt M6 x 30mm Bult M6 x 30mm ENGLISH 1.
- Page 10 STEP 3 / STEG 3 STIGA Guard 34” - Art.no. 61-4820-34...
- Page 11 STEP 3 / STEG 3 STIGA Guard 34” - Art.no. 61-4820-34 Pos. / PC(S) / Description Benämning Fig. ANTAL Backboard Backboard Middle Pole Mittstolpe Top Pole Övre stolpe Pole Bracket Stolpfäste Triangle Nut Triangelmutter Top Pole Cap Lock till Övre stolpe...
- Page 12 STEP 4 / STEG 4 STIGA Guard 34” - Art.no. 61-4820-34...
-
Page 13: Height Adjustment
STEP 4 / STEG 4 STIGA Guard 34” - Art.no. 61-4820-34 Pos. / PC(S) / Description Benämning Fig. ANTAL Bottom Pole Nedre stolpe Middle Pole Mittenstolpe Top Pole Övre stolpe Screw M5 x 16mm Skruv M5 x 16mm ENGLISH 1. Insert the Middle pole (P5) inside the Bottom pole (P4). Lock it in place with the Screw (H10). - Page 14 STEP 5 / STEG 5 STIGA Guard 34” - Art.no. 61-4820-34 ENGLISH RECOMMENDATIONS It is recommended filling the base with sand, not water. If water is used, make sure to empty all the water completely from the base before the temperature approaches or falls below the freezing point.
- Page 15 STEP 6 / STEG 6 STIGA Guard 34” - Art.no. 61-4820-34 ENGLISH MOVING SYSTEM 1. Adjust backboard to lowest position. 2. While holding the pole and lifting the back of the base, carefully lean system forward until wheels touch ground.
- Page 16 DISTRIBUTORS, where you can find detailed contact information. On the webpage you will also find the STIGA Games assortment and manuals for download. 8200-0507-04-A05 / 2016-04-26 © Copyright STIGA Sports AB.
