Summary of Contents for Makeblock HaloCode
- Page 1 HaloCode Standard Kit Sample Project Guide...
- Page 2 What's even better is that HaloCode can also interact with the mBlock 5 stage. Now let's make a simple project using HaloCode. In this project, you'll learn how to use the alligator clips to create a project. With the cardboard inside the package and the copper foil tapes, the LEDs can illuminate the corresponding color when you touch a specific...
- Page 3 Find the materials you need. (cardboard inside the package)
- Page 4 Attach the yellow, blue and green alligator touch sensor 0. clips to touch sensor 1, 2 and 3 respectively. DO NOT use an alligator clip to connect the 3.3V pin to the GND pin, otherwise a short circuit might happen and HaloCode might be damaged.
- Page 5 Tailor the cardboard inside the package and fold it as shown. Attach copper foil tapes to the cardboard. Remove the protective films on the copper foil tapes. *The copper foil tapes are conductive on both sides. *The protective film is used to protect the Attaching the alligator clips to the tapes can expand tape from oxidation.
- Page 7 Connect HaloCode to a computer with the Micro USB cable. mBlock 5 Start coding. Note: Check Quick Start Guide to see detailed instructions on using mBlock.
- Page 8 Now you know how to use the alligator clips. Use your imagination to create more fun projects. D1.1.1_KD010135000...
